Ss Brewtech Jacketed Unitank Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
ENGINEERING BETTER BEER
Jacketed Unitank

Advertisement

loading
Need help?

Need help?

Do you have a question about the Jacketed Unitank and is the answer not in the manual?

Questions and answers

Related Manuals for Ss Brewtech Jacketed Unitank

Summary of Contents for Ss Brewtech Jacketed Unitank

  • Page 1 ENGINEERING BETTER BEER Jacketed Unitank...
  • Page 2 IN THE CRATE JACKETED UNITANK (1) 8” or 12” TC Lid Cap w/ 3” (1) 8” or 12” TC Lid Clamp (1) 8” or 12” Lid Gasket Combination Dry-hop, PRV, and CIP Port (Spray Ball sold separately) (1) DIN Nut Rotatable Racking (1) 3”...
  • Page 3 TANK FEATURES & ASSEMBLY TC LID CAP W/ COMBINED 3” DRY HOP/ PRV/CIP PORT 3” TC Pressure Release Valve (PRV) 3” TC Gasket 3” TC Clamp TC Lid 8” or 12” TC Lid Gasket 8” or 12” TC Lid Clamp 8”...
  • Page 4 TANK FEATURES & ASSEMBLY 1.5” TC BLOW-OFF ARM W/ BUTTERFLY VALVE 1.5” TC Blow-Off Arm 1.5” TC Gasket 1.5” TC Clamp Clamp Butterfly Valve Page 4...
  • Page 5 TANK FEATURES & ASSEMBLY 1.5” TC CARBONATION STONE WITH 3/8” BALL-VALVE 1.5” TC Carbstone w/ 3/8” Ball-Valve 1.5” TC Gasket 1.5” TC Clamp 1.5” TC ANALOG TEMPERATURE GAUGE 1.5” TC Analog Temperature Gauge 1.5” TC Gasket 1.5” TC Clamp Page 5...
  • Page 6 TANK FEATURES & ASSEMBLY 1.5” TC PERLICK SAMPLE VALVE 1.5” TC Perlick Style Sampling Valve 1.5” TC Gasket 1.5” TC Clamp 1.5” TC THERMOPROBE 1.5” TC Thermowell / Probe 1.5” TC Gasket 1.5” TC Clamp Page 6...
  • Page 7 TANK FEATURES & ASSEMBLY ROTATABLE RACKING ARM 1.5” TC Butterfly Valve 1.5” TC Gasket 1.5” TC Clamp DIN Nut Rotatable Racking Arm w/ 1.5” TC Port 1.5” TC BUTTERFLY DUMP VALVE 1.5” TC Butterfly Valve 1.5” TC Gasket 1.5” TC Clamp Elbow Page 7...
  • Page 8 TANK FEATURES & ASSEMBLY STAINLESS STEEL SHELF & FEET Stainless Steel Shelf Threaded Stem Adjustable Feet Page 8...
  • Page 9 TANK FEATURES & ASSEMBLY 1/2” NPT GLYCOL RETURN LINE PORT 1/2” NPT Glycol Return Line Port 1/2” NPT GLYCOL SUPPLY LINE PORT 1/2” NPT Glycol Supply Line Port Page 9...

  • Page 10: Wiring Instructions

    PT 100 THERMOPROBE Screwdriver Insert Slot WIRING INSTRUCTIONS 1. Disconnect/unplug units from any power outlets. 2. Remove screw and unplug receptacle from the PT100 Thermoprobe. 3. Use the flat head screwdriver slot to remove face of receptacle. 4. Feed temperature sensor wires through receptacle. Screw 1.5”...

  • Page 11: Prior To Use

    PRIOR TO USE WARNING It is very important that once the vessel is empty and ready to be cleaned that the residual pressure buildup is released from the vessel before removing the lid cap. To perform this step, open the sampling valve, and allow all pressure to bleed off before loosening any of the TC connections on the vessel.
  • Page 12 PRIOR TO USE PASSIVATION Contrary to popular belief, stainless steel is not truly stainless. It is corrosion-resistant, but not corrosion- proof. The ability of stainless steel to resist corrosion is dependent upon its protective oxide layer. This layer must be periodically re-introduced by cleaning the stainless steel to remove any iron and surface contaminants and allowing the surface to react with oxygen in the atmosphere.
  • Page 13 CLEANING YOUR UNITANK CLEANING AND SANITIZING: CIP In simplest form, the basic principle of a vessel CIP (clean in place) is to recirculate a mixture of water and cleaning agent from the bottom of the vessel up through the spray ball of the vessel using an external pump in a continuous loop.
  • Page 14 SsBrewtech.com REV 02112019...
