Memjet AstroJet L1 Quick Start Manual

Hide thumbs
1
2
3
4
5

Advertisement

Table of Contents

AstroJet L1
Quick Start Guide
Step 1
Remove Printer and Accessories
from packaging
Place Printer on a level, stable surface. Make
sure Printer is level.
Step 2
Install Ink Drip Tray Assembly
1. Open Ink Tank Door [A].
2. Release Latch [B] to raise Top Assembly.
3. Insert tabs on Ink Drip Tray into frame slots
[C] as shown.
4. Close Top Assembly.
Step 3
Connect Power to Printer
1. Main Power Switch [1] is
turned OFF.
2. Plug power cord into
receptacle [1] located
below the Main Power
Switch. Internal power
supply in Printer is rated
100 to 240VAC, 50/60 Hz.
IMPORTANT!
CLOSE ALL COVERS AND
DOORS BEFORE POWERING
THE PRINTER UP OR DOWN.
NOTE: START ONE PRINTER
AT A TIME WHEN SIMILAR
PRINTERS ARE ON THE SAME
NETWORK.
Connect Printer to Computer
USB port [2] for computer connection.
Network Port [3] for connection to a network.
DO NOT CONNECT USB CABLE OR NETWORK
CABLE YET.
DO NOT TURN PRINTER POWER SWITCH [1]
ON YET.
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AstroJet L1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Memjet AstroJet L1

Summary of Contents for Memjet AstroJet L1

  • Page 1: Quick Start Guide

    AstroJet L1 Quick Start Guide Step 1 Remove Printer and Accessories from packaging Place Printer on a level, stable surface. Make sure Printer is level. Step 2 Step 3 Install Ink Drip Tray Assembly Connect Power to Printer 1. Open Ink Tank Door [A].
  • Page 2 3. License Agreement. Step 4 Check “I accept…” then click “Next>”. Print Driver Installation Minimum System Requirements:  Operating System: Windows 8/8.1, Windows 10 (Desktop Mode only). Windows XP, Windows Vista, Windows 7. Supports 32 and 64 bit systems. (Must have administrative privileges on system.) NOTE: Windows 8, 8.1 and 10 will only work in desktop mode.
  • Page 3 Step 5 7. Connect Device Now. Turn Printer ON and connect USB cable. Don’t click on either button. Software will finish installing. Install Ink Tanks Printer uses (1) Printhead Cartridge and (5) Ink Tanks (two Black, one Cyan, one Magenta, and one Yellow). 1.
  • Page 4 Step 6 2. Carefully remove Printhead Cartridge from foil packaging. Install Printhead Cartridge Handle Printhead Cartridge with extreme care to avoid damage. CAUTION  Use electrostatic discharge (ESD) protection when handling Printhead.  Hold Printhead Cartridge by handles ONLY.  DO NOT touch ink couplings, nozzle surface or electrical contacts.
  • Page 5 Step 7 For instructions on installing Accessories and Printer set- 630 Lively Blvd. up or operation, please refer to “AstroJet L1 Color Elk Grove Village, IL 60007 Label Printer Operator Manual” in Print Driver CD Phone: (847) 364-6363 supplied with Printer.
