Volvo V70 2014 Wiring Diagram page 41

Ground connections
31/84 - 31/90
31/84 Bottom rail, right
3/271 Contact, immobilizer, clutch pedal, RHD
3/281 Infotainment control module (ICM), LHD
3/284 Diagnostic contact, brake light, RHD
4/56 Central Electronic Module (CEM), LHD
7/51 Accelerator pedal sensor, RHD
7/93 Occupant Weight Sensor (OWS), LHD
7/175 Weight sensor passenger seat, seat belt reminder, RHD
8/51 Igniter side airbag front driver's seat, RHD
16/1 Integrated Audio Module (IAM)
16/36 Television module (TVM)
16/109 DVD player/control module
16/123 Auxiliary equipment input (AUX)
16/145 Remote Digital Audio Receiver (RDAR)
16/162 Digital Audio Broadcast Module (DABM)
31/88 Engine ignition coils
20/3 Spark plug with ignition coil, 4-Cyl. Turbo
Spark plug with ignition coil, 5-Cyl. Turbo
Spark plug with ignition coil, 6-Cyl.
20/4 Spark plug with ignition coil, 4-Cyl. Turbo
Spark plug with ignition coil, 5-Cyl. Turbo
Spark plug with ignition coil, 6-Cyl.
20/5 Spark plug with ignition coil, 4-Cyl. Turbo
Spark plug with ignition coil, 6-Cyl. Turbo
20/6 Spark plug with ignition coil, 4-Cyl. Turbo
Spark plug with ignition coil, 6-Cyl. Turbo
31/89 Engine ignition coils
20/5 Spark plug with ignition coil, 5-Cyl. Turbo
Spark plug with ignition coil, 6-Cyl.
20/6 Spark plug with ignition coil, 5-Cyl. Turbo
Spark plug with ignition coil, 6-Cyl.
20/7 Spark plug with ignition coil, 5-Cyl. Turbo
Spark plug with ignition coil, 6-Cyl.
Spark plug with ignition coil, 6-Cyl. Turbo
20/8 Spark plug with ignition coil, 6-Cyl.
Spark plug with ignition coil, 6-Cyl. Turbo
20/16 Capacitor, 6-Cyl.
31/90 Engine ignition coils
20/3 Spark plug with ignition coil, 6-Cyl. Turbo
20/4 Spark plug with ignition coil, 6-Cyl. Turbo
20/16 Capacitor, 6-Cyl. Turbo
TP 39264202 V70(08-), XC70(08-) & S80(07-) 2014 © Volvo Car Corporation 2013 41
