Tokheim ProGauge MAGLINK LX User Manual
Hide thumbs Also See for ProGauge MAGLINK LX:

Advertisement

USER MANUAL
MAGLINK LX
Rev. 9 – 04-2016

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ProGauge MAGLINK LX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Tokheim ProGauge MAGLINK LX

  • Page 1 USER MANUAL MAGLINK LX Rev. 9 – 04-2016...
  • Page 2 This page is left intentionally blank.
  • Page 3: Table Of Contents

    Maglink LX User Manual | Summary UMMARY PREFACE ................................4 GENERAL WARNINGS ............................4 INTRODUCTION ..............................5 GENERAL DESCRIPTION ............................7 ..........................7 ABELLING AND TYPE DESIGNATION ................................. 7 ESCRIPTION .............................. 8 OMPATIBLE PROBES INTENDED USE AND REASONABLY FORESEEABLE MISUSE .................. 9 POWER ON/OFF ..............................10 OPERATION ...............................11 .................................
  • Page 4: Preface

    Maglink LX «Manual_name» | Preface REFACE Start Italiana S.r.l. has made every effort possible so that this document is complete, accurate and updated. With every revision of the console, the corresponding information is periodically added to the document. Start Italiana S.r.l. reserves the right to make unannounced improvements and/or changes in the product and/or associated programs.
  • Page 5: Introduction

    Maglink LX User Manual | Introduction NTRODUCTION This manual has been prepared in accordance with IEC 82079-1 standards. “Preparation of instructions for use - Structuring, content and presentation - Part 1: General principles and detailed requirements”and according to the ATEX Directive 2014/34/EU concerning equipment and protective systems intended for use in potentially explosive atmospheres.
  • Page 6 Maglink LX User Manual | Introduction The Maglink LX console complies with the requirements of Directive 2012/19/EC on waste of electrical and electronic equipment (WEEE) and hence displaying the according symbol: IMPORTANT: The crossed out wheelie bin symbol indicates that the product, at the end of its useful life, must be disposed of with household waste and must be brought to a collection point for electrical and electronic equipment ATTENTION: The units of measurement contained in this manual refer to a specific choice by...
  • Page 7: General Description

    Maglink LX User Manual | General description ENERAL ESCRIPTION 4.1 Labelling and type designation The following table lists the labels placed on the equipment: Labelling Description The labelling on the outer container contains the following data: • Name and address of the manufacturer •...
  • Page 8: Compatible Probes

    Maglink LX User Manual | General description The following table lists the principal technical characteristics of the console: Characteristic Value Power supply 100 ÷ 240 V~, 50÷60 Hz Consumption 15 VA Operating temperature (-10 ÷ +50) °C Relative humidity (5 ÷ 95)%, non-condensing Number of probes Number of ON-OFF external sensors Up to 32...
  • Page 9: Intended Use And Reasonably Foreseeable Misuse

    Maglink LX User Manual | Power On/Power Off NTENDED USE AND REASONABLY FORESEEABLE MISUSE The intended use for the MAGLINK LX console is only for that described in this manual. The console is used for monitoring the level of the probes installed in the tanks. The console must be installed in a safe area and includes an Intrinsic safety barrier, 2 channels (BRA-2SIP) that serve to connect the XMT-SI-485 probes The following table lists the characteristics of use of the intrinsically safe barrier contained in the console:...
  • Page 10: Power On/Off

    Maglink LX User Manual | Power On/Power Off ON/OFF OWER IMPORTANT: Only authorized/trained personnel following the installation inline with the manufactures instructions can switch on the console. This operation must be in accordance with the instructions of the Installation Manual and according to Safety Instructions. The following table lists the steps necessary to switch on the console: Step Description...
  • Page 11: Operation

    The following table lists the data visible in the second row at the top of the page: Information Description Red arrow on Circular menu including: "Tanks,” "Tank Details,” "Location,” "ALARM LOG" Tokheim Station name Tanks Page Title INFO Button to access system information/functions...
  • Page 12: Functions

    Maglink LX User Manual | Manual update 7.1 Functions Using the up/down red arrows, you can access the functions of the console. The following table lists the available functions: Paragraph Function Description Icon Display tanks connected to the console/Select tank to be 7.1.1 Tanks displayed...
  • Page 13: Tanks

    Maglink LX User Manual | Manual update 7.1.1 Tanks The following image shows an example of the "Tank Page": The following table lists the page elements: Element Description Tank graph Graphical representation of the level in the tank The following data is displayed: •...
  • Page 14: Tank Details

    Maglink LX User Manual | Manual update 7.1.2 Tank details The following image shows an example of the "Tank Details": (It is accessed by clicking on the graphic on the page of this tank "Tank"): The following table lists the page elements: Element Description Graphical representation of the level in the tank...
  • Page 15 Maglink LX User Manual | Manual update 7.1.2.1 Tank Details/Tank Configuration The following image shows an example of the "Tank Configuration" (Accessed by clicking the icon the left): The following table lists the page elements: Element Description The following parameters are displayed: •...
  • Page 16 Maglink LX User Manual | Manual update 7.1.2.2 Tank Detail/Historical chart The following picture shows an example of the "Graph history" page (accessed by clicking the icon the left): The page shows the trend of the tank level displayed in [mm] over a 24 hr period. Legend (the lines are present only if the corresponding alarms are configured): Colour Description...
  • Page 17 Maglink LX User Manual | Manual update 7.1.2.3 Tank Detail/Historical list The following picture shows an example of the "Graph list" page (accessed by clicking the icon on the left): The following table lists the page elements, as a function of time: Element Description Prd (mm)
  • Page 18 Maglink LX User Manual | Manual update 7.1.2.4 Tank detail/Delivery List/Losses The following picture shows an example of the "Delivery list" page (accessed by clicking the icon the left): White lines are related to Delivery, the red lines are related to losses. The following table lists the page elements, as a function of data and time: Element Description...
  • Page 19 Maglink LX User Manual | Manual update 7.1.2.6 Tank details/Reconciliation The following picture shows an example of the "Reconciliation" page (accessed by clicking the icon the left): The following table lists the page elements: Element Description Time Reference time Vol. Initial Initial time volume Vol.
  • Page 20 Maglink LX User Manual | Manual update 7.1.2.7 Tank Details/Shift Report The following picture shows an example of the "Shift Report" page (accessed by clicking the icon the left): The following table lists the page elements: Element Description Incremental shift number Start Start of shift End of shift...
  • Page 21 Maglink LX User Manual | Manual update 7.1.2.8 Tank Details/DVD Details The following picture shows an example of the "DVD Details" page (accessed by clicking the icon the left): The following table lists the page elements: Element Description The following data is displayed: •...
  • Page 22: Location

    Maglink LX User Manual | Manual update 7.1.3 Tank detail percentage The following image shows an example of the "Status": The number of the tank, the name of the tank, its state and the percentage filling of the tank are reported on the page.
  • Page 23: List Of On/Off Sensors

    Maglink LX User Manual | Manual update 7.1.4 List of ON/OFF sensors The following image shows an example of the "List of ON/OFF sensors": The following table lists the page elements: Element Description Sensor type: • 1 – Internal sensor (up to 6) Number •...
  • Page 24: Alarm Log

    Maglink LX User Manual | Manual update 7.1.5 Alarm Log The following image shows an example of the "Alarm Log": The following table lists the page elements: Element Description Date - Time Date and time of alarm Tank Tank Number Alarm Tank status Alarm type:...
  • Page 25: Info

    Maglink LX User Manual | Manual update 7.1.6 INFO The following image shows an example of the page "INFO": The following table lists the page elements at the left of the page: Element Description Version Console software version Serial number Unique serial number of the console IP address Unique IP address of the console...
  • Page 26 Maglink LX User Manual | Manual update The following table lists the page buttons: Button Description Print inventory Prints the current inventory report Exporting the information log to a USB devices (The button appears if a USB device Export Log is connected) Download the latest software from the USB device (The button appears if a USB Download from USB...
  • Page 27: Manual Update Procedure

    Maglink LX User Manual | Manual update ANUAL UPDATE PROCEDURE The console can be periodically updated by downloading the latest version of the application files from the site www.startitaliana.it (Section MagLink-LX, ZIP format). The following table shows the necessary procedure steps for updating such data: Step Description Provide a USB device...
  • Page 28: Print Inventory

    Maglink LX User Manual | Print inventory RINT INVENTORY The console can be connected to a Sprint serial printer through the RS232 serial port. Once connected, the user can print the current inventory . The following table shows the necessary procedure steps for printing stock: Step Description Connect the Sprint printer to the console RS232 port using a CX cable...
  • Page 29: Shift Report

    Maglink LX User Manual | Shift Report 10 S HIFT EPORT The console can produce a Shift Report. The shift report can be manually triggered or it can be automatically configured. You can configure multiple daily Shift reports. The following table shows the necessary procedure steps for managing such Shift Reports: Step Description Press the "INFO"...
  • Page 30: Maintenance

    Maglink LX User Manual | Maintenance 11 M AINTENANCE Maintenance activities are defined and managed in accordance with EN 60079-17. IMPORTANT: Maintenance must be carried out only by authorized personnel or by the manufacturer IMPORTANT: Maintenance of electrical connections must be performed only by personnel trained and experienced (Refer to the installation manual of the console) IMPORTANT: The opening of the console can compromise the level of safety of the equipment, maintenance operations must only be performed by authorized personnel or by...
  • Page 31: Support

    Maglink LX User Manual | Support 12 S UPPORT If you need direct assistance from a Start Italiana S.r.l. technician the best solution is to connect the console to the Internet .The console requires public IP address and port 80 opened. All data of interest to the console can then be viewed directly by Start Italiana S.r.l.
  • Page 32: Safety Instructions

    Maglink LX User Manual | Safety directives 13 S AFETY INSTRUCTIONS Safety instructions are annexed to this document. Rev. 9, 04-2016 Page 32 of 40...
  • Page 33: Certification

    Maglink LX User Manual | Certification 14 C ERTIFICATION Rev. 9, 04-2016 Page 33 of 40...
  • Page 34 Maglink LX User Manual | Certification Rev. 9, 04-2016 Page 34 of 40...
  • Page 35 Maglink LX User Manual | Certification Rev. 9, 04-2016 Page 35 of 40...
  • Page 36 Maglink LX User Manual | Certification Rev. 9, 04-2016 Page 36 of 40...
  • Page 37: Notification

    Maglink LX User Manual | Notification 15 N OTIFICATION Rev. 9, 04-2016 Page 37 of 40...
  • Page 38: Revisions

    Revisions Maglink LX User Manual | 16 R EVISIONS The following table lists the revisions to the document: Firmware Revision No. Date Description Revision March 2014 Issue 1.0.0 February 2015 Added com ports inversion 2.0.0 March 2015 Addition of an application description section 2.0.0 April 2015 Addition of a certification and notifications section...
  • Page 40 Manufacturer_name START ITALIANA S.r.l. Via Pola 6 20813 Bovisio Masciago (MB) Italia Tel. +39 0362 1581465 Fax +39 0362 1581464 assistenza@startitaliana.it www.startitaliana.it...
