Distribution Box In Engine Compartment, Cold Zone F1-Mf2 - Volvo V70 2014 Wiring Diagram

Fuses

Distribution box in engine compartment, cold zone F1-MF2

15/37
15/37 Distribution box cold zone in engine compartment, Start/Stop function
No. No. Fuse function
F1 11A/1 9/42
F2 11A/2 4/56
F3 11A/3 2/88
11C/21-11C/22
F4 11A/4 2/193
11C/23-11C/30
F5 11A/5 15/32
F6 11A/6 4/31
6/28
F7 11A/7 Spare
F8 11A/8 Spare
F9 11A/9 6/25
F10 11A/10 Diode D1
F11 M11 Secondary battery
F12 11B/12 4/56
MF1 MF1 11A/1-11A/8
MF2 MF2 11A/1-11A/8
TP 39264202 V70(08-), XC70(08-) & S80(07-) 2014 © Volvo Car Corporation 2013
F9 D1 R1
2/166
PTC-element
Central Electronic Module (CEM)
Relay, 15-feed rear
Fuses in distribution box passenger compartment
Relay, comfort functions
Fuses in distribution box passenger compartment
Distribution box in cargo compartment
Passenger compartment fan control module
Motor, passenger compartment fan
Starter motor
Central Electronic Module (CEM)
Main fuses in distribution box in
engine compartment (15/31)
Fuses in distribution box in cold zone
engine compartment (15/37)
MF1
MF2
R2
F10 F11 F12 2/246
F1 F2 F3 F4 F5 F6
I013222
via A
- 100
- 50
- 60
2/193
- 60
2/88
- 60
- 40
-
- -
- -
2/35 30
- 50
2/246 70
- 15
- 175
- 175
29
