Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com
Th
ank you for purchasing the SR Intelligent Controls Series (SR) of our
company. You are recommended to take some time to read this manual, before
putting the SR in to service. It tells you how to install, program and use the SR. The
SR has, amongst many features, the advantage being able to be operated off line to
prove in service performance before being commissioned into service. When you read
the manual you will find many more advantageous properties of the products, it will
greatly simplify the operation of SR for you.
The SR is a type of intelligent control, which uses function blocks for
programming. It enables the control functions of a PLC to be achieved without the
need for large number of instructions and complicated programming. When several
function blocks are linked together in a specific way, relatively complicated control
functions can be implemented. The programming can be carried out in a logical,
speedy and verifiable manner. Programming can be implemented using a removable
LCD liquid crystal display panel or by use of a computer. The latter approach is
recommended for more complicated control schemes.
SR has a very wide range of applications. It can be used for the automation of
an extensive range of electrical and mechanical equipment, flow control, building
automation and many other fields. The implementation of SR provides for automation
of many aspects of day-to-day life from home through to the commercial,
manufacturing, mining, utility and service sectors of the economy. This manual will
describe in detail the functional characteristics and operating methods for SR.
Notes:
Copyright of this manual and patent of SR Intelligent Controls Series are the property
of ARRAY ELECTRONIC CO., LTD. The reproduction, transmission or use of this
manual or its contents is not permitted without written express written authority.
Our company reserves the right to make changes in design for improvement SR
Intelligent Controls Series without notification.
Suggestions for improvement are welcomed.
Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com
Preface

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SR Series and is the answer not in the manual?

Questions and answers

Related Manuals for Array electronic SR Series

Summary of Contents for Array electronic SR Series

  • Page 1 Notes: Copyright of this manual and patent of SR Intelligent Controls Series are the property of ARRAY ELECTRONIC CO., LTD. The reproduction, transmission or use of this manual or its contents is not permitted without written express written authority. Our company reserves the right to make changes in design for improvement SR Intelligent Controls Series without notification.
  • Page 2 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com Safety Guidelines: This manual contains notices which you should observe to ensure your own personal safety, as well as to product and connected equipment. These instructions in the manual are highlighted by a warning triangle and are marked as follows according to their danger level: Danger Indicates that death, severe harm to health or damage to assets will result if proper...

  • Page 3: Table Of Contents

    Part I Basic Operation and Application of SR Chapter I General Introduction to SR 1.1 Structure of SR Series 1.2 Naming Rules of SR Series 1.3 Specifications and Model of SR Series 1.4 Features of SR Chapter II Installing and Wiring of SR 2.1 Installing of SR 2.1.1 Installing Methods...
  • Page 4 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com 3.2.12 TSEQ 3.2.13 SSEQ 3.2.14 HOUR 3.2.15 Instructions of Property Pin 3.3 Input & Output Blocks 3.3.1 IN 3.3.2 OUT 3.3.3 RCI 3.3.4 DOUT 3.3.5 D-IN 3.3.6 PMSG 3.3.7 CONT 3.3.8 SLCD...
  • Page 5 6.2.1 Structure of Extension Module 6.2.2 Address Setup of Extension Module 6.2.3 Type and Wiring of Extension Module 6.3 Solid Diagram and Accessories of SR Series Chapter VII Technical Parameter of SR Series 7.1 Technical Parameter of SR-12MRA/SR-22MRA 7.2 Technical Parameter SR-12MRD/SR-22MRD 7.3 Technical Parameter SR-12MTD/SR-22MTD...
  • Page 6 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com Chapter I Installation and Uninstallation 1.1 Installation of Super CAD 1.2 Uninstallation of Super CAD Chapter II General Introduction to Super CAD 2.1 Operation Interface 2.2 Edition Interface 2.3 Main Functions Chapter III Operation Instruction and Function Block Stock...

  • Page 7: Structure Of Sr Series

    PLC, which uses ladder diagrams and associated instructions. The design concept, for the SR series products, includes a removable LCD panel. The program can be written directly into the SR using this LCD panel. After programming the LCD panel can be retained or removed and replaced with a cover.
  • Page 8 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com Fig.1.2 SR 22 Point Main Machine 1£®Input of Power (AC or DC) (AC110-220V), (DC12-24V) 2£®Input Wiring Terminal 3£®SR-HMI or SR-WRT 4£®Communication Interface 5£®Output Wiring Terminal (Output of relay or electronic transistor) 6£®LCD Display Panel Series 1.2 Naming Rules of SR...
  • Page 9 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com 1.3 Specifications and Type of SR Type Power Input Output Remarks 1 SR-12MRAC AC110-220V 8 points AC input 4 point relay output Machine with real-time clock 2 SR-12MRDC DC12-24V 8 points DC input 4 point relay output Machine with real-time clock (6 points analog)

  • Page 10: Features Of Sr

    Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com 22 SR-LC The decorating cover of the connecting cable. (If using SR-CBA or SR-CBD, then there is no need to use this cover.) (One on each side) 23 SR-CP Communication interface wire between SR and PC, to realize the programming, analog and slow monitoring function of the PC to the SR.
  • Page 11 Thus it can be extension to 20 points input/output once (12 points input and 8 points output). One set of SR series machine can be externally connected with 5 extension modules. Thus 22 points machine can be extension to 120 points input/output (74 points input and 48 points output).
  • Page 12 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com 8. Write the program online SR series intelligent controller adds the function of writing the program online. It can be updated and upgraded at any time according to the source program code. When SR series product being updated, you may update your system through the Internet.
  • Page 13 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com into a SR unit. With more complicated control schemes the use of an ancillary computer, loaded with SUPER RELAY LOGIC software, is recommended. The control program can then be written into the memory of the SR is a very friendly human-machine interface programming software.

  • Page 14: Installing Of Sr

    Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com Chapter II Installing and Wiring of SR 2.1 Installing of SR 2.1 Installing Method SR is small and it is suitable for fitting inside panels or machinery within it’s’ specification criteria.
  • Page 15 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com Fig. 2.3 Installation Dimension of SR-22 Series (MM) Fig. 2.4 Installation Dimensions of SR-VP Series Voice Module (MM) Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com...
  • Page 16 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com Fig. 2.5 Installation Dimensions of SR-20 and SR-RC Series (MM) 2.2 Wiring of SR A screwdriver with a spade tip width of 3mm is used for the wiring of FABs. The maximum cross sections of the wires that can be inserted into the terminals are determined according to the following sizes: ¡ù...

  • Page 17: Connecting Inputs

    Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com Fig. 2.6 AC Type Fig. 2.7 DC Type 2.2.2 Connecting Inputs The input to FAB can be either digital, such as on/off switches etc., or analog, such as pressure, temperature, humidity, flow, etc.

  • Page 18: Connecting Outputs

    Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com Connecting SR is shown as in the following figures: Fig. 2.8 AC Type Fig. 2.9 DC Type Fig. 2.10 DC Type (Analog) 2.2.3 Connecting Outputs 1.
  • Page 19 3. The output terminal must be connected with a load. 2.2.4 Net-connecting of SR Series SR series machine can be connected with voice module, remote control module, extension module together and use. They must be the same type. That is to say that the AC types are connected with the AC types and the DC types are connected with the DC types.
  • Page 20 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com 1. SR-12MRA and SR-20ERA, SR-RCA or SR-VPA Connecting Diagram Fig. 2.13 Notes: Input Voltage AC110-220V Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com...
  • Page 21 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com 2. SR-12MRD and SR-20ERD, SR-RCD or SR-VPD Connecting Diagram Notes: Input Voltage: DC 12-24V 3. SR-12MTD and SR-20ETD, SR-RCD or SR-VPD Connecting Diagram Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com...
  • Page 22 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com...
  • Page 23 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com Notes: 4.Don’t’ touch or take down the link bridge SR-CBA/CBD at SR working. 1. The connecting voltage of the transistor type output control must be ¨Q24VDC and the load voltage must be DC.

  • Page 24: General Function Block (Gf

    Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com Chapter III General Description of Function Block SR series adopt the programming methods by the use of function blocks. In total 8 general function blocks, 14 special function blocks and 8 input & output function blocks are configured.
  • Page 25 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com Parallel connection Of NO contacts Phase inverter Dual communicator contact Parallel connection NAND Of NC contacts Parallel connection of NAND NC contacts with RLO (With RLO borderline borderline test test) Series connection...

  • Page 26: And With Rlo Borderline Test

    Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com Logical frame of AND: I4 Q 3.1.2 AND with RLO Borderline Test In SR, the symbol is as shown in follows: Only when all the statuses of the inputs are 1 and at least the status of one input is 0 in the last period, the output status of AND with RLO borderline test is 1.
  • Page 27 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com 3.1.3 OR Parallel connection of a certain number of In SR, the symbol of OR NC contacts is shown in the SR line is as shown in follows: diagram as follows: This function block is called as OR, because the status for at least one of the inputs I1, I2, I3 or I4 is 1 (i.e.

  • Page 28: Nand

    Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com 3.1.5 XOR In SR line diagram, the two commutator In SR, the symbol of contacts for XOR are connected in serial XORis shown as follows: as follows: When the statuses of all the inputs are not the same, the output status of XOR is 1.

  • Page 29: Nand With Rlo Borderline Test

    Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com 3.1.7 NAND with RLO Borderline Test In SR, the symbol is as shown in follows: Only when the status of at least one of the input is 0 and statuses of all the inputs in the last period are 1, the output status of this NAND with RLO borderline test is 1.

  • Page 30: Special Function Blocks (Sf

    Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com 3.2 Special Function Block (SF) There are 14 special function blocks in total as list in the following table. Table 2: Special Function Blocks Function Representation Graphic TOND TOFD SBPL...
  • Page 31 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com MTOD UDCT PONS CMPR TSEQ SSEQ HOUR T/C-Comparator Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com...
  • Page 32 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com 3.2.1 TOND Line diagram/Symbol Pin Description in SR After TRG is triggered, the time delay timer starts timing. (If TRG stop triggering during the timing of timer, the timer will Input TRG terminate the timing.) After time T, the output is on (the output signal changes from 0...
  • Page 33 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com 3.2.2 TOFD Line diagram/ Symbol in Pin Description Turn on the timer of the time-delay off relay, when the input TRG Input TRG (trigger) is at the descending edge (changing from 1 to 0). The timer of disconnecting time-delay relay is reset via R (Reset Input R Input), and Output Q is set to 0.

  • Page 34: Spbl

    Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com 3.2.3 SPBL Line diagram/ Symbol in Pin Description Input TRG Trigger input (TRG) makes the output ON and OFF. The output Q is reset via R (Reset Input). (Q=0, R has ahigher Input R priority to TRG.) Every time TRG changes from 0 to 1, the status of Q will be...

  • Page 35: Tpbl

    Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com 3.2.4 TPBL Line diagram/ Symbol in SRPin Description Make the Output Q be Status 1 via Input S Input S (Position). TheOutput Q is reset to 0 via R (Reset Input). If S and R are both Status 1, Output Q is 0.

  • Page 36: Blnk

    Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com 3.2.5 BLNK Line diagram/ Symbol in Pin Description Input (only be effective in high potential). Make the clock Input EN pulse generator connected or open via EN input. Input R Make Output Q be 0 via Input R (Reset).
  • Page 37 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com 3.2.6 TMOD Line diagram/ Symbol in Pin Description Input TRG Timer for ON time delay is started via Input TRG (Trigger). Timer for ON time delay is reset to ON via Input R, and Input R make Output Q be 0).
  • Page 38 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com 3.2.7 PONS Line diagram/ Symbol in SR Pin Description Input TRG activated the single-pulse time and relay. When the Input TRG descending edge is coming, it will output a pulse with the width of Reset Single-pulse time relay.
  • Page 39 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com 3.2.8 UDCT Line diagram/ Symbol in SR Pin Description Internal counter value and the output are reset via R (Reset). R ha Input R a priority to CTN. When CNT (Counter) is inputting, the counter just counts the Input CNT change from Status 0 to Status 1 and doesn’t count the change...
  • Page 40 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com 3.2.9 CMPR Line diagram/ Symbol in SR Pin Description Analog Input 1, can be selected as: the value calculated from the Input 1 analog input IA through the math formula, or the preset analog value.
  • Page 41 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com Parameters] in [Option] to select the two values of the linear relationship as in Fig. 3.1 and Fig. 3.2. (If the sensor tests the 0¡æ first and then tests a 50¡æ. Through these tow times test, it will get the value of A and B.
  • Page 42 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com connected to the pin of the analog input. Thus CMPR will compare this fix value and the calculated value of the analog pin. Example 1: Comparing the calculated value of input 1 and input 2. Input 1 is connected to IA0;...
  • Page 43 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com Logic Relationship is as follows: Fig. 3.5 Function relationship is selected as “>”; Then when the time of B0 is > the time of B1, QA1 is 1. Otherwise it will be 0. Example 2: Comparing the times of two counters Logic Relationship is as follows: Fig.
  • Page 44 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com ON time: AM 8:00 of May.1 2003 OFF time: PM 5:00 of May.1 2003 ON time: AM 9:00 of Oct.01 2003 OFF time: PM 7:00 of Oct. 01 2003 The above of time sequence is correct, and the following is not correct: ON time: AM 8:00 of May.02 2003 OFF time: AM 6:00 of May 01 2003...
  • Page 45 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com 3.2.12 TSEQ (Time Sequence) Line diagram/ Symbol in SR Pin Description There are totally 8 output points (Output 0-7) in the TSEQ function block. And the Output 0 retains the state ON and is not limited by the Input R.
  • Page 46 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com 3.2.13 SSEQ (Step Sequence) Line diagram/ Symbol in Pin Description There are totally 8 output points (Output 0-7) in the SSEQ function block. Among them Output 1-7 will output the TRG Input ON state in time sequence one by one.

  • Page 47: Mtod

    Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com 3.2.14 HOUR Line diagram/ Symbol in Pin Description When INC was activated, the system time will increase 1 Input INC hour automatically. DEC Input When DEC was activated, the system time will decrease 1 hour automatically.
  • Page 48 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com Fig. 3.11 As shown in Fig. 3.11, coz’ the property pin is shelled when SLCD is set. And the property pin of B0 is empty. And when the output pin of B0 is high, HMI will show L:0 page automatically.
  • Page 49 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com 3.3.2 OUT The symbol in SR is as follows: Symbol in SR Function Explanation Output Pin One OUT point is correspond to one output terminal of SR. Function Explanation &...
  • Page 50 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com Function Description: The telephone voice module is to explain the alarming reason by voice through telephone or mobile dialing the preset telephone No. Presentation on how to implement it is made as follows.
  • Page 51 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com (3). When you use the voice module, you must record messages firstly, and the system messages No.01, No.02, No.03 and No.04 have the following functions. Message 0: prompt the user press 0 key and listen to the telephone.
  • Page 52 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com hang off the telephone after 20 seconds delay, and go back to waiting status£» £¨2£©.When there are more than 1 D-IN instructions in the user’s program of SR: A£®If all of the password protection of D-IN was selected, the voice module Will play the No.01 message repeatedly, when the user enter the password, If the password is wrong, the voice module will play the No.03 message, And then will play the...
  • Page 53 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com 3.3.6 PMSG (Need to select SR-VPA/VPD to use together) Line diagram/ Function Pin Description Symbol in SR ON When the ON input becomes 1, the voice module will play all the Voice Playing message that preset in this instruction.
  • Page 54 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com Function Explanation & Icon: To edit the HMI, each SLC has its correspondent HMI page. Notes: The tow input pins of this function block will be displayed or hided according to your choice.
  • Page 55 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com Chapter IV Instruction of HMI Module 4.1 The difference between LCD message of SR and the traditional LCD message In traditional LCD, it can only display some fixed and simple message such as time, I/O status etc.
  • Page 56 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com 3. Direct, Clear & Simple Connecting Relationship User only need to link the LCD with the function block, then all the message shown on LCD will be related to the connected instruction. For example as follows: Note: Set the parameter of B0 as follows: Fig.
  • Page 57 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com All function blocks with output can trigger the HMI When IA1 become 1 status, then the LCD will display the alarm message and indicate the water lever value.
  • Page 58 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com LCD, all the function keys can be defined and provided with explanations. In SUPER CAD, 8 pages of function keys are provided and each page has four function keys. Fig.
  • Page 59 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com Notes: In one LCD interface, only one special character can be added. 4.2 Application Examples of HMI Note º This is a water supply system. £...
  • Page 60 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com Fig. 4.10 B0 will control the pump #1, B1 will control the pump #2, and B6 will control the voice alarm message to alarm. e. The logic control program of SR-12MRDC is as follows: Fig.
  • Page 61 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com Start HMI of Pump #1. Start HMI of Pump #2. Set the HMI of trigger alarm parameter. The HMI when alarming HMI of parameter of time delay on Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com...
  • Page 62 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com HMI of Input and Output Fig. 4.12 4.3 Editing of the HMI Note: There is a LCD display on the hardware of SR, and the LCD can display the system messages, alarm messages, RUN/STOP status, I/O status, parameter changes and function keys.
  • Page 63 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com Choose the SLCD, and put it to the edit window, a SLCD set up window will appear as follows: The message screen which will be displayed The words Insert text...
  • Page 64 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com Choose “User selectable (Upper input not connected)” And choose “Data Source Option (Lower input not connected)” And choose “Time/Date Screen”, then the message screen will appear as follows: The words on the green lines can be changed Double Click to Modify Fig.
  • Page 65 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com Choose “User selectable (Upper input not connected)” And choose “Data Source Option (Lower input not connected)” And choose “Super Relay Input/Output values Screen”, the message screen will appear as follows: Modifiable Fig.
  • Page 66 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com Modified automatically Fig. 4.21 ¢ÛEdit a alarm message screen. Alarm messages screen will be activated by a connected instruction, when the condition is satisfied, the alarm message will appear on the LCD: There are 2 kinds of alarm message screens;...
  • Page 67 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com Fig. 4.23 The related instructions are: TOND, TOFD, SPBL, BLNK, TMOD, UDCT, PONS, CMPR, CT CMPR. ¢Ü Edit a parameter message screen. User can change the preset of the parameter on this kind of message screen by the panel keys on the SR.
  • Page 68 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com Fig. 4.25 There are 2 kinds of set method for presetting the value of CMPR: 1) One kind is that it only has 1 leg need to be compared (including two conditions): (1) Lower leg connected to an input for comparing to a fixed value, see following figure.
  • Page 69 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com Fig. 4.28 ¢Ý Order message screens When you edited a lot of message screens, you need to order them and let the more important one be displayed more previously. You just need to click, the ordering dialogue box will appear as follows: Fig.
  • Page 70 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com Fig. 4.30 4.4 Instruction of Virtual Keys In the Super Relay Logic software, we have defined 32 function keys in 8 pages (A,B,C,D,E,F,G,H),each page has 4 function keys (F1¡XF4), when a function keys was activated, it will offer a high or low potential (1 or 0 status) output, and this output can be used as an input for any other instructions to act as a switch function.
  • Page 71 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com can name the function key (or give some description for the function key), and you can set the password protection for the function key. At last, click OK to finish the definition of a function.
  • Page 72 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com Fig. 4.35 4.5 Set password There is a password protection option in SLCD dialogue box, you can choose according to your need. Fig. 4.36 Click and choose “LCD change Data password protection”, and “Edit” will be activated, you can change a new password.
  • Page 73 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com Fig. 4.38 4.6 Instruction of Help in LCD Software There is”Help” button in the dialogue box of Setup LCD Screen, click to select the help function, the following figure will appear Fig.
  • Page 74 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com If the program is mated and the main machine is running, the LCD displaying main interface will be as follows: In SUPER CAD, this interface cannot be used to program and it is fixed as the first page of the parameter windows.
  • Page 75 9. Audio output port (to be connected with the acoustics) 5.2 Connection between Voice Module and SR SR-VP type voice module can be connected with the SR series machines through SR-CB. Pay attention that only the machines of the same type can be connected together.
  • Page 76 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com machine. Insert the telephone crystal head into the “TO TEL” socket. Insert one head of the audio wire into the audio input port of the voice module (5 of Fig. 5.1) and connect the other head with the audio output of the PC.
  • Page 77 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com Fig. 5.3 Connection between SR-12MRDC and SR-VPD Notes: 1. Telephone wire is two-core wire. 2. Insert the telephone crystal head into the “TO TEL” socket. 3.
  • Page 78 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com automatically and broadcast-Please enter the password for confirmation, then the user enter the SR password. A. If the entered password is correct, SR will then broadcast-Correct password. Please enter the control code to control.
  • Page 79 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com eliminated, the voice module will dial, for alarm purpose, automatically every 40 seconds. While recording, user must delete all the voice once the first time using the voice module before using.
  • Page 80 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com Actual Demonstration: ¢Ù Dial the telephone No. 1234567 of the voice module via telephone or mobile. ¢Ú It will play Message 1 “Please enter the password.” ¢Û...
  • Page 81 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com listen to the message.” When the user presses Key #0, it will play Message 1 “Please enter the password.” Notes: When set B0, the password option must be selected. And the voice module will play Message 1, otherwise the voice module will directly play the selected message after the pressing of Key #0.
  • Page 82 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com software and then it is possible to correctly record to the voice module. In the following we will introduce the recording software in details: Start Software Super CAD and then click ¡°Option | Sound Record¡± to enter the main interface: Fig.
  • Page 83 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com then select button 6£®Volume Adjust: PC Volume Adjust Fig. 5.11 Volume Adjust 7£®PC Recording Procedure Select button and enter into the following interface: Adjust the Recording Volume Select File Saving Folder Set Voice Message File Name Fig.
  • Page 84 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com 9£® Memory Indicator: indicates the occupied memory of the voice message of the voice module. 10£® Voice Message Selection: Select broadcasting or writing voice message via 11£®...
  • Page 85 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com Fig. 5.15 Voice Tone Setup Dialogue Frame System parameter set includes: Volume, Audio Tone & Speaker Type. After setting the specification values, if needed, select “Download” selection frame to download.
  • Page 86 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com Fig. 23 Fig. 5.22 Wiring Diagram of Voice Module Recording Fig. 24 Fig. 25 Fig. 23: Free audio wire accessory, to connect the voice audio input and PC audio output.
  • Page 87 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com the microphone into the microphone input terminal of the PC voice card.) 10. After recording this section, save it into the directed folder of the PC. 11.
  • Page 88 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com Chapter VI Remote control and extension function 6.1 Remote control function The remote control function is to use a wireless transmitter and a receiver to control the ON/OFF status of outputs of SR.
  • Page 89 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com Fig6.2 SR-RCA connected to SR-12MRA and SR-VPA 2£® SR-RCD connected to SR-12MRDC and SR-VPD The DC type receiver and DC type SR, DC type voice module can be used together, SR-RCD can work with SR-12MRDC, SR-12MTDC, SR-22MRDC, SR-22MTDC or SR-VPD, and at the same time, the system can extended to connect 5 PCs of SR-20ERD Fig6.3 SR-RCD connected to SR-12MRDC and SR-VPD...
  • Page 90 Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com 3. SR-RCD connected to SR-12MTDC and SR-VPD Fig6.4 SR-RCD connected to SR-12MTDC and SR-VPD Note: 1£®Only the same type (AC or DC) can be used together. 2£®One SR main machine can extend to connect 5 extension module.(Same AC or DC type).
  • Page 91 6£® Power indicator light 6.2.2 Extension module address setting SR series product can be connected to 5 extension module at the most, we need to give each Controladores lógicos programables PLC baja gama expandibles entradas digitales AC 74368-SR22MRDC ARRAY Manual Ingles www.viaindustrial.com...
