Billion BiPAC 7402VGO Quick Start Manual

Voip/802.11g adsl2+ vpn firewall router
Hide thumbs Also See for BiPAC 7402VGO:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
BiPAC 7402VGO
VoIP/802.11g ADSL2+ VPN
Firewall Router
Quick Start Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BiPAC 7402VGO and is the answer not in the manual?

Questions and answers

Related Manuals for Billion BiPAC 7402VGO

Summary of Contents for Billion BiPAC 7402VGO

  • Page 1 BiPAC 7402VGO VoIP/802.11g ADSL2+ VPN Firewall Router Quick Start Guide...

  • Page 3: Package Contents

    For more detailed instructions on configuring and using the Billion VoIP/802.11g ADSL2+ VPN Firewall Router, please refer to the on-line manual. Package Contents VoIP/802.11g ADSL2+ VPN Firewall Router CD-ROM containing the online manual RJ-11 ADSL/telephone Cable Ethernet (CAT-5 LAN) Cable Console (PS2-RS232) Cable AC-DC power adapter (12VDC, 1.2A) This Quick Start Guide...

  • Page 4: The Front Leds

    Quick Start Guide The Front LEDs LAN Port 3 - 5 — (RJ-45 connector) WLAN Phone 8 – 9 — (RJ-11 connector) LINE VoIP PPP / MAIL ADSL Lit when power is ON. Lit when the system is ready. Lit when connected to an Ethernet device. Green for 100Mbps;...

  • Page 5: The Rear Ports

    The Rear Ports Port Power Switch RESET — (RJ-45 connector) CONSOLE Phone ─ (RJ-11 connector) ADSL Antenna LINE VoIP/802.11g ADSL2+ VPN Firewall Router Power ON/OFF switch Connect the supplied power adapter to this jack. After the device is powered on, press it to reset the device or restore to factory default settings.

  • Page 6: Connecting Your Adsl Router

    Quick Start Guide Connecting Your ADSL Router 1. Connect this router to a LAN (Local Area Network) and the ADSL/telephone (ADSL) network. 2. Power on the device. 3. Make sure the PWR and SYS LEDs are lit steadily and that the LAN LED is lit. 4.

  • Page 7: Configuring Pc In Windows Xp

    Configuring PC in Windows XP 1. Go to Start / Control Panel (in Classic View). In the Control Panel, double-click on Network Connections 2. Double-click Local Area Connection. 3. In the Local Area Connection Status window, click Properties. 4. Select Internet Protocol (TCP/IP) and click Properties.

  • Page 8: Configuring Pc In Windows 2000

    Quick Start Guide Configuring PC in Windows 2000 1. Go to Start / Settings / Control Panel. In the Control Panel, double-click on Network and Dial-up Connections. 2. Double-click Local Area Connection. 3. In the Local Area Connection Status window click Properties. 4.

  • Page 9: Configuring Pc In Windows 98/Me

    Configuring PC in Windows 98/Me 1. Go to Start / Settings / Control Panel. In the Control Panel, double-click on Network and choose the Configuration tab. 2. Select TCP/IP -> NE2000 Compatible, or the name of your Network Interface Card (NIC) in your PC. 3.
  • Page 10 Quick Start Guide Configuring PC in Windows NT4.0 1. Go to Start / Settings / Control Panel. In the Control Panel, double-click on Network and choose the Protocols tab. 2. Select TCP/IP Protocol and click Properties. 3. Select the Obtain an IP address from a DHCP server radio button and click OK.
  • Page 11 Configuring Your ADSL Router To configure this device, you must have IE 5.0 / Netscape 4.5 or above installed Verifying Your Local Network Connection with the Device To see if this ADSL Router is visible on the local network, go to Start / Run.

  • Page 12: Connecting To The Router

    Quick Start Guide Connecting to the Router Open the web browser and type http://192.168.1.254 in the browser’s address box. This number is the default IP address for this router. Press Enter. 2. A username and password window will appear. The default username and password are admin and admin.

  • Page 13: Product Support And Contact Information

    At the main menu screen, the left navigation panel where bookmarks are provided links you directly to the desired setup page, including: Status (ARP Table, Wireless Association, Routing Table, DHCP Table, IPSec Status, L2TP Status, Sessions and UPnP Portmap) Quick Start Configuration (LAN, WAN, System, Firewall, VPN, VoIP, QoS, Virtual Server, Time Schedule and Advanced) Save Config to FLASH...
