Step 7:
Estimated time for this step: 15 minutes
With the positions and programming of all your major components settled, you can now install your CB2000s. Refer to
the diagrams in Step 1 as you connect components.
1. Install a double-gang electrical box (if using CB2050 or CB2000 with CB50) or single-gang electrical box (for
CB2000), surface box, or mud ring according to the manufacturer's instructions.
2. If using the CB2000 with a FrontRow CM3000 amplifier/switch (if not, skip to #3):
• Install Cat 5 cable from the electrical box to the location of the FrontRow CM3000. Ensure the cable is installed in
compliance with your national and local electrical codes.
• Connect the Cat 5 cable to the CB2000's Network jack.
WARNING: TO AVOID DAMAGE, CONNECT TO THE CB2000'S "NETWORK ONLY" JACK!
If you are controlling a serial device (e.g., projector), connect the provided serial cable(s) to the CM3000's
COM1 captive screw connector. Wiring is as follows:
• Black (ground) to GND
• Red (input to device) to TX1
• White (output from device) to RX1
IMPORTANT: Be sure to keep wiring and Action commands consistent to avoid
problems. For example, serial Actions sent to COM1 should use the TX1/RX1 pins.
(See Appendix A).
• If you are controlling a device via infrared (e.g., a DVD player), connect an IR emitter cable (not included; part
number 520-3001-001) to the TB5 IR Emitter Cable Extension Adapter (not included; part number 310-2546-120)
and connect the TB5 to the CM3000's IR captive screw connector. Secure the emitter end to the controlled
device's infrared sensor. Be sure the CB2000 jumper (see page 2) is connecting pins 2 and 3.
• If you are using general purpose input (GPI) signals, be sure the CB2000 jumper (see page 2) is connecting
pins 1 and 2.
• Connect the Cat 5 cable to one of the CLAN jacks on your CM3000.
• If connecting your ezRoom to a local area network (for example when used with a Conductor system), connect
the network cable to LAN1 or LAN2 on the CM3000.
If using the CB2000 as a standalone controller with the TB12 adapter, or TB6 and TB8 adapters:
3.
• Mount the TB adapter(s) securely near the projector or other device to be controlled.
• Thread Cat 5 cable from the electrical box to the location of the TB adapter(s). Ensure the cable is installed in
compliance with your national and local electrical codes.
• Connect the Cat 5 cable to the CB2000's AUX jack.
WARNING: TO AVOID DAMAGE, CONNECT TO THE CB2000'S "AUX" JACK!

Install your CB2000
