XT-1
One Pedal, Infinite Guitars
User Manual (EN)
"Sim1 - Sound Imprinting' is a registered trademark property of
Sim1 Srl. All other product names and images, trademarks and
artists names are the property of their respective owners, which
are in no way associated or affiliated with Sim1. Product names
are used solely for the purpose of describing certain types of
tones achievable with Sim1's modeling technology. Use of
these names does not imply any cooperation or endorsement".
1
Advertisement
Related Manuals for SIM1 XT-1
Summary of Contents for SIM1 XT-1
- Page 1 Sim1 Srl. All other product names and images, trademarks and artists names are the property of their respective owners, which are in no way associated or affiliated with Sim1. Product names are used solely for the purpose of describing certain types of tones achievable with Sim1’s modeling technology.
- Page 2 XT-1: One Pedal, Infinite Guitars! Thank you for buying the new XT-1 by SIM1. This is the first guitar profiling system that makes it possible to play your electric guitar with the sound of any other existing guitar in the world.
- Page 3 Do not try to repair the device or replace parts within it. This violation will invalidate the warranty. For any damage or inconvenience please refer to SIM1 srl or an authorized SIM1 distributor/store. Use only the specified AC adaptor, and make sure the line voltage at the installation matches the input voltage specifications.
- Page 4 Make sure that liquids of any kind are not spilled on the device. Do not use or place the device near water. Immediately turn off the device and remove the AC Adaptor from the mains power source, and request assistance from a SIM1 Srl or an authorized SIM1 distributor/store, when: •...
- Page 5 Product Specifications Total pre-sets…………….…..………………………………………………………………30 Guitar Profiles pre-loaded………………………………………………………………12 AD Conversion.………………….……………………..……………………………….32 bit DA Conversion…................32 bit Sample Rate….………………….……………………..………………………...48/96 kHz Input Impedance…………………………………………………………..…………..1 MΩ Output Impedance (Standard Output-OUT)………….…………………..680 Ω Output Impedance (Balanced Output-BAL)……...……………..……...10 kΩ Recommended Load Impedance……………....10 KΩ or Greater Signal To Noise ratio……………………………………...……….….…..> 104 dB Controls…….…….…On/Off switch, Up &...
- Page 6 1. LED Display: Backlit display, consists of two lines of 16 characters each. It shows all the information concerning the working procedures of XT-1 and the guitars tones when in use (Guitar Brand and Model, Bench number, Pick Up position).
- Page 7 6. AC Adaptor Jack: An AC Adaptor (sold separately) must be connected to this jack in order to use XT-1. For more information see the Specifications manual section. 7. Input Jack: This jack accepts input signals coming from a guitar 8.
- Page 8 13. USB Storage stick: To store a backup of the sounds on the device transport it to the configurator, make your own patch and store it back to the pedal. 14. Wi Fi USB Key: To connect XT-1 to a mobile phone/tablet and synchronize the device to the app for Android/IOS. Connections...
- Page 9 Connections Place XT-1 on the floor and make sure that the on/off switch (10) is in the off position (O), then connect the Power Supply 9V-1A (sold separately) to the electric socket and to the XT-1. Before connecting or disconnecting any device to XT-1 always make sure that the on/off switch (10) is in the off position (O) and that the volume control in your system are set to the minimum.
- Page 10 The “Shop Mode” allows you to record 1 or 3 pickup positions of the Source Guitar, and automatically assigns this Guitar to all pre-sets of XT-1. At the same time all pre-sets sounds will be restored into those ones of Factory Default.
- Page 11 (4) and repeat the chromatic scale (point 7). 11. If you are satisfied with the quality rating, then press the “Up switch” (5). The system will make a computing process of the sounds loaded in the XT-1 (Display: Computing Progress 00%...100%).
- Page 12 23. For any reason, during each Pickup recording, it is possible to stop the procedure, just by holding for 2 seconds the Down Switch (4). With the Shop Mode XT-1 creates 3 Source Guitars (Guit1, Guit2 Guit3), each of them corresponding to a different Pickup. The system will automatically assign: - the Source Guit1 (Neck Pickup) to all the Target Guitars with the emulation of a Neck/Piezo Pickup sound or Mic recorded sound;...
- Page 13 Guitar, and automatically assigns this Guitar to all pre-sets of XT-1. In this case the pre-sets sounds won’t be changed into those ones of Factory Default. 1. Connect the Source Guitar to the Input Jack (7) of XT-1 and the Output Jack (8/9) to the amplifier/Mixer as described in the “Connections Section”;...
- Page 14 The “Learn&Play Mode” allows to record 1 pickup positions of the Source Guitar and store it to XT-1. In this case the target sounds on the pedal won’t be automatically assigned to this Source Guitar. You should do it manually using the “Configurator Software”...
- Page 15 USB Port XT-1 is equipped with an USB Port 2.0, which must be used with the USB stick to transfer the sounds (both source guitars and target guitars) from XT-1 to the Configurator Software, make your own set up, and return them back to XT-1 to make the upgrade of the device.
- Page 16 Please note that if you do not input in a correct way the Serial Number Code on the Web/App, the downloaded sounds will not be correctly installed in your XT-1 device and they will not work properly.
