Page 2
Copyright Alle informatie in dit technische document, evenals de tekeningen en technische beschrijvingen beschikbaar gesteld door Cleopatra B.V., blijven het eigendom van Cleopatra B.V. en mogen niet worden gekopieerd zonder toestemming. Cleopatra B.V. behoudt het recht voor om wijzigingen aan te brengen in het belang van verdere ontwikkelingen.
Waarschuwingen Zonder toestemming en zonder aanwijzingen is het gebruik van de stoomcabine voor de volgende personen verboden: - Kinderen - Volwassenen met beperkingen - Personen die niet geïnstrueerd zijn, over waar de stoomcabine voor bedoeld is. - Personen onder invloed mogen geen gebruik van de stoomcabine maken.
Bediening Kinderen mogen de stoomcabine alleen onder begeleiding gebruiken. Wanneer kinderen het apparaat gebruiken zonder begeleiding, wordt dit als oneigenlijk gebruik beschouwd. Gebruik alleen geurstoffen die bij de Voedsel en Waren Autoriteit bekend zijn. Voorbereiding De stoomgenerator moet volgens de aanwijzingen in de installatiehandleiding zijn aangesloten voordat het systeem wordt aangezet.
Bediening Stoom Afbeelding 2 Afbeelding 3 Afbeelding 4 Stoom functie (A): Druk toets A in om de stoomtoets te activeren (de toets is helder verlicht) of te deactiveren, de toets is niet verlicht (zie afbeelding 2). Druk nogmaals om de stoom aan /uit te zetten. Stoomcapaciteit aanpassen: Druk toets A in om de toets te activeren.
Bediening licht Afbeelding 5 Afbeelding 6 Verlichting activeren (B): Druk toets B in om de verlichtingstoets te activeren, de toets is helder verlicht, of te deactiveren, de toets is niet verlicht (zie afbeelding 5). Druk nogmaals om de verlichting aan /uit te schakelen.
Bediening van de geurstof dosering Afbeelding 7 Afbeelding 8 Afbeelding 9 Geurstof activeren (C): Druk toets C in om de geurstoftoets te activeren, de toets is helder verlicht, of te deactiveren, de toets is niet verlicht (zie afbeelding 7). Druk nogmaals om de geurstof in/uit te schakelen. De geurstof toevoer werkt niet gedurende de eerste 3 minuten van de stoomcyclus.
Storingen Een storing wordt gemeld door het display. Door het aantal LED’s welke oplichten te tellen, wordt duidelijk welke storing wordt gemeld. Hieronder een aantal voorbeelden: -Wanneer er 2 LED’s oplichten, code 2 -Wanneer er 5 LED’s oplichten, code 5 Om een storing te resetten, moet de stoomknop 5 seconden worden in gehouden.
Geurstof De Cleopatra stoombad geuren zijn hoogwaardige stoombad melken die zowel voor particulieren als door professionele partijen gebruikt worden. Aromatherapie gegarandeerd! De volgende geuren zijn verkrijgbaar: Eucalyptus (1 liter en 5 liter verpakking) Eucamint (1 liter en 5 liter verpakking)
7.1 Bijvullen van de geurstof (BackWall uitvoering) Trek de dop van de fles. Gebruik alleen producten die specifiek zijn ontwikkeld voor gebruik in stoomcabines. Lees de aanwijzingen op de verpakking aandachtig. Gebruik de bijgeleverde trechter om de Druk de dop weer op de fles. geurstof in te schenken.
7.2 Bijvullen van de geurstof Gebruik alleen producten die specifiek zijn Haal de slang naar de geurstof pomp ontwikkeld voor gebruik in stoomcabines. en de slang naar de stoomuitlaat uit het Lees de aanwijzingen op de verpakking reservoir. aandachtig. Slang naar de geurstof pomp Slang naar de stoominlaat Verwijder het reservoir van de houder.
Page 13
Bijvullen van de geurstof Meng de geurstof en water in de juiste Draai de dop weer op de fles. verhoudingen voordat deze in de tank wordt gegoten. Deze tank is 1 liter wat betekend: - Geurstof: 0.25 L - Water: 0.75 L Plaats het reservoir terug in de houder.
Onderhoud Stoomunit ontkalken: Kalkafzetting in de stoomunit kan de volgende gevolgen hebben: - Het duurt langer voordat de stoom in de cabine komt. - De cabine komt niet goed op temperatuur. - De stoomunit maakt een hard bubbelend geluid. Bij de bovenstaande symptomen is onderhoud aan de stoomunit gewenst. Vraag bij uw dealer naar de mogelijkheden.
Page 16
All information in this technical document, together with the drawings and technical specifications made available by Cleopatra B.V., remain the property of Cleopatra B.V. and may not be copied without permission. Cleopatra B.V. reserves the right to make changes in the interest of further developments.
Page 17
Table of contents User manual Warnings ......................18 Control ......................19 Steam control ......................20 Light control ......................21 Fragrance dispenser control ..................22 Defects ......................23 Fragrance ......................24 7.1 Refilling the fragrance (BackWall version) ............25 7.2 Refilling the fragrance..................26 Maintenance ......................28...
Warnings Without permission and without instructions, the use of the steam cabin is forbidden for the following persons: - Children. - Adults with disabilities. - Persons who have not been instructed about what the steam cabin is meant for. - Persons who are intoxicated. Bringing electrical devices in the cabin is forbidden! Warning hot surfaces.
Control Children may only use the steam cabin under supervision. When children use the device without supervision, this is considered improper use. Use only fragrances that are known from the Food and Consumer Product Safety Authority. Preparation The steam generator must be connected in accordance with the instructions in the installation manual before the system is switched on.
Steam control Image 2 Image 3 Image 4 Steam function (A): Press button A to activate the steam button (the button is lightened) or to deactivate, the button is not luminous (see image 2). Press again to turn the steam on / off. Adjust steam capacity: Press button A to activate the button.
Light control Image 5 Image 6 Activate lighting (B): Press button B to activate the light button, the button is lightened, or to deactivate, the button is not luminous (see image 5). Press again to turn the lighting on / off. Adjust lighting: Press button B to activate the button, then press buttons D / E to adjust the lighting.
Fragrance dispenser control Image 7 Image 8 Image 9 Activate fragrance dispenser (C): Press button C to activate the fragrance button, the button is lightened, or to deactivate, the button is not luminous (see image 7). Press again to turn the fragrance dispenser on / off. The fragrance supply does not work during the first 3 minutes of the steam cycle.
Defects A defect is shown on the display. By counting the number of LEDs that light up, it becomes clear which defect is reported. Below a few examples: -When 2 LEDs light up, code 2 -When 5 LEDs light up, code 5 To reset the defect, the steam button must be pressed for 5 seconds.
Fragrance The Cleopatra steam bath fragrances are high-quality steam bath milks that are used for both private and professional parties. Aromatherapy guaranteed! The following fragrances are available: Eucalyptus (1 liter and 5 liters) Eucamint (1 liter en 5 liters) Pine (1 liter)
7.1 Refilling the fragrance (BackWall version) Remove the cap from the bottle. Only use products that have been specifically developed for use in steam cabins. Read the instructions on the packaging accurately. Use the supplied funnel to pour in the Press the cap back on the bottle.
7.2 Refilling the fragrance Only use products that have been specifically Remove the hose to the fragrance pump developed for use in steam cabins. and the hose to the steam outlet from the Read the instructions on the packaging reservoir. accurately.
Page 27
Refilling the fragrance Mix the fragrance and water in the right Turn the cap back on the bottle. proportions before poured in the tank. This tank is 1 liter which means: - Fragrance: 0.25 L - Water: 0.75 L Return the reservoir in the holder. Return the hoses in the reservoir.
Maintenance Descaling the steam unit: Lime deposits in the steam unit can have the following consequences: - It takes longer for the steam to enter the cabin. - The cabin does not reach the right temparature. - The steam unit makes a loud bubbling sound. You steam unit has the symptoms above? Maintenance of the steam unit is desirable.
Page 30
Wij behouden het recht voor en om technische veranderingen en printing-gerelateerde kleurafwijkingen aan te passen. 07-2017 Cleopatra B.V. Oostzijde 295, 1508 EN Zaandam T: +31-75-6478200, info@cleopatra.nl, www.cleopatra.nl We reserve the right and to adjust technical changes and printing-related color deviations.
