Dakota 42
Dakota 42H
Important operating and
maintenance instructions
included.
WARNING: If the information in these
instructions is not followed exactly, a fire
or explosion may result causing proper-
ty damage, personal injury, or death.
• Do not store or use gasoline or other flamma-
ble vapors and liquids in the vicinity of this or
any other appliance.
• What to do if you smell gas
- Do not try to light any appliance
- Do not touch any electrical switch. Do not
use any phone in your building.
- Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
- If you cannot reach your gas supplier, call
the fire department.
• Installation and service must be performed by
a qualified installer, service agency, or the gas
supplier.
Note: This appliance must be installed outside.
CAUTION
DO NOT DISCARD THIS MANUAL
Read, understand and follow
these instructions for safe
installation and operation.
Owner's Manual
Installation and Operation
Leave this manual with
party responsible for
use and operation.
WARNING
HOT! DO NOT TOUCH.
SEVERE BURNS MAY RESULT.
CLOTHING IGNITION MAY RESULT.
Glass and other surfaces are hot during
operation and cool down.
• Keep children away.
• CAREFULLY SUPERVISE children in same room as
appliance.
• Alert children and adults to hazards of high
temperatures.
• Keep clothing, furniture, draperies and other
combustibles away.
This appliance has been supplied with an integral barrier
to prevent direct contact with the fixed glass panel. Do
NOT operate the appliance with the barrier removed.
Contact your dealer or Hearth & Home Technologies if the
barrier is not present or help is needed to properly install one.
Installation and service of this appliance should be
performed by qualified personnel. Hearth & Home
Technologies suggests NFI certified or factory-trained
professionals, or technicians super-
vised by an NFI certified professional.
4036-905 REV. F
11/04

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LifeStyle Collection Dakota 42 and is the answer not in the manual?

Questions and answers

Summary of Contents for Heat-N-Glo LifeStyle Collection Dakota 42

  • Page 1 Owner’s Manual Installation and Operation Models: Dakota 42 Dakota 42H CAUTION DO NOT DISCARD THIS MANUAL • • • Important operating and Read, understand and follow Leave this manual with maintenance instructions these instructions for safe party responsible for included. installation and operation.
  • Page 2 5,218,953; 5,328,356; 5,429,495; 5,452,708; 5,542,407; 5,613,487; (Australia) 543790; 586383; (Canada) 1,123,296; 1,297,746; 2,195,264; (Mexico) 97-0457; (New Zealand) 200265; or other U.S. and foreign patents pending (ou autres brevets americains et etrangers en attente). Gas and Electric Model Number Information Heat-N-Glo LifeStyle Collection • Dakota 42, Dakota 42H • 4036-905 Rev. F • 11/04...
  • Page 3: Table Of Contents

    C. Warranty ............32 Section 7: Electrical Information D. Contact Information ........33 A. Recommendation for Wire ......13 B. Connecting to the Appliance ......13 C. Intellifire Ignition System Wiring ....13 Heat-N-Glo LifeStyle Collection • Dakota 42, Dakota 42H • 4036-905 Rev. F • 11/04...
  • Page 4: Listing And Code Approvals Section

    National Fuel Gas Code, ANSI Z223.1-latest edition in the U.S.A. and the CAN/CGA B149 Installation Codes in Canada. Heat-N-Glo LifeStyle Collection • Dakota 42, Dakota 42H • 4036-905 Rev. F • 11/04...
  • Page 5: Getting Started

    Hearth & Home Technologies. Tape measure Level Any such action may cause a fire hazard. Non-corrosive leak check solution 1/2 - 3/4 inch length, #6 or #8 Self-drilling screws Heat-N-Glo LifeStyle Collection • Dakota 42, Dakota 42H • 4036-905 Rev. F • 11/04...
  • Page 6: Selecting Appliance Location

    • Do NOT infringe on building’s warm air envelope. • If fireplace is installed into exterior wall of build- ing, the surface surrounding it must be exterior wall system. Figure 3.1 Framing Dimensions Heat-N-Glo LifeStyle Collection • Dakota 42, Dakota 42H • 4036-905 Rev. F • 11/04...
  • Page 7: Clearances

    48 inches. Figure 3.3 Clearances to Mantels or other Combustibles above Appliance Heat-N-Glo LifeStyle Collection • Dakota 42, Dakota 42H • 4036-905 Rev. F • 11/04...
  • Page 8: Termination Locations

    CAUTION: IF EXTERIOR WALLS ARE FINISHED WITH VINYL SIDING, IT IS NECESSARY TO INSTALL THE VINYL PROTECTOR KIT TO THE TOP OF THE EXTERIOR FIRESTOP (FOR ALL ROUND TERMINATION CAPS). IT IS STRONGLY RECOMMENDED WHENEVER POSSIBLE TO USE THE VINYL PROTECTOR KIT. Heat-N-Glo LifeStyle Collection • Dakota 42, Dakota 42H • 4036-905 Rev. F • 11/04...
  • Page 9: Appliance Preparation

    Door operation NAILING TABS (BOTH SIDES) Figure 5.2 Proper Positioning, Leveling and Securing of a Appliance CAUTION Do NOT notch into the framing around the appliance spacers. Heat-N-Glo LifeStyle Collection • Dakota 42, Dakota 42H • 4036-905 Rev. F • 11/04...
  • Page 10: Gas Information

    Manifold 3.5 inches 10.5 inches Pressure w.c. w.c. These pressures can be verified through the internal valve access panels as shown on the following page. Heat-N-Glo LifeStyle Collection • Dakota 42, Dakota 42H • 4036-905 Rev. F • 11/04...
  • Page 11: Valve Access

    Reverse these steps to reassemble before log positioning. Figure 6.3 Remove the inside valve access panel by lifting it up and out. Heat-N-Glo LifeStyle Collection • Dakota 42, Dakota 42H • 4036-905 Rev. F • 11/04...
  • Page 12 Do NOT change the valve settings. • This valve has been preset at the factory. • Changing valve settings may result in fire hazard or bodily injury. Heat-N-Glo LifeStyle Collection • Dakota 42, Dakota 42H • 4036-905 Rev. F • 11/04...
  • Page 13: Electrical Information

    • Low voltage and 110 VAC voltage cannot be shared within trols. Wiring errors can cause improper and dangerous the same wall box. operation. Verify proper operation after servicing. Heat-N-Glo LifeStyle Collection • Dakota 42, Dakota 42H • 4036-905 Rev. F • 11/04...
  • Page 14 MODULE BATTERY (3V) PACK GROUND TO FIREPLACE CHASSIS LOW VOLTAGE VALVE SEE NOTE 1 PIGGYBACK ON/OFF SWITCH Figure 7.1 Intellifire Pilot Ignition (IPI) Wiring Diagram VALVE Heat-N-Glo LifeStyle Collection • Dakota 42, Dakota 42H • 4036-905 Rev. F • 11/04...
  • Page 15: Finishing

    • Seal joints between the finished wall and appliance top and sides using only a 300 F minimum sealant. Heat-N-Glo LifeStyle Collection • Dakota 42, Dakota 42H • 4036-905 Rev. F • 11/04...
  • Page 16: Appliance Setup

    • Do NOT place embers directly over burner ports. • Replace ember material annually. Improperly placed embers interferes with proper burner operation. Figure 9.2 Placement of Lava Rocks Heat-N-Glo LifeStyle Collection • Dakota 42, Dakota 42H • 4036-905 Rev. F • 11/04...
  • Page 17: Positioning The Logs

    Place Front Left Log on the grate with the left side of the log against the left front grate tine. The right side of the log will angle toward the center of the grate. Heat-N-Glo LifeStyle Collection • Dakota 42, Dakota 42H • 4036-905 Rev. F • 11/04...
  • Page 18: Glass Assembly

    • To adjust handle, loosen screws to move handles as necessary and tighten screws. Glass Specifications Dakota 42: Tempered Dakota 42L: Tempered Dakota 42H: Tempered Dakota 42HL: Tempered Heat-N-Glo LifeStyle Collection • Dakota 42, Dakota 42H • 4036-905 Rev. F • 11/04...
  • Page 19: Operating Instructions

    • Alert children and adults to hazards of high temperatures. • Do NOT operate with protective barriers open or removed. • Keep clothing, furniture, draperies and other combustibles away. Heat-N-Glo LifeStyle Collection • Dakota 42, Dakota 42H • 4036-905 Rev. F • 11/04...
  • Page 20: Lighting Appliance

    Keep burner and control compart- ment clean. See installation and operating instructions accompany- ing appliance. Final Inspection by _________________________________ Heat-N-Glo LifeStyle Collection • Dakota 42, Dakota 42H • 4036-905 Rev. F • 11/04...
  • Page 21: After Appliance Is Lit

    In an Intellifire ignition system it is normal to see the pilot flame, but it should turn off burn continually? when ON/OFF is turned off. In a standing pilot system the pilot will always stay on. Heat-N-Glo LifeStyle Collection • Dakota 42, Dakota 42H • 4036-905 Rev. F • 11/04...
  • Page 22: Troubleshooting

    Verify that spark gap from ignitor to pilot hood is .17 in. or 1/8 in. c. Module is not grounded. Verify module is securely grounded to metal chassis of appliance. Heat-N-Glo LifeStyle Collection • Dakota 42, Dakota 42H • 4036-905 Rev. F • 11/04...
  • Page 23: Maintaining And Servicing Appliance

    • Restricted air flow affects burner operation. control compartment • Burner, burner ports Risk of: • Fire • Delayed ignition or explosion • Exposure to combustion fumes • Odors Heat-N-Glo LifeStyle Collection • Dakota 42, Dakota 42H • 4036-905 Rev. F • 11/04...
  • Page 24: Valve Service And Replacement

    Turn the gas ball valve off and disconnect the gas line after Remove the refractory side panel and set aside. the ball valve by loosening the flare nut using a 13/16” and a 15/16” wrench. Heat-N-Glo LifeStyle Collection • Dakota 42, Dakota 42H • 4036-905 Rev. F • 11/04...
  • Page 25 TUBE PILOT TUBE Figure 12.8 Disconnect the pilot and orifice tubes using a 7/16” and a 5/8” wrench. Reverse these steps to replace the gas valve. Heat-N-Glo LifeStyle Collection • Dakota 42, Dakota 42H • 4036-905 Rev. F • 11/04...
  • Page 26 2. Replace batteries in remote transmitters and battery-powered receivers. 3. Verify batteries have been removed from battery back-up IPI systems to prevent premature battery failure or leaking. Heat-N-Glo LifeStyle Collection • Dakota 42, Dakota 42H • 4036-905 Rev. F • 11/04...
  • Page 27: Reference Materials

    Dimensions are actual appliance dimensions. Use for reference only. For framing dimensions and clearances refer to Section 3. LEFT VIEW RIGHT VIEW Appliance Dimensions Inches 23-1/8 37-1/8 6-3/4 23-1/4 16-5/8 9-7/8 1067 1219 Figure 13. 1 Appliance Dimensions Heat-N-Glo LifeStyle Collection • Dakota 42, Dakota 42H • 4036-905 Rev. F • 11/04...
  • Page 28: Service Parts

    B. Service Parts Beginning Manufacturing Date: 4-04 (NG, LP) Exploded Parts Diagram Ending Manufacturing Date: ______ (GN, PL) Vue éclatée des pièces 28 29 30 28 27 Heat-N-Glo LifeStyle Collection • Dakota 42, Dakota 42H • 4036-905 Rev. F • 11/04...
  • Page 29 Access Panel Inner Shell 4036-137 Access Panel Intermediate Shell 4036-139 Replacement Grate GR34 Accessories Conversion Kit NG 4036-041 Conversion Kit LP 4036-042 5' Flexible Gas Line 4021-113 Heat-N-Glo LifeStyle Collection • Dakota 42, Dakota 42H • 4036-905 Rev. F • 11/04...
  • Page 30 B. Service Parts List (NG, LP) Exploded Parts Diagram Beginning Manufacturing Date: 4-04 (GN, PL) Vue éclatée des pièces Ending Manufacturing Date: ______ Log Set Assembly Heat-N-Glo LifeStyle Collection • Dakota 42, Dakota 42H • 4036-905 Rev. F • 11/04...
  • Page 31 4036-703 Log, Front Right 4036-702 Log Set - Box 3 4036-699 Log, Left Center 4036-705 Log, Right Center 4036-704 Fiber Ash Bed 4036-730 Lava Rock 28911 Heat-N-Glo LifeStyle Collection • Dakota 42, Dakota 42H • 4036-905 Rev. F • 11/04...
  • Page 32: Warranty

    Subject to the conditions set forth herein, HEARTH & HOME TECHNOLOGIES INC. (HHT) extends the following limited warranty with respect to your Heat-N-Glo fireplace, excluding accessories, chimney components and glass doors. If HHT is satisfied that any part or portion of the fireplace covered by this warranty is defective in material or workmanship...
  • Page 33: Contact Information

    6237588, 6296474, 6374822, 6413079, 6439226, 6484712, 6543698, 6550687, 6601579, 6672860, 6688302B2, 6715724B2, 6729551, 6736133, 6748940, 6748942, D320652, D445174, D462436; (Canada)1297749, 2195264, 2225408; or other U.S. and foreign patents pending. Printed in U.S.A. - Copyright 2004 Heat-N-Glo LifeStyle Collection • Dakota 42, Dakota 42H • 4036-905 Rev. F • 11/04...
