Perma Pure Baldwin Series Instruction Manual
Heated filter probes general purpose
Hide thumbs
Also See for Baldwin Series:
- User manual (25 pages) ,
- User manual (28 pages) ,
- Instruction manual (44 pages)
Advertisement
P
P
E
R
M
E
R
M
I
NSTRUCTION
HEATED FILTER PROBES
G
P
ENERAL
URPOSE
Model 34C-MONSOL
Perma Pure LLC
1001 New Hampshire Ave
Lakewood, NJ 08701
www.permapure.com
P
P
A
U
R
E
A
U
R
E
M
ANUAL
S
ERIES
Version 4.05
Tel: 732-244-0010
Tel: 800-337-3762
(toll free US)
Fax: 732-244-8140
Email: info@permapure.com
Advertisement
Table of Contents
Related Manuals for Perma Pure Baldwin Series
Summary of Contents for Perma Pure Baldwin Series
- Page 1 NSTRUCTION ANUAL HEATED FILTER PROBES ENERAL URPOSE ERIES Model 34C-MONSOL Version 4.05 Perma Pure LLC Tel: 732-244-0010 1001 New Hampshire Ave Tel: 800-337-3762 (toll free US) Lakewood, NJ 08701 Fax: 732-244-8140 www.permapure.com Email: info@permapure.com...
-
Page 2: Table Of Contents
ABLE OF ONTENTS A: Specifications ......................3 B: Limited Warranty ......................4 C: Principle of Operation ....................5 D: Maintenance ....................... 6 E: Troubleshooting ......................7 F: Spare Parts ......................... 8 Appendix: ........................9 Table of Contents... -
Page 3: A: Specifications
A: S PECIFICATIONS General Specifications Probe 18" Stinger probe, 0.5" dia x .065" wall, 316L SS tubing Calibration Integral calibration on both sides of filter element Heater Temp Control External regulated (standard) Connections 1¼" male pipe nipple mount; ½" male pipe thread adapter Connectors ¼"... -
Page 4: B: Limited Warranty
Perma Pure LLC WARRANTY and DISCLAIMERS Perma Pure (Seller) warrants that product supplied hereunder shall, at the time of delivery to Buyer, conform to the published specifications of Seller and be free from defects in material and workmanship under normal use and service. Seller’s sole obligation and liability under this warranty is limited to the repair or replacement at its factory, at Seller’s option, of any such product which proves... -
Page 5: C: Principle Of Operation
C: P RINCIPLE OF PERATION The Baldwin™-Series Model 34C Heated Filter Probe is designed to be mounted on a stack or duct for use in high particulate applications. Its primary function is to provide a heated environment to maintain sample gas temperatures above dew point and remove particulate material from the gas sample. -
Page 6: D: Maintenance
D: M AINTENANCE The Model 34C does not require routine maintenance for the filter head or the temperature controller. The filter element requires periodic replacement, depending upon application and dust loading. See the attached Spare Parts list for replacement elements. If the Model 34C is used in conjunction with the Baldwin™-Series Flow Control Drawer, monitoring the sample vacuum will warn the operator when to change the filter element. -
Page 7: E: Troubleshooting
Heater clamps not getting hot Check for 110VAC going into the Replace clamp Clamps For further service assistance, contact: Perma Pure LLC 1001 New Hampshire Ave Lakewood, NJ 08701 Tel: 800-337-3762 (toll free U.S.) Tel: 732-244-0010 Fax: 732-244-8140 Email: info@permapure.com... -
Page 8: F: Spare Parts
F: S PARE ARTS Model 34C-MONSOL Part No. Description 1PCG-002 Connector: Heated Line Entry Seal, 3” 3FES-004 Filter Element: 316L SS, 1.25” x 2.975”, 10 Micron 3PAM-006PK Gasket: Graphoil 1.25” (10 pack) 3PHS-417 Heater Cartridge, 350W 3PAM-028PK O- Ring: Silicone, 50 Durometer (10 pack) 3PAM-010PK O- Ring: Viton, 50 Durometer (10 pack) 3PAM-031PK... -
Page 9: Appendix
PPENDIX...
