467790317, 467791317
IMPORTANT: Fill out the product record information below.
See rating label on unit for serial number.
Date Purchased
Note: Sales docket must be kept as proof of
purchase date.
For support with your new barbecue, please call us at:
Amalgamated Hardware Merchants
Ph: 07 3208 1233
Email: enquiries@ahmaustralia.com.au
.
AGA 8544 G
© 2017 Char-Broil, LLC Columbus, GA 31902
For use with propane gas only ● For Outdoor Use Only
DO NOT USE INDOORS.
Printed in China
Professional 3 Burner
Gas Grill
Assembly instructions © 2017
06/07/17 • G466-016-150801
Advertisement
Related Manuals for Char-Broil 467790317
Summary of Contents for Char-Broil 467790317
- Page 1 Ph: 07 3208 1233 Email: enquiries@ahmaustralia.com.au For use with propane gas only ● For Outdoor Use Only AGA 8544 G DO NOT USE INDOORS. © 2017 Char-Broil, LLC Columbus, GA 31902 Assembly instructions © 2017 Printed in China 06/07/17 • G466-016-150801...
-
Page 2: Table Of Contents
DANGER TABLE OF CONTENTS For Your Safety................2-3 If you smell gas: Use and Care .................4-10 1. Shut off gas to the appliance, if possible. Limited Warranty.................11 2. Extinguish any open flame. Parts List..................12 3. Open lid. Parts Diagram................13 4. If odor continues, keep away from the appliance and immediately call your gas Assembly................14-33 supplier or your fire department. - Page 3 Clean and oil cooking grate assemblies While acceptable locations to use the barbecue are shown Clean/Inspect firebox on page 6. Char-Broil recommends not to use the barbecue Clean grease tray under any overhead. The smoke from cooking, especialy Check gas supply hose for cracks/leaks...
-
Page 4: For Your Safety
Gas Cylinder USE AND CARE • The gas cylinder used with your barbecue must meet the following requirements: WARNING • Use gas cylinders only with these required measurements: 30.5 cm diameter x 45.7 cm tall with 9 kg. capacity maximum. This is the minimum cylinder that can be used. -
Page 5: For Your Safety
NOTE: The connection to Gas Cylinder Leak Test the gas cylinder is an For your safety ‘ A NTI-CLOCKWISE connection. ’ • Leak test must be repeated each time gas cylinder is exchanged Ensure the connection or refilled. is tightened firmly. Normally Direction for only 1-1 threads of the hose... - Page 6 THIS APPLIANCE SHALL ONLY BE USED IN AN ABOVE GROUND OPEN AIR SITUATION WITH NATURAL VENTILATION, WITHOUT STAGNANT AREAS, WHERE GAS LEAKAGE AND PRODUCTS OF COMBUSTION ARE RAPIDLY DISPERSED BY WIND AND NATURAL CONVECTION. ANY ENCLOSURE IN WHICH THE APPLIANCE IS USED SHALL COMPLY WITH ONE OF THE FOLLOWING: •...
- Page 7 Ignitor Lighting WARNING • Do not lean over grill while lighting. 1. Turn gas burner control valves to (off). 2. Open lid during lighting or re-lighting. For Safe Use of Your Grill and to Avoid Serious Injury: 3. Turn ON gas at LP cylinder. •...
- Page 8 • Cover barbecue if stored outdoors. Choose from a variety of barbecue covers offered by Char-Broil at charbroil.com. • Store barbecue indoors ONLY if LP cylinder is turned off and Disconnected, removed from barbecue and stored outdoors.
- Page 9 MAINTENANCE CAUTION It is your responsibility to properly maintain your barbecue. The frequency of the maintenance will depend on the level SPIDER ALERT! you use the barbecue. Cooking grates and hot plates should be cleaned after or just prior to each use. At least once a year you need to clean the cooking chamber and inspect the burners for corrosion.
- Page 10 Cleaning the Burner Assembly Follow these instructions to clean and/or replace parts of burner (C) Wear eye protection: Use an air hose to force air into assembly or if you have trouble igniting barbecue. the burner tube and out the burner ports. Check each 1.
- Page 11 MANUFACTURER’S WARRANTY STATEMENT The benefits under this manufacturer's warranty are in addition to other rights and remedies under law in relation to goods. Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and for compensation for any other reasonably foreseeable loss or damage.
-
Page 12: Parts List
PARTS LIST Description Description TOP LID REAR TROLLEY PANEL B TEMPERATURE GAUGE UPPER REAR TROLLEY PANEL BEZEL, F/ TEMP GAUGE FRONT DOOR BRACE LOGO PLATE SIDE SHELF CONNECTION BRACE HANDLE F/ TOP LID RAIL, F/ GREASE TRAY BEZEL, F/ HANDLE GREASE TRAY RUBBER BUMPER, W/ HOLE, F/ TOP LID LEFT DOOR, NO HANDLE... -
Page 13: Parts Diagram
PARTS DIAGRAM... -
Page 14: Assembly
HARDWARE LIST Hardware is shown actual size. You may have spare hardware after assembly is complete. Description Picture Cleaning Tool Knob Bezel, Knob #8x3/8" self-tapping Screw AA Battery #8x3/8" self-tapping Screw(Black) 1/4-20x1/2” Screw 1/4-20x1/2” Screw(Black) 1/4-20x2-3/8” Screw #10-24x3/8” Screw(Black) #10-24x3/4” Screw #8-32x3/8”... -
Page 15: Assembly
ASSEMBLY... - Page 22 WARNING Burner must properly engage valve as shown. Failure to engage valve as shown may result in personal injury and/or property damage. Before After...
- Page 26 Remove screws and washers Enlevez les vis et rondelles Retire los tornillos y arandelas...
- Page 28 AA Battery...
- Page 34 NATURAL GAS CONVERSION TO BE INSTALLED ONLY ON OR IN A NON- WARNING COMBUSTIBLE ENCLOSURE Note: Recommended clearances must be maintained, NATURAL GAS CONVERSION ONLY TO BE DONE see page 4. BY AN AUTHORISED PERSON OR LICENSED PLUMBER. Gas Piping Improper installation, adjustment, alteration, service (a) A minimum pipe diameter of 15mm is required or maintenance can cause injury or property damage.
- Page 35 Appliance conversion - Main Burners 1.Remove cooking grate, hot plate, and heat tents. 2.Remove clips retaining flame carryover tubes and burners. 3.Remove flame carryover tubes and burners. 4.Using a 7 mm nut drive remove LP orifices and save in case barbecue needs to be converted back to LP.
-
Page 36: Troubleshooting
EMERGENCIES: If a gas leak cannot be stopped, or a fire occurs due to gas leakage, call the fire department. Emergencies Possible Cause Prevention/Solution Gas leaking from • Damaged hose. •Turn off gas at LP cylinder or at source on natural gas systems. Discontinue use of cracked/cut/burned hose. - Page 37 Troubleshooting (continued) Problem Possible Cause Prevention/Solution Sudden drop in gas flow or • Check for gas in LP cylinder. • Out of gas. low flame. • Excess flow valve tripped. • Turn off knobs, wait 30 seconds and light grill. If flames are still low, turn off knobs and LP cylinder valve.
- Page 40 For support with your new barbecue, please call us at: Amalgamated Hardware Merchants Ph: 07 3208 1233 Email: enquiries@ahmaustralia.com.au For use with propane gas only ● For Outdoor Use Only AGA 8544 G DO NOT USE INDOORS.
