UniFocus Time Clock Installation & Mounting Manual page 2

Wall/Angle Mount Assembly Instructions
Note: There are three sets of instructions for alternate mount installation.
Please read instructions thoroughly before you begin.
Please be sure your mount kit has the following parts:
ITEM PART
NO. NUMBER
1 PT81000A
2 PT81000B
3 PT81000C
4 PT81000D STUDDED ADJUSTMENT PLATE
5 PT81000E PERFORATED ADJUSTMENT PLATE
6 PT81000F
7
M4 X 0.7 X 8 PAN HEAD MACHINE
8
SCREW, PHILLIPS, ZINC, STEEL
Wall
Begin with the Base Mount
securely fastened to the wall.
(fasteners not included)
Lift the PC/Mount Plate as
shown. Insert the TABS into
the slots at the top of the Base
Mount attached to the wall.
Secure the two plates using
the Tension Knob. These
plates are designed to be a
tight fit, you may need
assistance.
1
DESCRIPTION
BASE MOUNT
MOUNT PLATE
CORD GUARD
TENSION KNOB
14" ZIP TIE
Position the PC face down on a
protected/padded surface.
Once both TABS are fully
inserted, lower the PC at an
angle. For safety, do not leave
the PC "hanging" on the
Mount Plate TABS.
Run cables through the
cut-outs in the Mount Plate
before installing Cord Guard.
1
QTY
1
1
1
1
1
1
2
5
4
8
Install the Perforated Adjust-
ment Plate (part #5) to the
Mount Plate as shown.
Place the Cord Guard over the
cords and align with the holes
on the Mount Plate.
2
3
7
6 8
Tabs
Place the Mount Plate as you see
above. Be sure the TABS are pointed
up. Install screws in the 4 positions
noted.
Install the Studded Adjust-
ment Plate (part #4) to the
Base Mount. Select 1 of 3
angles by inserting the stud
into one of the 3 holes.
Secure the Cord Guard by
installing two screws on the
back side of the Mount Plate.
See: Optional Power Brick installation (page 4)
Screws
