Summary of Contents for Volvo S80 2014
- Page 1 W E B E D I T I O N Q U I C K G U I D E...
- Page 2 WELCOME TO YOUR NEW VOLVO! This folder contains a selection of the most common functions in your particular car. The owner's manual and other manuals contain safety instructions and all warning, important and note texts. The following symbols mean: Different parts are pointed out in the overview images.
- Page 3 How does the remote control key work? Unlocks the doors and boot lid and disarms the alarm. The function can be set in MY CAR. Locks doors and boot lid and arms the alarm. Approach light duration. One press unlocks the boot lid, two presses open it slightly.
- Page 4 How do I start or switch off the engine? Starting Push the remote control key into the ignition switch (does not apply to Keyless drive*). Depress the clutch or brake pedal. Briefly press the START/STOP ENGINE button. Switching off Briefly press the START/STOP ENGINE button. Take the remote control key out from the ignition switch.
- Page 5 How do I use the Start/Stop function*? Manual gearbox Stop the engine: Declutch, move the gear lever into neu- tral position and release the clutch pedal. Start the engine: Depress the clutch pedal. Automatic gearbox Stop the engine: Stop the car with the foot brake and then maintain the brake pressure.
-
Page 6: Store Setting
How do I adjust the seat? Raise/lower the front of the seat cushion. Raise/lower the seat. Move the seat forward/backward. Tilt the backrest. Lumbar support* adjustment. Storing settings for power seat*. Memory buttons for power seat*. Store setting: Hold the button depressed to store settings while depressing one of the memory buttons. - Page 7 How do I regulate the temperature? Turn for individual temperature in the left/right-hand area of the passenger compartment. The screen shows the selected temperature. Press AUTO for automatic control of air distribu- tion and other functions. The screen shows AUTO CLIMATE.
- Page 8 How is the trip computer operated? OK opens the trip computer's menus, activates selected option and extinguishes messages. Thumbwheel scrolls between the trip computer options. RESET resets data in the selected trip computer step and goes back in the menu structure. How do I reset the trip meter? Turn the left-hand stalk switch thumbwheel to show or T2.
- Page 9 How do I switch on and off the Infotainment system? A short press activates the system. A long press (until the screen switches off) deactivates. To switch off the sound: Give a short press - the next press reactivates. Note that the whole of the Sensus system (including navigation* and phone functions*) is started/switched off at the same time.
- Page 10 What services do I get with Volvo ID*? Volvo ID is your personal ID registered to the car which can give you access to various services such as My Volvo web and the facility to send an address from the map service on the Internet directly to the vehicle.
- Page 11 How do I use apps when the car is connected to the Internet*? When the car is connected to the Internet, apps for music services, web radio, navigation services and simple web browsers can be used. Press the Connect button Apps and press OK/MENU in order to show Select...
- Page 12 How do I connect an external audio device? Connect an external device via the AUX or USB* inputs in the centre console's storage compartment. In the normal view for the media source, press MEDIA in the centre console. Turn TUNE to the desired audio source and press OK/MENU.
- Page 13 Under Service & repair is information about your chosen workshop that you registered in the My Volvo web portal. Dealer information there is the option to call and send a booking request to the workshop (also available via My Volvo web).
- Page 14 Leather requires regular care in order to maintain appea- rance. For this reason, the leather upholstery should be treated using the Volvo Leather Care kit 1-4 times per year. The Volvo Leather Care kit is available for purchase from a Volvo dealer.
- Page 15 Where are the storage spaces located? Shown here are some of the car's storage spaces. The owner's manual shows the location of more storage spaces. Where are the AUX/USB* and 12 V sockets located? The remote control key must be at least in key position I in order for the 12V sockets in the passenger compartment to work.
- Page 16 How do I start or switch off the engine? After a cold start the idling speed is high irrespective of outside temperature. It is part of Volvo's efficient emissions system. During cold starting, certain diesel engines have a delayed start due to preheating.
