Force 10 Traverse 2000 Hardware Manual

Hide thumbs Also See for Traverse 2000:
Table of Contents

Advertisement

Quick Links

Download this manual
Traverse Hardware Guide
TR4.0.x/TN5.0.x
June 2011
R

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Traverse 2000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Force 10 Traverse 2000

Summary of Contents for Force 10 Traverse 2000

  • Page 1 Traverse Hardware Guide TR4.0.x/TN5.0.x June 2011...
  • Page 2 Traverse, TraverseEdge, TraversePacketEdge, TransAccess, are registered trademarks of Force10 Networks, Inc. Force10, the Force10 logo, and TransNav are trademarks of Force10 Networks, Inc. or its affiliates in the United States and other countries and are protected by U.S. and international copyright laws. All other brand and product names are registered trademarks or trademarks of their respective holders.

  • Page 3: Table Of Contents

    Traverse 2000 Specifications ........
  • Page 4 Chapter 8 Gigabit Ethernet-only Cards (Dual-slot) 1-Port 10GbE Card ..........2 10-Port GbE Card .

  • Page 5: Traverse 2000 Platform

    This platform also offers a high-capacity wideband digital cross-connect matrix scales from 96 to 384 protected STS/STM equivalents (2688 to 10,752 VT1.5s). Note: If using a Traverse 2000 in a SONET-only DCS-768 matrix shelf configuration, the platform supports 768 protected STS equivalents (21,504 VT1.5s).
  • Page 6 Front View and VT/TU 5G Switch cards, and two slots are dedicated to General Control Module (GCM) cards. The Traverse 2000 shelf is configured by populating the system with GCMs (control cards), service interface modules (SIMs or cards), and VT/TU 5G Switch cards.
  • Page 7 Figure 3 Rear View of Traverse 2000 Slot Numbers. There are 20 slots in each Traverse 2000 shelf. For all nodes except the DCS-768, the slot usage is: •...
  • Page 8 For information on ECMs, see the Traverse Cabling and Cabling Specifications Guide, Chapter 2—“ECM Interface Specifications.” Traverse 2000 This table lists the specifications for the Traverse 2000 platform. Specifications Table 1 Traverse 2000 Specifications Parameter Specification Number of shelves per 7-foot rack...
  • Page 9 Table 1 Traverse 2000 Specifications (continued) Parameter Specification Supported service interface module • 28-port DS1 cards • 12-port DS3/E3/EC-1 Clear Channel • 24-port DS3/E3/EC-1 Clear Channel • 12-port DS3/EC-1 Transmux • 24-port Universal Transmux • 48-port Universal Transmux • 21-port E1 •...
  • Page 10 Traverse Hardware Guide, Release TR4.0.x...

  • Page 11: Traverse 1600 Platform

    Chapter 2 Traverse 1600 Platform Introduction The Traverse 1600 is a 16-slot, 19-inch rack-mountable shelf optimized for access and metro/IOF ring switching, as well as transport applications. The Traverse 1600 is also scalable to 75 Gbps STS/STM switching capacity with high-density DS1/E1 to OC-192/STM-64, 10/100, and Gigabit Ethernet (GbE) service flexibility.
  • Page 12 Traverse 1600 Fourteen slots accommodate service interface and VT/TU 5G Switch cards, and two Front View slots are dedicated to general control module cards (control cards). The Traverse 1600 shelf is configured by populating the system with control cards, SIMs, and VT/TU 5G Switch cards.
  • Page 13 Traverse 1600 The Traverse system’s fully-meshed passive backplane provides full interconnection Rear View for cards and external interfaces such as power, timing, alarm, management, and the fan tray card. All power and interface connections are terminated from the rear of the Traverse shelf, except for the serial interface and the Ethernet port (for local craft access), which are on the front faceplate of the control card.
  • Page 14 Timing Interface The backplane provides primary and secondary T1/E1 and CC2M (Composite Clock—64 kHz and 2 MHz) input and output timing interfaces, and primary and secondary BITS input timing interfaces. These timing interfaces are routed to both control cards, which distribute system timing references to all cards. System and Environmental Alarms Interface Support is provided for the full set of system alarm outputs, sixteen environmental alarm inputs, a fail-safe alarm, and a remote alarm cut-off.
  • Page 15 Quality of Service Traverse IP quality of service (IP QoS) provides filters and priority queueing with statistics for all the traffic going over the Traverse DCC network. Priority is given to traffic originating from the Traverse network and the TransNav server. An access control list (ACL) manages IP hosts and networks for IP forwarding action to allow or block traffic.
  • Page 16 Traverse 1600 This table lists the specifications for the Traverse 1600 platform. Specifications Table 5 Traverse 1600 Specifications Parameter Specification Number of shelves per 7-foot rack System configuration 16-slot shelf: • 2 slots for redundant control cards • 14 slots for universal service interface module cards Maximum switching capacity 75 Gbps Power consumption...

  • Page 17: Traverse 600 Platform

    Chapter 3 Traverse 600 Platform Introduction The Traverse 600 system is physically smaller than the Traverse 1600 and Traverse 2000 systems, and is most efficiently used by service providers and carriers that do not require the capacity of a full 16-slot or 20-slot shelf. •...
  • Page 18 Traverse 600 The Traverse system’s fully-meshed passive backplane provides full interconnection Rear View for cards and external interfaces such as power, timing, alarm, management, and the fan tray card. All power and interface connections are terminated from the rear of the Traverse shelf, except for the serial interface and the Ethernet port (for local craft access), which are on the front faceplate of the control card.
  • Page 19 telemetry inputs and outputs are supported by the optional Environmental Alarm Card located on the main backplane, which provides additional system-management functions to accommodate customer-defined alarm input/output requirements. The card is field replaceable and can be replaced without disconnecting the alarm wiring. Modem Interface The RS-232C modem interface uses a vertical 8-pin RJ-45 connector that is configured as a data terminal equipment (DTE) port for connection to an external modem,...
  • Page 20 helps machines on one subnet reach remote subnets without configuring routing or a default gateway. Power Terminals The Traverse receives redundant -48 VDC feeds from the PDAP (PDAP-4S, PDAP-15A, or legacy PDAP-4S) or third-party power distribution unit and distributes these to each slot. Each slot has access to both A and B -48 VDC power feeds. Electrical Connector Cards for Electrical Interfaces The electrical connector cards (ECMs) enable copper and coax network interface cabling using industry-standard cables and connectors.
  • Page 21 Traverse 600 This table lists the specifications for the Traverse 600 platform. Specifications Table 6 Traverse 600 Specifications Parameter Specification System configuration 6-slot shelf: 2 slots for redundant control cards 4 slots for universal service interface module cards Maximum switching capacity 15 Gbps Power consumption 150 to 250 Watts, typical (max.
  • Page 22 Traverse Hardware Guide, Release TR4.0.x...

  • Page 23: Fan Assemblies

    The System increases the speed of the other fans • The control card raises an alarm in the GUI Traverse fan assembly differences are as follows: • Traverse 2000 and Traverse 1600 Front Inlet Fan Assemblies • Traverse 600 Fan Assembly Traverse Hardware Guide, Release TR4.0.x...
  • Page 24 GCM and service cards in the shelf. The Traverse 1600 Inlet Fan fan assembly has five fans. The Traverse 2000 fan assembly has six fans. The fans draw Assemblies in cooling air from the front and push the air upward through the perforated shelf. The air ramp above the shelf directs the heated air out through the rear of the shelf.
  • Page 25 Traverse 600 One fan assembly is integrated within each Traverse 600 shelf. Fan Assembly The Traverse 600 fan assembly (fan card with integral shelf fan tray) cools the GCM and service cards in the shelf. The Traverse 600 fan assembly has six fans and can force up to 200 cubic feet per minute of cooling air.
  • Page 26 Fan Assembly This table lists the specifications of the fan assembly for each shelf. Specifications Table 7 Fan Tray and Fan Module Specifications Specification Parameter Traverse 2000 Traverse 1600 Traverse 600 Number of fans Power (nominal) 30 W 30 W...

  • Page 27: Power Distribution And Alarm Panels

    Important: Carefully plan your power supply capacity. See the Planning and Engineering Guide, Chapter 1—“Traverse Equipment Specifications,” Power Consumption. This chapter includes the following topics: • PDAP-4S—for Traverse 1600 and Traverse 2000 systems • PDAP-15A—for Traverse 600 systems • PDAP Specifications...

  • Page 28: Pdap-4S

    PDAP-4S The PDAP-4S provides redundant, field replaceable 40 amp TPA fuses for up to four Traverse shelves and GMT fuses (from 0.25 amps to 15 amps per fuse) for up to five pieces of auxiliary equipment. The PDAP’s field replaceable fuses are accessible without having to remove the front panel.

  • Page 29: Pdap-15A

    PDAP-15A The PDAP-15A provides GMT fuses (from 0.25 amps to 15 amps per fuse) for up to ten pieces of auxiliary equipment. The PDAP’s field replaceable fuses are accessible without having to remove the front panel. Force10 recommends using a 3 amp fuse per power feeder for the TE-100 and a 5 amp fuse per power feeder for the Traverse 600.
  • Page 30 Traverse Hardware Guide, Release TR4.0.x...

  • Page 31: General Control Module (Gcm) Cards

    Chapter 6 General Control Module (GCM) Cards Introduction The General Control Module (GCM) card controls and manages all Traverse cards and services, and the fan tray. This chapter contains the following topics: • GCM Card Description • GCM Card Types •...
  • Page 32 GCM Card The GCM controls and manages all Traverse shelf cards and services, and the fan tray. Description The GCM can operate by itself or with a second GCM for redundancy. Redundant GCMs provide the following key functions: • System initialization •...
  • Page 33 faceplate of the GCM also supports hardware/firmware diagnostics and configuration (IP address, card, and interface). The GCM’s also have an Ethernet interface (RJ-45) with auto-sensing capability located on the front faceplate, typically for temporary connection of a technician’s PC laptop. One 10/100 Ethernet port is located on the front of the GCM for local technician access.
  • Page 34 PDAP-4S, visual and audible alarms to third-party fuse and alarm panels, or the gateway Traverse node. The GCM can also send and receive additional programmable environmental alarms. An Environmental Alarm Module (EAM), located on the back of the shelf, provides additional environmental alarm input and output capability.
  • Page 35 GCM Card The Traverse supports the following GCM card types: Types Table 7 GCM Card Types Model Number Card Description • TRA-GCM-U • General Control Module card • TRA-GCM-VCX • General Control Module card with VTX/VCX switch fabric • TRA-GCM-1P-OC12-IR1 •...
  • Page 36 Table 7 GCM Card Types Model Number Card Description • TRA-GCM-1P-OC48-CW1590-80K-VCX • GCM with 1-port OC-48/STM-16 Optics-CWDM-LR2/LH2, 1591 nm; plus VTX/VCX switch • TRA-GCM-1P-OC48-CW1610-80K-VCX • GCM with 1-port OC-48/STM-16 Optics-CWDM-LR2/LH2, 1611 nm; plus VTX/VCX switch • TRA-GCM-1P-OC48DW[–60]19-100K-A • GCM with 1-port OC-48/STM-16 Optics-DWDM-ELR/LH, CH[19–60], [191.9–196.0] GHz •...

  • Page 37: Card Specifications

    Card Specifications for all GCM types are outlined in the table below. Specifications Table 8 GCM Specifications Parameter Specification Maximum number per shelf 2 (all platforms) Technician Serial interface RS-232C DB-9 (DCE) Technician LAN interface 10/100BaseT Ethernet RJ-45 Backplane DCN Ethernet interface 10/100BaseT Ethernet RJ-45 (on rear of shelf and shared by active and standby GCM’s) Backplane RS-232 interface...
  • Page 38 Table 8 GCM Specifications (continued) Parameter Specification Weight 2.0 lbs 0.9072 kg Industry Standards ITU-T G.703 (Table 7 and Figure 15), G.704, G.707, G.781 ANSI T1.105 GR-253-CORE, GR-1244-CORE Jitter & Wander: ITU-T G.813 (option 1 specification) Frame SSM: ITU-T G.704, Section 2.3.4, Table 5C and 5D Frame: HDB3, Framed “all 1”...

  • Page 39: Next-Generation Ethernet Cards

    Chapter 7 Next-Generation Ethernet Cards Introduction Force10 Networks offers several versions of its single-slot next-generation Ethernet (NGE) service interface cards with optical and electrical Gigabit Ethernet (GbE) and electrical Fast Ethernet (FE) ports. This chapter includes the following topics: •...
  • Page 40 Virtual Concatenation NGE cards support HO/LO VCAT and provide up to a maximum of 64 Ethernet over SDH or SONET (EOS) trunks. It allows optical bandwidth to be tuned to the smallest increments in SONET and SDH with the ability to provide bandwidth on demand, enabling maximum bandwidth efficiency.
  • Page 41 NGE/NGE Plus The Traverse supports these card types, as shown in the following two tables: Card Types Table 8 NGE Card Types Model Number Card Description TRA-4GELX-16TX-HLVC 4-port GbE LX plus 16-port 10/100BaseTX TRA-4GESX-16TX-HLVC 4-port GbE SX plus 16-port 10/100BaseTX TRA-4GE47-53-16TX-HLVC 4-port GbE CWDM (40 km) 1471/1491/1511/1531 nm plus 16-port 10/100BaseTX...
  • Page 42 Table 10 NGE / NGE Plus Card Specifications Parameter NGE Plus Maximum cards per shelf Traverse 2000: 16; Traverse 1600: 12; Traverse 600: 4 Equipment protection 1:1 Ethernet electrical and optical equipment protection Physical interface types Optical fiber (GbE LX, SX, and CWDM);...
  • Page 43 Table 10 NGE / NGE Plus Card Specifications (continued) Parameter NGE Plus Ethernet Services Ethernet transport Ethernet over SONET/SDH (EOS) using GFP encapsulation, HO/LO VCAT, and LCAS Transport diagnostics GFP Link Integrity Load balancing IEEE 802.3 Link Aggregation Groups (LAGs) Spanning tree protocol RSTP and V-RSTP (separate RSTP instances per EOS) Service protection...
  • Page 44 Assumes full-duplex capacity (2.5 Gbps to the backplane and external ports), as well as a mix of frame sizes typical of Internet traffic. The actual switching capacity is dependent on the mix of Ethernet frame sizes. See the TransNav Management System Provisioning Guide, Chapter 52—“Ethernet Traffic Management.” The full 5 Gbps switching capacity capability is limited to high order switching.
  • Page 45 NGE Gigabit NGE and NGE Plus cards with GbE ports are based on IEEE 802.3 Ethernet Ethernet Ports transmission standards and operate in full line rate. These cards integrate a full IEEE 802.1D Layer 2 switch and Ethernet over SONET/SDH (EOS) mapper. They can aggregate and transport Ethernet frames in a SONET/SDH contiguous concatenation (CCAT) or virtual concatenation (VCAT) payload.
  • Page 46 Force10 recommends customers take actual fiber readings, as these values are based on standards qualification. For valid wavelengths, see GbE CWDM Wavelengths. These values account for the connector loss from connection to the optical interface and the worst case optical path penalty. GbE CWDM The following NGE cards offer the ITU-T G.694.2 CWDM optical transceivers on the Wavelengths...
  • Page 47 Specifications This table lists the specifications for the electrical fast Ethernet (FE) port interface: Table 13 Fast Ethernet (10/100BaseTX) Card Specifications Parameter Specification (FE TX) Port data rate 10 or 100 Mbps Connector Telco 50 to RJ-45 (ECM required) Media type 2 pairs, Twisted Pair Category 5 UTP 420 ft Maximum reach...
  • Page 48 Traverse Hardware Guide, Release TR4.0.x...

  • Page 49: Gigabit Ethernet-Only Cards (Dual-Slot)

    Chapter 8 Gigabit Ethernet-only Cards (Dual-slot) Introduction Force10 Networks offers a variety of dual-slot Gigabit Ethernet-only (GbE) service interface cards to support higher bandwidth and port density Ethernet applications and services: bandwidth-intensive Ethernet Private Lines (EPL), Multipoint Layer 2 Virtual Private Networks (VPNs), Internet Protocol Television (IPTV), and other IP-centric video applications.
  • Page 50 Use the dual-slot, hot-swappable 10GbE card in any combination of the available interface slots of the Traverse 2000 or Traverse 1600 shelves. Physical access to the optical interface is through an MPX connector with singlemode fiber on the back of the shelf.
  • Page 51 10GBaseZR Parameter (TRA-1P-10GE-LR-SMF) (TRA-1P-10GE-ER-SMF) (TRA-1P-10GE-ZR-SMF) Maximum cards per shelf Traverse 2000: 9; Traverse 1600: 7 Equipment protection 1:1 Ethernet optical equipment protection (requires an optical splitter/coupler) Physical interface types Optical fiber (10GbE LR, ER, and ZR) Service interface types UNI - 802.1Q supporting tagged, untagged, and priority tagged Ethernet frames NNI - 802.1ad / QinQ supporting double tagged Ethernet frames...
  • Page 52 Table 10 10GbE Card Specifications (continued) 10GBaseLR 10GBaseER 10GBaseZR Parameter (TRA-1P-10GE-LR-SMF) (TRA-1P-10GE-ER-SMF) (TRA-1P-10GE-ZR-SMF) Ethernet Services Ethernet transport Ethernet over SONET/SDH (EOS) using GFP encapsulation, HO VCAT, and LCAS Transport diagnostics GFP Link Integrity Load balancing IEEE 802.3 Link Aggregation Groups (LAGs) Spanning tree protocol RSTP and V-RSTP (separate RSTP instances per EOS) Service types...
  • Page 53 Assumes full-duplex capacity (10 Gbps to the backplane and external ports), as well as a mix of frame sizes typical of Internet traffic. The actual switching capacity is dependent on the mix of Ethernet frame sizes. See the TransNav Management System Provisioning Guide, Chapter 52—“Ethernet Traffic Management.” For installation specifications, see the Traverse Cabling and Cabling Specifications Guide, Chapter 1—“Fiber Optic Interface Cabling Specifications.”.
  • Page 54 10-Port GbE The 10-port GbE (GbE-10) card supports high density Ethernet switching and provides Card a comprehensive set of features to enable the Traverse platform to support evolution to an end-to-end Carrier Ethernet transport Ethernet infrastructure. Each card integrates 20 Gbps of non-blocking L2 Ethernet switching into the Traverse shelf. Advanced IEEE 802.ad Provider Bridging capabilities include support for 802.1Q C-VLANs and S-VLANs (Q-in-Q) with granular traffic shaping to support differentiated service classes and guaranteed SLAs.
  • Page 55 GbE-10 Gigabit Ethernet Ports. Table 14 10-port GbE Card Specifications GbE-10 Parameter (TRA-10P-1GE-SFP) Maximum cards per Traverse 2000: 8; Traverse 1600: 6 shelf Equipment 1:1 Ethernet optical equipment protection; requires an optical splitter/coupler protection Physical interface Optical fiber (GbE SX, LX, and ZX)
  • Page 56 Table 14 10-port GbE Card Specifications (continued) GbE-10 Parameter (TRA-10P-1GE-SFP) Transport GFP Link Integrity diagnostics Load balancing IEEE 802.3 Link Aggregation Groups (LAGs) Spanning tree RSTP and V-RSTP (separate RSTP instances per EOS) protocol Service types MEF E-Line: Ethernet private line (EPL), Ethernet virtual private line (EVPL) MEF E-LAN: Ethernet bridge (multipoint-to-multipoint) Aggregate bridge (point-to-multipoint) Traffic Management...

  • Page 57: Gbe-10 Gigabit Ethernet Ports

    Table 14 10-port GbE Card Specifications (continued) GbE-10 Parameter (TRA-10P-1GE-SFP) Industry standards ITU -T Rec: G.7041/Y.1303 (GFP) and G.7042 (LCAS) Telcordia GR-1377-CORE IEEE: 802.3ab/z, 802.1ad/1D/1p/1Q/p MEF 9 technical specification Assumes full-duplex capacity (10 Gbps to the backplane and external ports), as well as a mix of frame sizes typical of Internet traffic.
  • Page 58 Specifications This table lists the specifications for the optical and electrical GbE port interfaces: Table 15 GbE Port Interface Specifications Specification Parameter GbE SX GbE LX GbE ZX GbE TX (SFP-1000BASE-SX850) (SFP-1000BASE-LX1330) (SFP-1000BASE-ZX1550) (SFP-1000BASE-TX) Port data rate 1 Gbps Connector SFP LC RJ-45 (SCM required)

  • Page 59: Comparing Gigabit Ethernet Payload Capacity

    Comparing Different concatenation methods on the Gigabit Ethernet (10GbE and GBE-10) cards Gigabit result in different throughput for payload traffic. See the following table for a basic Ethernet summary of the differences. Payload Table 16 Comparing Gigabit Ethernet Payload Capacity Capacity Payload Capacity SONET...
  • Page 60 Traverse Hardware Guide, Release TR4.0.x...

  • Page 61: Ethernet Over Pdh Cards

    Chapter 9 Ethernet Over PDH Cards Introduction Force10 Networks offers several versions of its single-slot Ethernet over PDH (Plesiochronous Digital Hierarchy) service interface cards with optical and electrical Gigabit Ethernet (GbE) and electrical Fast Ethernet (FE) ports. The EoPDH Service Interface Modules (SIMs) for the Traverse® multiservice switching and transport platform position Force10 with the industry’s leading solution...
  • Page 62 For FE interface specifications, see EoPDH Fast Ethernet Ports. Table 11 EoPDH Card Specifications Parameter EoPDH Maximum cards per shelf Traverse 2000: 16; Traverse 1600: 12; Traverse 600: 4 Equipment protection 1:1 Ethernet electrical and optical equipment protection Traverse Hardware Guide, Release TR4.0.x...
  • Page 63 Table 11 EoPDH Card Specifications (continued) Parameter EoPDH Physical interface types Optical fiber (GbE LX and SX); Electrical twisted pair/copper (GbE TX and 10/100BaseTX) Service interface types UNI - 802.1Q supporting tagged, untagged, and priority tagged Ethernet frames NNI - 802.1ad / QinQ supporting double tagged Ethernet frames Connector MPX for optical;...
  • Page 64 Table 11 EoPDH Card Specifications (continued) Parameter EoPDH Service types MEF E-Line: Ethernet private line (EPL), Ethernet virtual private line (EVPL) MEF E-LAN: Ethernet bridge (multipoint-to-multipoint) Aggregate bridge (point-to-multipoint) Traffic Management EVC types Point-to-Point, Multipoint-to-Multipoint and Point-to-Multipoint Number of EVCs per EoS 4093 EVCs per EoS, 64 EoSs per card C-VLAN/CoS preservation Full preservation of C-VLAN IDs and C-VLAN CoS (IEEE...
  • Page 65 Table 11 EoPDH Card Specifications (continued) Parameter EoPDH Industry standards ITU -T Rec: G.707, G.7041/Y.1303 (GFP), G.7042 (LCAS), G.7043, and G.8040 Telcordia GR-253-CORE, GR-1377-CORE, GR-63-CORE, GR-1089-CORE IEEE: 802.3ab/x(PAUSE)/z, 802.1D/Q VLAN MEF 9 (EPL, EVPL, E-LAN) and MEF 14 (QoS/TM) technical specifications Assumes full-duplex capacity (2.5 Gbps to the backplane and external ports), as well as a mix of frame sizes typical of Internet traffic.
  • Page 66 Table 12 GbE Port Interface Specifications (continued) Specification Parameter GbE SX GbE LX GbE TX Objective 0.34 mi 6.21 mi 420 ft 1, 2 Distance 0.55 km 10 km 128 m Nominal 850 nm 1310 nm wavelength Transmitter –10.5 to –4 dBm –10 to –3 dBm output power Receiver level...
  • Page 67 Specifications This table lists the specifications for the electrical fast Ethernet (FE) port interface: Table 13 Fast Ethernet (10/100BaseTX) Card Specifications Parameter Specification (FE TX) Port data rate 10 or 100 Mbps Connector Telco 50 to RJ-45 (ECM required) Media type 2 pairs, Twisted Pair Category 5 UTP 420 ft Maximum reach...
  • Page 68 Traverse Hardware Guide, Release TR4.0.x...

  • Page 69: Sonet/Sdh Cards

    Chapter 10 SONET/SDH Cards Introduction The SONET/SDH service interface module (SIM) cards support non-blocking cross-connects, protection switching, and alarm and performance monitoring. Each of the cards provides a physical connection, in accordance with transmission standards and functions. The topics in this chapter describe and give the specifications for the following service interface cards: •...
  • Page 70 Use the single-slot, hot-swappable OC-3/STM-1 card in any of the available optical interface slots of the Traverse 2000, Traverse 1600, or Traverse 600 shelves. Physical access to the optical interface is through an MPX connector on the back of the shelf.
  • Page 71 Table 12 OC-3 IR1/STM-1 SH1 Card Specifications (continued) Specifications Specifications Parameter IR1 / SH1 LR2/LH2 (S-1.1) (L-1.2) Transmitter output -16 to -8 dBm -6 to 0 dBm power Optical Monitoring Maximum RMS width 7.7 nm Minimum extinction 10 dB ratio Receiver signal level -28 to -7 dBm -32 to -10 dBm...
  • Page 72 Use the single-slot, hot-swappable OC-12/STM-4 card in any of the available optical interface slots of the Traverse 2000, Traverse 1600, or Traverse 600 shelves. Physical access to the optical interface is through an MPX connector on the back of the shelf.
  • Page 73 Table 14 4-Port OC-12/STM-4 Card Specifications (continued) Specification Parameter IR1 / SH1 LR2 / LH2 (S-4.1) (L-4.2) Maximum RMS width 2.5 nm Minimum extinction ratio 8.2 dB 10 dB Receiver signal level -27 to -7 dBm -26 to -8 dBm -1 PRBS, BER=10 Guaranteed link budget 11 dB...
  • Page 74 SONET/SDH services. Use the single-slot, hot-swappable OC-48/STM-16 card in any available optical interface slot of the Traverse 2000, Traverse 1600, or Traverse 600 shelf. Physical access to the optical interface is through an MPX connector on the back of the shelf.
  • Page 75 (WL-16.2) (I-16) (S-16.1) (L-16.1) (L-16.2) (L-16.2) CWDM DWDM Maximum interfaces per Traverse 2000: 20; Traverse 1600: 16; Traverse 600: 6 shelf Port data rate 2.488 Gbps Optical line coding Binary Non-Return-to-Zero Line format ITU -T Rec. G.707 SONET/SDH ANSI T1.105-1995...
  • Page 76 Table 16 OC-48/STM-16 Card Specifications (continued) LR2 / ELR / SR1 / IR1 / LR1 / LR2 / VR2 / Parameter (L-16.2) (WL-16.2) (I-16) (S-16.1) (L-16.1) (L-16.2) (L-16.2) CWDM DWDM Nominal wavelength 8 ITU 42 ITU (typical) 1310 nm 1310 nm 1550 nm CWDM DWDM...
  • Page 77 Use the dual-slot, hot-swappable OC-48 card in any available optical interface slot of the new Traverse 2000 shelf in a DCS-768 matrix configuration. Physical access to the optical interface is on the back of the shelf. Configure each card to process SDH or SONET modes through the user interface.
  • Page 78 SR1 / IR1 / LR1 / LR2 / LH2 Parameter (L-16.2) (I-16) (S-16.1) (L-16.1) Maximum interfaces per Traverse 2000: 20 shelf Port data rate 2.488 Gbps Optical line coding Binary Non-Return-to-Zero Line format ANSI T1.105-1995 GR-253-CORE ITU -T Rec. G.707 SONET...
  • Page 79 Table 20 8-port OC-48 Card Specifications (continued) SR1 / IR1 / LR1 / LR2 / LH2 Parameter (L-16.2) (I-16) (S-16.1) (L-16.1) Regulatory Standards NEBS: GR-63-CORE, GR-1089-CORE Safety: UL60950, EN 60950, IEC 60950, CSA C2.22 No. 60950 Eye Safety: Class 1 EMI: FCC Part 15, Class A;...
  • Page 80 OC-48 LR / The OC-48 LR/STM-16 LH CWDM cards offer the ITU standard 20 nm spacing STM-16 LH between wavelengths, from 1470 nm to 1610 nm, as seen in the table below: CWDM Table 21 OC-48 LR/STM-16 LH CWDM Wavelengths Wavelengths Typical TX Card...
  • Page 81 OC-48 ELR / This table lists the frequency, wavelengths, and channels of the Traverse STM-16 ELH 1-port OC-48 ELR/STM-16 ELH ITU DWDM cards. ITU DWDM Table 22 OC-48 ELR/STM-16 ELH ITU DWDM Wavelengths Wavelengths Card Frequency Wavelength Channel (THz) (nm) OC-48 ELR/STM-16 ELH 191.9 191.9 1562.23...
  • Page 82 4 Cards capabilities of a high-performance SONET/SDH ADM and a non-blocking cross connect in a single card. Supported on the Traverse 2000 and Traverse 1600 platforms, this high-performance card provides a single OC-192/STM-64 port that can be used as a 10 Gbps trunk interface, as well as for the aggregation and grooming of SONET/SDH services.

  • Page 83: Oc-192 Lr / Stm-64 Lh Itu Dwdm Wavelengths

    Table 24 1-Port OC-192/STM-64 Interface Specifications (continued) Parameter SR1 / IR2 / LR2 / LR ITU / ELR ITU / LH ITU LH ITU (S-64.1) (S-64.2) (L-64.2) (WL-64.1) (WL-64.2) Nominal Wavelength 42 ITU 42 ITU DWDM DWDM 1310 nm 1550 nm channels channels 19-60...
  • Page 84 These values account for the connector loss from connection to the optical interface and the worst case optical path penalty. Traverse Hardware Guide, Release TR4.0.x...
  • Page 85 OC-192 LR / This table lists the frequency, wavelengths, and ITU channels of the Traverse 1-port STM-64 LH ITU OC-192 LR/STM-64 LH ITU DWDM FEC cards. DWDM Table 25 OC-192 LR/STM-64 LH ITU DWDM Wavelengths Wavelengths Card Frequency Wavelength Channel (THz) (nm) OC-192 LR/STM-64 LH ITU 191.9...
  • Page 86 OC-192 ELR / This table lists the frequency, wavelengths, and ITU channels of the Traverse 1-port STM-64 LH ITU OC-192 ELR/STM-64 LH ITU DWDM FEC cards. DWDM Table 26 OC-192 ELR2/STM-64 ELH2 ITU DWDM Wavelengths Wavelengths Card Frequency Wavelength Channel (THz) (nm) OC-192 ELR2/STM-64 ELH2 ITU 191.9...

  • Page 87: Electrical Cards

    Chapter 11 Electrical Cards Introduction The information in this chapter describes and gives the specifications for the following electrical service interface modules (SIMs or cards): • 28-Port DS1 Card • 12-Port DS3/E3/EC-1 Clear Channel Card • 24-Port DS3/E3/EC-1 Clear Channel Card •...
  • Page 88 Switch card or VTX/VCX integrated card to use transport bandwidth efficiently. Use the single-slot, hot-swappable DS1 card in any of the available electrical interface slots of the Traverse 2000, Traverse 1600, or Traverse 600 shelves. Physical interfaces are 64-pin Telco connectors on the back of the shelf.
  • Page 89 Table 13 28-port DS1 Card Specifications (continued) Parameter Specification Regulatory Standards NEBS: GR-63-CORE, GR-1089-CORE Safety: UL60950, EN 60950, IEC 60950, CSA C2.22 No. 60950 Eye Safety: Class 1 EMI: FCC Part 15, Class A; EN 300 386; EN 55022, Class A Industry Standards ITU-T G.703 (Table 4 and Figure 10) ANSI T1.102, T1.102...
  • Page 90 DS3 port for DS3 or EC1 through the user interface. Use the single-slot, hot-swappable card in any of the available electrical interface slots of the Traverse 2000, Traverse 1600, or Traverse 600 shelves. Physical I/O interfaces are on the back of the shelf.
  • Page 91 Table 15 12-port DS3/E3/EC-1 Clear Channel Card Specifications (continued) Specification Parameter DS3 Value E3 Value EC-1 Value Regulatory Standards NEBS: GR-63-CORE, GR-1089-CORE Safety: UL60950, EN 60950, IEC 60950, CSA C2.22 No. 60950 Eye Safety: Class 1 EMI: FCC Part 15, Class A; EN 300 386; EN 55022, Class A Industry Standards ITU-T G.703 (Table 6 and Figure 14), G.751, G.832 ANSI T1.105, T1.107...
  • Page 92 Parameter DS3 Value E3 Value EC-1 Value Maximum cards per shelf Traverse 2000: 16; Traverse 1600: 12; Traverse 600: 4 Protection switching 1:N (where N=1, 2) Equipment Protection (switching time <= 50ms) Bit rate 44.736 Mbps 34 Mbps, ±50 bps 51.840 Mbps...
  • Page 93 Table 17 24-port DS3/E3/EC-1 Clear Channel Card Specifications (continued) Specification Parameter DS3 Value E3 Value EC-1 Value Regulatory Standards NEBS: GR-63-CORE, GR-1089-CORE Safety: UL60950, EN 60950, IEC 60950, CSA C2.22 No. 60950 Eye Safety: Class 1 EMI: FCC Part 15, Class A; EN 300 386; EN 55022, Class A Industry Standards ITU-T G.703 (Table 6 and Figure 14), G.751, G.832 ANSI T1.105, T1.107...
  • Page 94 Use the single-slot, 12-port Transmux card in any electrical interface slot of the Traverse 2000, Traverse 1600, or Traverse 600 shelves. In addition to the transmux (DS3-TMX) and optical transmux (STS1-TMX) functionality, any port can be independently configured for DS3 clear channel or EC-1 through the user interface.
  • Page 95 Table 19 12-port DS3/EC-1 Transmux Card Specifications (continued) Specification Parameter DS3 Value EC-1 Value DS3-TMX STS1-TMX Subport VT15/VC11 mapping VT2/VC12 Line code HDB3 B3ZS Termination Unbalanced Coaxial Cable Input impedance 75 ohm Cable length 450 ft (137.2 m) Connector BNC (ECM required) Loopback Terminal and Facility modes...
  • Page 96 (UTMX-24) These channels can contain either DS1 or E1 signals. Use the single-slot, UTMX-24 card in any electrical interface slot of the Traverse 2000, Traverse 1600, or Traverse 600 shelves. In addition to transmux functionality, any port can be individually configured to operate in DS3-CC, EC1, DS3-TMX, and STS1-TMX modes.
  • Page 97 Table 21 24-port DS3/EC-1 Universal Transmux Card Specifications (continued) Specification Parameter EC-1 DS3-TMX STS1-TMX Value Value Line code B3ZS Termination Unbalanced Coaxial Cable Input impedance 75 ohm Cable length 450 ft (137.2 m) Connector Mini-SMB (ECM required) Loopback Terminal and Facility modes Temperature -5°...
  • Page 98 These channels can contain either DS1 or E1 signals. Use the single-slot, 48-port Transmux card in any electrical interface slot of the Traverse 2000, Traverse 1600, or Traverse 600 shelves. In addition to transmux functionality, any physical port can be independently configured for DS3 clear channel or EC-1 through the user interface.
  • Page 99 Table 23 48-port DS3/EC-1 Universal Transmux Card Specifications (continued) Specification Parameter EC-1 DS3-TMX STS1-TMX Value Value DS3 mapping DS1 or E1 Subport Non-sequential or Sequential numbering Subport VT15/VC11 mapping VT2/VC12 Line code B3ZS Termination Unbalanced Coaxial Cable Input impedance 75 ohm Cable length 450 ft (137.2 m) Connector...
  • Page 100 VTX/VCX integrated card to use transport bandwidth efficiently. Use the single-slot, hot-swappable E1 card in any of the available electrical interface slots of the Traverse 2000, Traverse 1600, or Traverse 600 shelves. Physical interfaces are 64-pin Telco connectors on the back of the shelf.
  • Page 101 Table 25 21-port E1 Card Specifications (continued) Parameter Specification Regulatory Standards NEBS: GR-63-CORE, GR-1089-CORE Safety: UL60950, EN 60950, IEC 60950, CSA C2.22 No. 60950 Eye Safety: Class 1 EMI: FCC Part 15, Class A; EN 300 386; EN 55022, Class A Industry Standards ETS 300 417 ITU-T G.707, ITU-T G.783...
  • Page 102 Traverse Hardware Guide, Release TR4.0.x...

  • Page 103: Vt/Vc Switching Cards

    Chapter 12 VT/VC Switching Cards Introduction The Traverse system cross connects at the VT-1.5, VT-2, VC-3, VC-11, and VC-12 levels using one of these cards: • VT/TU 5G Switch Card • VT-HD 40G Switch Card • VTX/VCX Integrated Cards Switching at this level requires less multiplexing and demultiplexing between VC or STS terminations.
  • Page 104 VT/TU 5G The VT/TU 5G Switch card integrates wideband switching and grooming functions Switch Card into the Traverse platform. This card has a termination capacity of 5 Gbps for up to either 32 STS-3c/AU-4 or 96 STS-1/AU-3 equivalents. This single-slot card operates with mated cards in a 1:N equipment protection group. Use this card to cross connect VT/VCs from these protection groups: 1+1 APS, UPSR, BLSR, 1+1 path protection, 1+1 MSP, SNCP, and MS-SPRings.
  • Page 105 Switch Card module, the dual-slot VT-HD Switch card provides a higher density within a single Traverse 2000 shelf configured as a DCS-768 matrix shelf. This card has a termination capacity of 40 Gbps for up to 768 bi-directional STS-1 equivalents.
  • Page 106 VTX/VCX Force10 offers GCM cards with an integrated virtual tributary/container (VT/VC) Integrated cross-connect (VTX/VCX) component, known simply as VCX. The VCX component Cards has a termination capacity of 2.5 Gbps for up to either 16 STS-3c/AU-4 or 48 STS-1/AU-3 equivalents. This component operates with a mated VCX in a 1:1 equipment protection group.
  • Page 107 NDEX data rate, 6 power consumption, 6 Backplane transmux card, 8 BITS input timing interfaces, 4, 2 data rate, 8 data communications network, 4, 3 power consumption, 9 description, 3, 2 DS3/EC-1 clear channel card environmental alarm module, 4, 3 data rate, 4 timing references, input and output, 4, 2 power consumption, 4...
  • Page 108 Laser control optional PDAP description, 3 GbE, 7 Power consumption OC-12/STM-4, 5 Traverse 1600, 6 OC-192/STM-64, 15 Traverse 2000, 4 OC-3/STM-1, 3 Traverse 600, 5 OC-48/STM-16, 8, 10 RJ-45 connector Modem interface, 4, 3 Backplane RS-232 interface, 4, 3 Module, see Card...
  • Page 109 UTMX UTMX-24 card specifications, 10 data rate, 10 power consumption, 11 UTMX-48 card specifications, 12 data rate, 12 power consumption, 13 VT-100 terminal, 4, 3 Traverse Hardware Guide, Release TR4.0.x...
