- Page 1 CA630 Fall Management System User Guide 0510-1116-C Released 10/16/14...
- Page 2 Copyright 2013, 2014 by RF Technologies, Inc. All Rights Reserved. No Part of this work may be reproduced or copied in any form or by any means without written permission from RF Technologies, Inc. Classifications The following information can be found on the back label of the CA630 control unit.
- Page 3 RF Technologies, Inc. for set up and use. Do not attempt to use extension cords or other equipment not supplied by RF Technologies, Inc.
- Page 4 RF Technologies, Inc. representative. To arrange for a quarterly inspection by RF Technologies, Inc., call our Technical Support Department at (800)-669-9946 or (262) 790-1771. Failure to provide regular inspection of these products may result in equipment and/or...
- Page 5 Series Software Administrator Guide. This includes regular inspection, testing, and cleaning. RF Technologies, Inc. recommends monthly maintenance and testing of your system. It is also recommended that your facility keep records of maintenance and test completions.
- Page 6 (2) this device must accept any interference received, including interference that may cause undesired operation. RF Technologies prohibits changes or modifications to the product; this may void the user’s authority to operate the equipment (FCC Code of Federal Regulations Title 47 Part 15.21).
-
Page 7: Table Of Contents
Contents Contents Contents Contents CONTENTS ..................... 1 PREFACE ....................3 ..................3 VERVIEW CA630 .................... 3 ................3 NTENDED UDIENCE ........... 4 DDITIONAL ETAILED OCUMENTATION ............... 4 ONTACT NFORMATION CHAPTER 1 ..................... 5 ................5 YSTEM VERVIEW ................... 6 ONTROL .............. - Page 8 Contents Contents CHAPTER 4 ................... 17 ..............17 ARING YSTEM ............17 ROUBLESHOOTING YSTEM ............... 18 ESTING YSTEM ........... 19 PERATING AND TORAGE ONDITIONS Pads ..................19 Control Unit ................19 ................. 20 ERVICE AND ETURN ..................21 UPPLIES ................22 RODUCT ARRANTY Page 2 of 23...
-
Page 9: Preface
Preface Preface Preface Preface Overview This guide provides important information about the Code Alert CA630 System, a component of the Fall Management System. It provides detailed instructions about using the CA630 as well as specific requirements. CA630 The CA630 provides restraint-free monitoring of a resident who may try to leave a bed or chair without assistance. -
Page 10: Additional Detailed Documentation
Preface Preface Additional Detailed Documentation Documentation for the system is available in Portable Document Format (PDF). Please contact your RF Technologies sales representative to request a copy of documentation. Contact Information For more information about RF Technologies, Inc. products go to www.rft.com. -
Page 11: Chapter 1
The control unit, sensor pad and accessories function as a stand-alone system or can be configured to interface with RF Technologies software version 7.0.8.2 and above. When interfaced with the software, a Fall alarm is activated in response to the applicable event. -
Page 12: Control Unit
CHAPTER 1 System Overview Control Unit The control unit is designed to fit inside a silicone protective covering (Protective Boot) to minimize damage from dropping and electro-static discharge. It also includes an attachment strap for mounting the control unit to a bed or chair. Protective Boot Hold Button Volume Indicator Lights... -
Page 13: Control Unit Buttons
Control Unit Jacks WARNING: Do not plug anything into the respective jacks other than RF Technologies’ approved pads, cables and adapters (refer to the Supplies section). Doing so will void the warranty. Nurse Call Adapter Power Supply... - Page 14 CHAPTER 1 System Overview POWER SUPPLY JACK— Connect the optional AC Adapter for continuous use. WARNING: Use 9V battery as a source of backup power when using the optional AC Adaptor to reduce inadvertent power loss to the control unit. NURSE CALL JACK —If using the control unit for Nurse Call, connect the Nurse Call modular jack cable.
-
Page 15: Chapter 2
CHAPTER 2 Set Up CHAPTER 2 Set Up Setting Up The System : When positioning the control unit, ensure that the speaker holes and indicator lights are not covered. Visually inspect the sensor pad and sensor pad wires for damage. If damaged, replace the damaged pad before proceeding. - Page 16 CHAPTER 2 Set Up To the Admit Information window opens for you to enter admit information. Enter resident information; the yellow fields designate required entry. Select the Transmitters tab. NOTE: The Transmitter tab only appears if the Quick Response Premiere is licensed. Page 10 of 23 CA630 In-Service Manual 0510-1116-C...
- Page 17 CHAPTER 2 Set Up Select the Transmitter ID number (printed on device) from the pull- down. Click Add. The transmitter will appear under the Transmitters Assigned field. The Select Type field is populated with Fall Monitoring. For the CA630, the Supervised time defaults to the unit’s Transmitter Supervise Time, set during configuration.
-
Page 18: Fall Alert
CHAPTER 2 Set Up Fall Alert Refer to the instructions on the Sensor Pad for placement of the pad on the bed or chair. Connect the Sensor Pad to the control unit and position the resident on the pad. The control unit beeps once and the green light flashes every 2 seconds to indicate the system is monitoring. -
Page 19: Chapter 3
Select an Event Cause. Chart the event per your facility’s policies and procedures. : If the Enforce Joint Commission feature is activated in the RF Technologies’ software, you must select an Event Cause once the alarming device has been reset. -
Page 20: Nurse Call
CHAPTER 3 Responding to Alarms Nurse Call When a resident pushes the plunger on the Nurse Call cord, an Assistance Required alarm is generated. The control unit beeps twice every 2 seconds to alert caregivers. A green status indicator light flashes in conjunction with the beeps for a visual alert. -
Page 21: Low Battery
CHAPTER 3 Responding to Alarms Low Battery NOTE: A fully charged battery may last approximately 30 days when using one sensor (i.e. Fall Alert). Additionally, monitoring activity and battery condition will shorten operational life of the battery. When the battery on the control unit is low, the red light flashes every 10-seconds, the control unit beeps in conjunction with the flashes and a yellow Low Battery alarm appears on theClient computer. - Page 22 CHAPTER 3 Responding to Alarms This page intentionally left blank. Page 16 of 23 CA630 In-Service Manual 0510-1116-C...
-
Page 23: Chapter 4
CHAPTER 4 Maintenance CHAPTER 4 Maintenance Caring For Your System Do not immerse the control unit in liquid; dry clean with alcohol wipe. Do not carry or move the control unit or the sensor pad by the cable(s). : Remove the 9-volt alkaline battery from the control unit if the CA630 Fall Management System will not be used for a prolonged period. -
Page 24: Testing Your System
CHAPTER 4 Maintenance If the control unit indicates an Assistance Required alarm, but the button on the nurse call cord set is in the reset position, check the connection between the nurse call cord set and the adaptor cable. The ¼” plug on the end of the nurse call cord set must be fully engaged with the mating jack of the adaptor cable (see figures below). -
Page 25: Operating And Storage Conditions
CHAPTER 4 Maintenance Operating and Storage Conditions Pads Pads must be stored properly to prevent damage. Store flat. Do not fold or store other items on top of pads. Pads have a limited life; mark each pad with the WARRANTY EXPIRES date. Control Unit Store control unit at the following temperature and relative humidity. -
Page 26: Service And Return
CHAPTER 4 Maintenance Service and Return Do not attempt to service or repair the CA630 System; there are no serviceable parts inside the control unit or the sensor pad. Any attempt at servicing or repairing the product voids the warranty. If you encounter problems with your equipment, please contact RF Technologies for assistance. -
Page 27: Supplies
CHAPTER 4 Maintenance Supplies Sensor pads are disposable, intended for single-resident use, and warranted for 7, 30, 90 or 180 days, which is the limited expected useful life. You must record the date the warranty expires in the area provided on the label. You must not use the sensor pad after the warranty has expired. -
Page 28: Product Warranty
CHAPTER 4 Maintenance Product Warranty RF Technologies, Inc. (herein referred to as “Seller”), warrants to the Buyer that during the warranty period (defined below) the RF Technologies, Inc. products (herein referred to as “Product”) will be free from manufacturing defects and will conform to the Seller’s product specifications. - Page 29 CHAPTER 4 Maintenance process, software patches, software, or equipment not sold or provided by Seller, (7) acts of God, acts of civil or military authority, fires, floods, strikes, or other labor disturbances, war, riot, or other causes beyond the reasonable control of the Seller, (8) damage due to moisture, dust, dirt, and facility renovations, (9) unregulated and or out of specification electric power, temperature, humidity, or (10) radio frequency interference in the Product’s...
