HDMI Splitter
SS0202
Model No.
Operating Instructions
Dear customer
Thank you for purchasing this product. For optimum performance and safety,
please read these instructions carefully before connecting, operating or adjusting
this product. Please keep this manual for future reference.
FEATURES
Easy to Use: Install in seconds, no need for setting.
Switching: Inputs could be switched between HDMI and DVI.
Conversion: It could convert DVI and SPDIF audio into complete HDMI.
Distribution: Two identical HDMI outputs.
Stackable (Daisy chained): Large distribution achieved by stacking SS0202.
HDCP compliant.
１
Grandbeing
（P/N of this Instructions is INSSS-0202）
Operating Instructions
®
GRANDBEING
®
Advertisement
Table of Contents
Related Manuals for Grandbeing SS0202
Summary of Contents for Grandbeing SS0202
- Page 1 Easy to Use: Install in seconds, no need for setting. Switching: Inputs could be switched between HDMI and DVI. Conversion: It could convert DVI and SPDIF audio into complete HDMI. Distribution: Two identical HDMI outputs. Stackable (Daisy chained): Large distribution achieved by stacking SS0202. HDCP compliant. ® １...
- Page 2 Operating Instructions NOTICE Grandbeing Inc. reserves the right to make changes in the hardware, packaging and any accompanying documentation without prior written notice. TABLE OF CONTENTS Introduction Package Contents Panel Descriptions Connecting Operating Specifications Typical Application Maintenance Product Service Warranty...
- Page 3 Series connected SS0202 achieves long-distance transmission of HDMI signal of more than 15 meters. When two or more SS0202 are stacked together (Daisy chained), they can be used to create a larger distribution. SS0202 offers solutions for digital entertainment center, HDTV retail and show...
- Page 4 2) Connect the first HDMI device into the HDMI Output 1 slot in the back of SS0202. Connect the second device into the HDMI Output 2. 3) Insert the DC side of 12v power supply into SS0202 and then connect the AC side of the power supply into the wall outlet.
- Page 5 (d) The unit does not operate normally or exhibits a marked change in performance; (e) The unit has been dropped or the cabinet damaged. 2) Servicing Personnel: Do not attempt to service the unit beyond that described in these operating instructions. Refer all other servicing to authorized servicing personnel. ® ５ GRANDBEING...
- Page 6 WARRANTY If your product does not work properly because of a defect in materials or workmanship, Grandbeing Company (referred to as “the warrantor”) will, for the （Parts (1) Year， Labor(90) Days） length of the period indicated as below, which starts with the date of original purchase (“Limited Warranty period”), at its option...
- Page 7 The items listed are not exclusive, but are for illustration only.) 3) PARTS AND SERVICE, WHICH ARE NOT COVERED BY THIS LIMITED WARRANTY, ARE YOUR RESPONSIBILITY. Customer Services Directory Grandbeing Technology Co., Ltd B-26H, Neptunus Mansion, Nanyou Da Dao, Shenzhen , P.R. China Post Code:518054 Tel:86-755-33639970 Fax:86-755-33639971 Email:Sales@grandbeing.com, lauarthur@163.com...
