UniFocus Time Clock Installation & Mounting Manual page 4

Desktop Mount Assembly Instructions
Please be sure your mount kit has the following parts:
ITEM PART
NO. NUMBER
1 PT81000A
2 PT81000B
3 PT81000C
4 PT81000D STUDDED ADJUSTMENT PLATE
5 PT81000E PERFORATED ADJUSTMENT PLATE
6 PT81000F
7
M4 X 0.7 X 8 PAN HEAD MACHINE
8
SCREW, PHILLIPS, ZINC, STEEL
Place the PC face down on a
protected/padded surface.
Place the Cord Guard over the
cords and align with the holes on
the Mount Plate.
A
Insert the tabs from both Studded (part
#4) and Perforated (part #5) Adjustment
Plates into the large slots in position
A&B above. Be sure to keep the stud
facing inward.
3
DESCRIPTION
BASE MOUNT
MOUNT PLATE
CORD GUARD
TENSION KNOB
14" ZIP TIE
Place the Mount Plate as you see above. Be
sure the TABS are pointed up. Install screws
in the 4 positions noted.
Secure the Cord Guard by installing two
screws on the back side of the Mount Plate.
B
Depending on the preferred angle, insert
the stud into one of the three holes on the
Perforated Adjustment Plate. These Plates
are designed to be a tight fit, you may
need assistance.
QTY
1
1
1
1
1
1
2
8
4 5
Tabs
Screws
PRESS FIRMLY
1
6 8
Run cables through the cut-outs in
the Mount Plate before installing
Cord Guard.
Insert the Base Mount: Align the two
tabs with the two slots in the Base
Mount.
Holding the plates firmly, attach the
Tension Knob and tighten. The Procare
Touch 8 Mount should now be tight and
firm.
See: Optional Power Brick installation (page 4)
2
3
7
