- Page 1 Model No SP0104-U01 Operating Instructions Thanks for purchasing our product. Please be sure to read this instruction manual. carefully before using our product.
- Page 3 Introduction SP0104-U01 is a four-way HDMI splitter. It distributes one input HDMI signal to four identical UTP outputs. These four outputs are synchronized. SP0104-U01 has the ability of pre-emphasis and equalization. Series connection of SP0104-U01 achieves long distance transmission of HDMI signal of more than 50 meters.
-
Page 4: Table Of Contents
Contents HDMI Splitter..................1 ■ Product Overview ................1 ■ Features ..................1 ■ Package Contents ................3 ■ Connections and Operations............3 ■ Specifications .................6 ■ Panel Descriptions .................7 ■ Typical Application .................8 ■ Maintenance ...................8 ■ Product Service ................8 ● Provided Service .................8 ●... -
Page 5: Hdmi Splitter
HDMI Splitter Product Overview ( Model Number: SP0104-U01 ) ■ Dear customer Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. Features ■... - Page 6 Warning To reduce the risk of fire, electric shock or product damage: To reduce the risk of fire, electric shock or product damage: 1. Do not expose this apparatus 6. Clean this apparatus to rain, moisture, dripping or only with dry cloth. splashing and that no objects filled with liquids, such as vases, shall be placed on the apparatus.
-
Page 7: Package Contents
Package Contents ■ ① Main unit. P/N_SP0104-U01. ② 5VDC Power Supply.P/N_VDC0503. ③ Operating Insrtuctions.P/N_INSSP0104-U01. ④ IR TX UNIT. NOTE: Cables are optional Connections and Operations ■ 1) Connect the HDMI input sources into SP0104-U01(Input cables are optional). 2) Connect two CAT-5E/6E cables to both the STP/UTP outputs of SP0104-U01 and inputs of STP/UTP receiver (such as EX0101-U51/53 etc). - Page 8 Position1 Position2 Position3 Function 1080P stereo (Using Embedded EDID) (note1) 1080P 5.1 (Using Embedded EDID) (note2) Edid auto mix, mix result is compatible with all HDMI sinks (note3) copy the first detected HDMI output's edid to the input port (note4) LC mode, 1080P stereo (Using Embedded EDID) (note5) LC mode, Edid auto mix, mix result is compatible...
- Page 9 Note7: Please refer to Note 4. The only difference is that if video appears noise or interference when the long HDMI/UTP cable is used or the quality of HDMI/UTP cable is not so good, use this mode Note8: Fix single UTP output, use the embedded 1080P-stereo EDID Attention: Insert / Extract cables gently.
-
Page 10: Specifications
Specifications ■ Operating Temperature Range -5 to +35°C (-41 to +95°F) Operating Humidity Range 5 to 90% RH ( no condensation ) Video Amplifier Bandwidth 140mHz Input Video Signal 0.5-1.0 volts p-p Input DDC Signal 5 volts p-p (TTL) VGA: 640x480, 800x600, 1024x768,1 280x1024 DTV/HDTV: Video Format Supported... -
Page 11: Panel Descriptions
Panel Descriptions ■ Front Panel Back Panel Page 7... -
Page 12: Typical Application
Typical Application ■ Maintenance ■ Clean this unit with a soft, dry cloth. Never use alcohol, paint thinner or benzine to clean this unit. Product Service ■ ● Provided Service 1) Damage Requiring service: The unit should be serviced by qualified service personnel if: The DC power supply cord or AC adaptor has been damaged;... -
Page 13: Mail-In Service
Objects or liquids have gotten into the unit; The unit has been exposed to rain; The unit does not operate normally or exhibits a marked change in performance; The unit has been dropped or the cabinet damaged. 2) Servicing Personnel: Do not attempt to service the unit beyond that described in these operating instructions. -
Page 14: Warranty Limits And Exclusions
repair your product with new or refurbished parts, or (b) replace it with a new or a refurbished product. The decision to repair or replace will be made by the warrantor. During the “Labor” Limited Warranty period there will be no charge for labor. During the “Parts”... - Page 15 listed are not exclusive, but are for illustration only.) 3) Parts and service, which are not covered by this limited warranty, are your responsibility. Page 11...
