Qc Tracking Menu - Awareness Technology CHROMATE Operator's Manual

5.5 QC Tracking Menu

QC Tracking enables Controls and Calibrators to be tracked using a Levey-Jennings chart.
1
2
3
Search by Assay or Name.
Choose an Assay, choose a name, or choose a Lot # from the drop down
menus.
Edit QC points by clicking on an item in the list and highlighting it.
The curve may be viewed by Absorbance or Concentration results.
Data can be printed from this screen by pressing the Print QC Report button.
NOTE: Lot numbers are entered in the tab labeled Lot # Registration.
Edit by selecting the Select QC Points button or by un-checking the checkbox for
specific QC points.
Select the Save QC Points button to save the QC points displayed.
ChroMate
6 7
Figure 5.5-1 QC Tracking Example
Feature / Description:
Microplate Reader Operator's Manual Doc. 4300 Rev. Q
®
4 5
Steps:
1
2
3
4
5
6
7
65
