31/Xx10 - 31/Al - Volvo V70 2014 Wiring Diagram

Ground connections

31/XX10 - 31/AL

31/XX10 LH wheel housing 1
3/10 Reversing light contact
3/282 Switch indicator 1st gear, I5D
4/28 Transmission Control Module (TCM)
4/46 Engine Control Module (ECM)
4/109 Glow plug control module
6/73 Coolant pump
6/139 Upper actuating motor, intake manifold
6/140 Lower actuating motor, intake manifold
6/179 Electric oil pump
7/200 Sensor, coolant temperature
7/243 Gear position sensor neutral position
8/3 Electromagnetic clutch, climate control system, 4-Cyl.
8/78 Pressure monitor power steering, 4-Cyl. Turbo
9/32 PTC resistor, crankcase ventilation
9/38 Electrically heated fuel filter, 4-Cyl. Diesel
20/3-6 Spark plug with ignition coil, 4-Cyl. Turbo
31/XX14 LH wheel housing 3 (ABS)
4/16 Brake Control Module (BCM)
31/TRM Accessories
2/141 Refrigeration box relay
4/131 Control module back massage left
4/110 Trailer Module (TRM), Accessory
4/133 Control module back massage right
9/24 Refrigeration box
17/19 12 V outlet, cargo compartment
10/288 Lighting, overhead console
17/37 4-pin outlet, tow hitch cable harness
17/38 7-pin outlet, tow hitch cable harness
17/39 13-pin outlet, tow hitch cable harness
31/INFOT Infotainment
16/105 Audio module (AUD)
16/159 Control module, cellular phone handsfree, LHD
31/AL Auxiliary lights
10/65 Auxiliary light, front right
10/69 Auxiliary light, front left
TP 39264202 V70(08-), XC70(08-) & S80(07-) 2014 © Volvo Car Corporation 2013 43
