Introduction

Engine oil temperature sensor probe

OM0373
Category A tests prefer the measurement of the test vehicle's engine temperature.
The engine temperature sensor probe measures engine oil temperature in the sump
of the test vehicle, providing an accurate reading of the temperature of the engine.
The probe connects to the OmiSmoke handset using the Oil Temperature Probe
socket.
To monitor the engine temperature of the vehicle after it's warm-up period, prior to an
emissions test, the sensor probe must be inserted into the engine oil dipstick
aperture. First remove and clean the engine oil dipstick of the vehicle.
NEVER insert the probe into the dipstick aperture without first setting the
depth gauge, and take care not to insert the probe any further than the
gauge allows. Serious damage to the engine could result.
