- Page 1 EDGE Power Module 4 Outputs, EDGE Power Module 2 Outputs Models: 074–11770, 074–11771 Wiring Diagrams 891–00548 Version 3.0 Date: 07-15-18...
- Page 2 All information, illustrations, photos, and specifications in this manual are based on the latest information available at the time of publication. The right is reserved to make changes at any time without notice. 891–00548 EDGE Power Module Wiring Diagrams...
-
Page 3: Wiring Diagrams
Wiring Diagrams Topics Covered in this Chapter ▪ Wiring Diagrams ▪ Technical Specifications Wiring Diagrams Figure 1-1 Grounding, page 3 Figure 1-2 Variable Output (SSR) Wiring, page 4 Figure 1-3 Wiring Diagram With a SPST Disconnect Switch, page 4 Figure 1-4 Wiring Diagram With a DPST Disconnect Switch, page 5 Figure 1-1 Grounding Proper grounding must be followed for the heatsink... - Page 4 Chapter 1: Wiring Diagrams Figure 1-2 Variable Output (SSR) Wiring Variable Output/SSR 064-11343 Variable Electric Light/ Heater Heat Lamp L2/N 100-240VAC Output Warning: Place the connector with the ferrite bead in the L2/N EDGE Power module enclosure L2/N wire return must To variable module not share the same wire as the load...
-
Page 5: Technical Specifications
Chapter 1: Wiring Diagrams Figure 1-4 Wiring Diagram With a DPST Disconnect Switch EARTH EARTH To the L2/N controller L2/N DPST disconnecting switch Breaker circuit Technical Specifications EDGE Power Module - Safety ratings Requires a minimum load of 0.2A Resistive loads (heat lamps, heat mats, incandescent light) 16.66A A MAX 120 VAC, 2000 W, 16.66 A, 50/60 Hz... - Page 6 Chapter 1: Wiring Diagrams Storage Temperature -20 to 50°C (-4 to 122°F) Environment Type Indoor use only Pollution Degree Installation Category Altitude 2000 Meters Max. (5661 Ft. Max) Operating Relative Humidity 0 to 10°C (32 to 50°F) Non condensing (maximum) 10 to 30°C (50 to 86°F) 95 % (±...
- Page 7 Chapter 1: Wiring Diagrams Allowable loss of performance in a noisy environment Accuracy of ±0.8A from initial reading with a load of 1% precision used for testing purpose 0–10Vdc outputs 0–10Vdc, accuracy: 1% (means, 0.1V) 891–00548 EDGE Power Module Wiring Diagrams...
- Page 8 NOTES 891–00548 EDGE Power Module Wiring Diagrams...
-
Page 9: Conditions And Limitations
All Fiberglass Propellers Lifetime 5 to 7 years - end-user pays 50% 7 to 10 years - end-user pays 75% Flex-Flo/Pan Feeding System Motors AP/Cumberland 2 Years Feeder System Pan Assemblies 5 Years ** ** Warranty prorated from list price: Cumberland Feed Tubes (1-3/4"... - Page 10 1004 E. Illinois St. Assumption, IL 62510-0020 Phone: 1-217-226-4421 Fax: 1-217-226-4420 www.gsiag.com AP and Cumberland are a part of GSI, a worldwide brand of AGCO Corporation. Copyright © 2018 by GSI Group Printed in Canada 895–00756 REV. 1 CN #891–00548...
