Additional Fault Finding Instructions
Smoke Detection System SDS-2/6
• Fault Finding Table ( Quick Reference )
• Fault Finding of Airflow Faults
• Fault Finding of Data Transfer Faults
• Fault Finding of Smoke Detector Faults
• Problems with Fuses on Power Supply Module
Drawings
• Wiring Diagram Smoke Detectors, Airflow Indicators, Zener Barriers BG01.724
• Configuration Tables SDS01.100.80 - SDS01.100.88
Fault Finding Instructions SDS26
for
safetec Brandes und Niehoff GmbH
Arenskule 7-9
D-21339 Lüneburg
Germany
Tel.: ++49 - 4131 – 7670-200
Fax.: ++49 - 4131 – 7670-201
Contents
16.06.09
safetec
Seite 1 von 13
Advertisement
Summary of Contents for Safetec SDS-2/6
- Page 1 Additional Fault Finding Instructions Smoke Detection System SDS-2/6 safetec Brandes und Niehoff GmbH Arenskule 7-9 D-21339 Lüneburg Germany Tel.: ++49 - 4131 – 7670-200 Fax.: ++49 - 4131 – 7670-201 Contents • Fault Finding Table ( Quick Reference ) •...
- Page 2 Fault Finding Table Faults Possible Reasons Correction (on the LCD) CHECK : Fan -x- All 3- way valves were shortly 1. Check position of 3-way closed. valves 2. Switch-over to stand-by fan aggregate Fuse(s) of fan aggregate on Correct faults...
- Page 3 Further Fault Possible Reason Correction Contrast of LCD is too weak or Contrast control is not adjusted Adjust contrast intensity at the too strong adjustable resistor on the rear side of indication / control module LCD does not display any...
- Page 4 Fault Finding of Airflow Faults Fault Indication: “FAULT Airflow all lines” or “FAULT: Airflow Line -x-y-z-“ • Ensure one of the fans is running. • Ensure 3-way-valves are open. • Ensure upper door of the smoke detection panel / extension unit is closed.
- Page 5 Table 1a and 1b • If the measured voltages are correct, but fault indication is still present, the detector interface module must be exchanged. • If the measured voltages are not correct compared with table 1, disconnect the wires at the terminal nos. 33/34 at the detector interface module. Measure the...
- Page 6 Fault Finding of Data Transfer Faults General Information The following components of the smoke detection system SDS are connected by a 4- wire-bus ( RS485-bus ): Name of Component Function Address – No. Indication- / control module Master No address...
- Page 7 Fault Indication “FAULT: Data Transfer” This fault indication without display of any device no. appears only on the repeater panel. It means, that no call of the master reaches the controller of the indication- / control module in the repeater panel. Therefore no other faults can be displayed.
- Page 8 Fault Indication “FAULT: Data Transfer Device -1-2-3- ... ” ( all connected components are indicated as faulty ) When the fault indication lists all addressable components, please check the following: • Check setting of rotary switch at indication- / control module in smoke detection panel.
- Page 9 Fault Finding of Smoke Detector Faults General Information Max. 6 smoke detectors are connected to one smoke detection panel or to one extension unit. Each smoke detector has a DIP-switch on its rear side to assign its ID- no. Note that only the values 1 – 6 are allowed ( also in the extension units with higher line nos.
- Page 10 All smoke detectors of the smoke detection panel or extension unit indicate “FIRE”, but no smoke is present Please disconnect the wires at terminal nos. 31/32 at the detector interface module. If the alarm indication is still present, the detector interface module is defective and must be exchanged.
- Page 11 Cleaning of Smoke Detectors Push back snapping lugs of outer protection cap and remove outer protection cap Smoke detector from below Remove PCB by carefully pushing back snapping lugs Remove detection chamber by carefully pushing back snapping lugs PCB from below...
- Page 12 Clean both parts of labyrinth with compressed air. Ensure, that the small white reflector in the optical chamber is clean. If there are sticky residues, the labyrinth may be cleaned with a mild soap solution or with isopropyl alcohol.
- Page 13 Problems with Fuses on Power Supply Module (SDS-2/6) Blown Possible Reason Fuse Power supply module defective. Exchange power supply module. External short circuit on the bus cable. Please disconnect bus cable from terminal nos. 17, 18, 19 and 20 at the power supply module and start system again.
- Page 14 Zener Barriere for Airflow Indicator Line 4 - 6 corresponding to Line 1 - 3 Contacts of airflow detector 3 x H05VV 2x0,75 H05VV 2x0,75 shown in fault position (no airflow) Airflow Indicator Line 4 - 6 Smoke Detection System SDS-2/6 Rev. 26.04.02 Maßstab safetec Gepr. BG01.720.04.tcd Wiring Diagram Smoke Detectors, Airflow Indikators, Zener Barriers Bearb.
- Page 15 "1" connected to the Smoke Det. Panel "1" Legend: Value for Setting the Rotary switch End-of-Line-Resistors not required Cablework for Interconnection Configuration Table for Smoke Detection System SDS-2/6 safetec SDS01.100.80 Gez.: 28.07.97 kb without Extension Unit and without Repeater Panel...
- Page 16 Legend: Value for Setting the Rotary switch Connect End-of-Line-Resistors ( 120 Ohm ) to Terminal 19/20 in Smoke Det. Panel and Repeater Panel Cablework for Interconnection Configuration Table for Smoke Detection System SDS-2/6 safetec SDS01.100.81 Gez.: 28.07.97 kb without Extension Unit but with one Repeater Panel...
- Page 17 Legend: Value for Setting the Rotary switch Connect End-of-Line-Resistors ( 120 Ohm ) to Terminal 19/20 in Smoke Det. Panel and Repeater Panel No. 2 Cablework for Interconnection Configuration Table for Smoke Detection System SDS-2/6 safetec SDS01.100.82 Gez.: 28.07.97 kb...
- Page 18 Legend: Value for Setting the Rotary switch Connect End-of-Line-Resistors ( 120 Ohm ) to Terminal 19/20 in Smoke Detection Panel and Extension Unit Cablework for Interconnection Configuration Table for Smoke Detection System SDS-2/6 safetec SDS01.100.83 Gez.: 28.07.97 kb without Extension Unit and without Repeater Panel...
- Page 19 "1" Legend: Value for Setting the Rotary switch Connect End-of-Line-Resistors ( 120 Ohm ) to Terminal 19/20 in Extension Unit and Repeater Panel Cablework for Interconnection Configuration Table for Smoke Detection System SDS-2/6 safetec SDS01.100.84 Gez.: 28.07.97 kb with one Extension Unit and one Repeater Panel...
- Page 20 "1" Legend: Value for Setting the Rotary switch Connect End-of-Line-Resistors ( 120 Ohm ) to Terminal 19/20 in Extension Unit and Repeater Panel No. 2 Cablework for Interconnection Configuration Table for Smoke Detection System SDS-2/6 safetec SDS01.100.85 Gez.: 28.07.97 kb...
- Page 21 Legend: Value for Setting the Rotary switch Connect End-of-Line-Resistors ( 120 Ohm ) to Terminal 19/20 in Smoke Det. Panel and Extension Unit No.2 Cablework for Interconnection Configuration Table for Smoke Detection System SDS-2/6 safetec SDS01.100.86 Gez.: 28.07.97 kb with two Extension Units but without Repeater Panel...
- Page 22 "1" Legend: Value for Setting the Rotary switch Connect End-of-Line-Resistors ( 120 Ohm ) to Terminal 19/20 in Extension Unit No.2 and Repeater Panel Cablework for Interconnection Configuration Table for Smoke Detection System SDS-2/6 safetec SDS01.100.87 Gez.: 28.07.97 kb with two Extension Units and one Repeater Panel...
- Page 23 "1" Legend: Value for Setting the Rotary switch Connect End-of-Line-Resistors ( 120 Ohm ) to Terminal 19/20 in Extension Unit No.2 and Repeater Panel Cablework for Interconnection Configuration Table for Smoke Detection System SDS-2/6 safetec SDS01.100.88 Gez.: 08.09.98 kb with two Extension Units and with two Repeater Panels...
