  • Page 1 700 Series Installation Instructions TES1589/B Dec 2010...
  • Page 2 The information in these Operating Instructions is subject to change without notice, and does not represent a commitment on the part of Crypton Ltd Service & Warranty The reliability of this equipment is fully supported by our service agents, with repair workshops and field service engineers to provide a full range of After-Sales Care, including installation, contract maintenance, factory overhaul and emergency repairs on site.
  • Page 3: Table Of Contents

    700 Series Installation Instructions TES1589 Iss.B Page 3 CONTENTS HEALTH AND SAFETY INTRODUCTION FITTING THE KEYBOARD AND MOUSE FITTING THE MONITOR FITTING THE CABLE HOOKS OIL TEMPERATURE PROBES BATTERY TACHOMETER OPTIONAL EQUIPMENT REMOTE INDICATOR HANDSET ACOUSTIC TACHOMETER INFRA RED KEYBOARD...
  • Page 4: Health And Safety

    700 Series Installation Instructions TES1589 Iss.B Page 4 HEALTH AND SAFETY The equipment is not weatherproof and should not be used outside in rain or snow. The internal circuits and components of the analyser should not be tampered with. No internal parts are operator serviceable.
  • Page 5: Introduction

    700 Series Installation Instructions TES1589 Iss.B Page 5 INTRODUCTION This equipment leaves the factory set for 230V a.c. nominal, single phase 50/60 Hz. mains supply. Where the mains voltage differs from this, it is essential that the equipment is ordered for the specific voltage in your region.
  • Page 6: Fitting The Keyboard And Mouse

    700 Series Installation Instructions TES1589 Iss.B Page 6 FITTING THE KEYBOARD AND MOUSE To fit the Keyboard, Mouse and Monitor follow the procedure detailed below, observing the correct sequence of actions: Remove the back panel as shown in Fig. 1 by unscrewing the 6 earth nib Philips screws.
  • Page 7: Fitting The Monitor

    700 Series Installation Instructions TES1589 Iss.B Page 7 FITTING THE MONITOR Unpack the monitor and remove the four screws on the monitor mounting panel. Assemble the monitor to the bar mounted monitor bracket and secure using the four screws as shown in Fig. 4a. Fit the monitor signal lead and feed this through the monitor bracket, adjust tilt of screen as required and tighten in position.
  • Page 8: Fitting The Cable Hooks

    700 Series Installation Instructions TES1589 Iss.B Page 8 FITTING THE CABLE HOOKS Various cable hooks are provided for securing cables. Threaded inserts are fitted on each side and the rear of the unit for this purpose. Fit hooks using hardware provided (see Fig.
  • Page 9: Oil Temperature Probes

    700 Series Installation Instructions TES1589 Iss.B Page 9 OIL TEMPERATURE PROBES Depending on the model purchased you will have either a cabled or wireless version of the temperature probe. The Oil Temperature probe holster/recharging station is located on the top of the left side panel of the unit towards the rear. Fig 6a and 6b show the DX211-11 cabled probe connections.
  • Page 10: Optional Equipment

    Page 10 OPTIONAL EQUIPMENT A number of optional devices may be fitted for use with the 700 Series Emissions Analysers. Please refer to the Software and Hardware operating instructions for details. Wireless peripherals requires the use of wireless enabled equipment to operate. The wireless receiver will be situated in the upper USB port on the PC front panel.
  • Page 11: Connecting To The Mains Power Supply

    700 Series Installation Instructions TES1589 Iss.B Page 11 CONNECTING TO THE MAINS POWER SUPPLY The equipment should be connected to the mains power supply via the mains cable supplied with the equipment. This equipment leaves the factory set for 230V a.c. nominal, single phase 50/60 Hz.
  • Page 12: Operating System

    After switch on, the computer will perform the start up sequence and the Windows® XP desktop will be displayed as shown below. The 700 Series is controlled by means of ‘icons’ on the desktop. Each application is accessed by double clicking on the individual icon for that application. The desktop will only show the programs associated with the particular model you have purchased and may not display all the programs shown below.
  • Page 13: Operators Manuals

    700 Series Installation Instructions TES1589 Iss.B Page 13 OPERATORS MANUALS Double click to open a folder containing Operators Manuals in Adobe Portable Document Format. Clicking on any manual will open it in Adobe Acrobat Reader. INSTALL/UPDATE SOFTWARE Double click to run a program called Install.exe or Setup.exe for a disk placed in the disk drive.
  • Page 14: After Sales Service

    For details of local service agents please call: Email: support@cryptontechnology.com Fax: +44 (0) 844 665 7604 Crypton Ltd. Hopton Industrial Estate, London Road, Devizes, Wiltshire, SN10 2EU Tel: +44 (0) 844 665 7613 Fax: +44 (0) 844 665 7604 Email: sales@cryptontechnology.com...
