Bluefin LED GW20IFM Installation Manual

Bluefin LED Underwater lights.
GW20IFM/GW48CCIFM Installation manual.
Thank you for choosing Bluefin LED underwater lights, our products have been designed and tested
to ensure optimum performance and longevity is maintained.
All Bluefin Led lights are water tested so please be aware there may be moisture present on the light.
This light is designed for use on fibre glass hulls only and not to be mounted to any Metal hull or
your warranty will be void. If you are mounting to a Metal hull boat a Delrin isolation sleeve can be
purchased.
Please ensure that your product is installed as per our instructions below, failure to do so may
invalidate your warranty.
If you are installing a GW48CCIFM please refer to the Driver instructions for electrical installation.

Specification: electrical/fuse ratings

Great White
GW20IFM

Warnings:

•
Do not attempt to install the lights whilst the boat is in the water.
•
Ensure that the correct voltage is used for the light.
•
Ensure that an in line fuse is installed with the correct fuse rating per the light installed.
•
Ensure that the supplied gel connector is used to make a watertight connection or your
Warranty will be Void.
•
Do not remove the inline HYDRO LOCK or your warranty will be void.
•
Do not hold the light by the cable.
•
Do not use abrasives on the lenses.
•
Do not stare into the LED light at close proximity
•
Lights must be mounted a minimum of 300mm from any Anodes.
•
Do not mount lights directly underneath Anodes.
•
Do not bond directly to Anodes.
•
Only bond to the vessels DC bonding system & ensure all connections are in perfect
condition & are regularly checked.
•
When mounting on any type of conductive surface or hull material full electrical isolation
between the light & mounting surface must be provided & maintained at all times
throughout the lights life.
•
Failure to adhere to any of these requirements will invalidate warranty.
•
As Galvanic currents & corrosion are external factors any type of damage caused by galvanic
affects are not covered by BluefinLEDs warranty policy.

Tools required for installation:

•
101mm(4") hole saw
•
Drill
•
Marine sealant 3M 5200/4000UV, Sika flex 291i or equivalent (do not use 3M 4200)

Installation:

For optimum affect effect the light should be positioned between 8-12" (200-300mm) below the
water line and at a 90 deg angle. Recommended spacing from 3-3"(1mtr) to 5-11" (1.8mtrs) between
the lights.
1
Voltage
24V only (Absolute min of
19V under load @ light).
Current Fuse rating
24v-5.1 8amp
