Bluefin LED Firefly FF Installation Manual

Bluefin Led Underwater lights.
Firefly Flood Light FB/FF/FR Installation manual.
Thank you for choosing Bluefin LED lights, our products have been designed and tested rigorously to
ensure optimum performance and longevity.
As these lights are highly polished please be careful on installation not to scratch the lights as they
will mark easily.
Please ensure that your product is installed as per our instructions below, failure to do so may
invalidate your warranty.
Specs: electrical/fuse ratings
Voltage
Flood light 12/24VDC

Warnings:

•
Ensure that the correct voltage is used for the light.
•
Ensure that an in line fuse is installed with the correct fuse rating per the light installed.
•
Ensure that use the Screws provided.
•
Ensure all connections are made water tight.
•
Do not hold the light by the cable.
•
Do not use abrasives to clean the light.
•
Do not look directly into the light at close proximity

Tools required for installation:

•
3.5mm (9/64") and 5mm drill bit for Bracket mounted option.
•
3mm and 8mm drill bit for surface mounted option
•
3mm drill bit and multi tool cutter for recessed mounted option.
•
Drill
•
Posi head hand screwdriver

Installation:

Bracket mounted option Fig 1
Choose the location for the bracket flood light to be mounted, use the bracket as a template for the
screw holes and drill two holes using a 3.5mm drill.
Mount the bracket using the two supplied screws.
You will notice single larger hole in the centre of the bracket, this is for the cable to be passed
through if necessary. Please be careful not to bend the cable at the light end. The cable dia is 5mm
for the cable to be passed through the structure being mounted too.
Adjust the angle of the light and lock in place using a 3mm Allen key on the two side bolts.
Surface mount option Fig 2
Choose the location for the surface flood light to be mounted, use the two holes on the light as a
template for the screw holes and drill the two holes using a 3mm drill.
Drill an 8mm hole central for the cable access to be passed through..
Mount the Light using the two supplied screws.
1
Current
12v 850ma/24v 420ma
Fuse rating
3 amp
