Central Electronic Module (Cem) 1:3 - Volvo V70 2014 Wiring Diagram

Control modules

Central Electronic Module (CEM) 1:3

15+ 30+
15/31
1 1
11B/17 11A/2
2 2
B A
TP 39264202 V70(08-), XC70(08-) & S80(07-) 2014 © Volvo Car Corporation 2013
1
11A/1
2
4/56
C5:1
CEM
CAN
LIN
F7
C3:61
1 2
GN-WH
F23
C3:75
1 2
RD-BN
F9
2 C1:65
1
VT-GN
F10
C1:76
1 2
GY
C1:48
YE-BU
C1:10
BU-BK
GY-BN
C4:6
C2:43
GY-BN
C4:9
VT
C2:11
GN-VT
C2:5
BU
C2:43
GY-BN
C4:6 GY-BN
C1:41
BU-WH
3/130C1:8, 3/4:1
4/33:1
6/127:1
6/127:2
6/1:1,6/1:4
2/182:2
4/119:2
4/93C4:14
7/199:2
6/36:3
15/36
4/93C4:14
4/119:2
4/46
46
