Introduction

Smokemeter

The smokemeter houses the measurement components of OmiSmoke.
1
OM0382
1. Receiver optics cover
2. Air intake
3. 4-pin XLR power connector
4. 5-pin XLR handset connector
5. Fuse
6. Power switch
7. Transmitter optics cover
8. Carry handle
9. Exhaust measuring chamber
8
2
8
3
9
7
4
5
6
