Group 37 Wiring and fuses
Diagnostics system
73/4017
73/4016
31/83
TP 39264202 V70(08-), XC70(08-) & S80(07-) 2014 © Volvo Car Corporation 2013
RHD
BK
LHD
BK
BK-WH
73/4012
73/4002
31/10
1
11A/1
2
4/56
C5:1
C1:31 CEM
CAN
C1:30
LIN
C3:7
C3:6
MIDSPEED
73/4001
73/4037
3 4 5 6
CAN
16
11 14
30+
15/31
1
11A/2
2
C5:2
1
F16
2
C3:68
73/4038
138
