Volvo XC60 2010 Wiring Diagram page 158

Connectors
74/407 Alternative 2 - 74/407B
74/407 Alternative 2
16-pin green
No. Infotainment harness
1 74/407B:1 Connector
2 74/407B:2 Connector
3 74/407B:3 Connector
4 74/407B:4 Connector
5 74/407B:5 Connector
6-8 -
9 74/407B:9 Connector
10 74/407B:10 Connector
11 74/407B:11 Connector
12 74/407B:12 Connector
13 74/407B:13 Connector
14-16 -
74/407B
16-pin green
No. Infotainment harness
1 16/105C1:1 Audio module (AUD)
2 16/105C1:2 Audio module (AUD)
3 16/105C1:3 Audio module (AUD)
4 16/105C1:4 Audio module (AUD)
5 16/105C1:5 Audio module (AUD)
6 -
7 -
8 -
9 16/105C1:9 Audio module (AUD)
10 16/105C1:10 Audio module (AUD)
11 16/105C1:11 Audio module (AUD)
12 16/105C1:12 Audio module (AUD)
13 16/105C1:13 Audio module (AUD)
14 -
15 -
16 -
74/507:23
GY-BK
GY 74/409:10
YE-BK 74/508:23
74/509:4
GY-RD
74/510:4
YE-RD
- -
GN-BK 74/507:22
74/409:9
GN
VT-BK 74/508:22
GN-RD 74/509:3
74/510:3
VT-RD
-
-
GY-BK 74/407:1
GY 74/407:2
YE-BK 74/407:3
74/407:4
GY-RD
YE-RD 74/407:5
- -
-
-
-
-
GN-BK 74/407:9
74/407:10
GN
74/407:11
VT-BK
GN-RD 74/407:12
VT-RD 74/407:13
-
-
- -
- -
TP39133202 XC60 2009
Floor harness
Connector
Connector
Connector
Connector
Connector
Connector
Connector
Connector
Connector
Connector
Floor harness
Connector
Connector
Connector
Connector
Connector
Connector
Connector
Connector
Connector
Connector
GY-BK
GY
YE-BK
GY-RD
YE-RD
-
GN-BK
GN
VT-BK
GN-RD
VT-RD
-
GY-BK
GY
YE-BK
GY-RD
YE-RD
-
-
-
GN-BK
GN
VT-BK
GN-RD
VT-RD
-
-
-
158
