Lectrotab Oval SETR-61 Operating Manual page 9

Oval Programming Chart for SETR-61 Series
Enter/Adjust/Exit Program Mode:
To enter program mode main power must be on and aux 12vdc must be off.
Press and hold key noted in "Enter" column (see chart below) for more than 2 seconds, then apply 12vdc to Aux terminal. Release the button.
Press "STBD BOW UP or DOWN" to change the value as per Programming Details and chart below.
Press and hold "PORT BOW UP" for more than 2 seconds to exit program mode.
Function Enter
Timing PORT BOW DOWN
LED's On/Off PORT BOW UP
Swap LED's STBD BOW DOWN
Programming Details:
Timing: #LED's lit corresponds to the #seconds in actuator stroke time i.e. 8 LED's = 8 seconds, 4 LED's = 4 seconds
(Actuator's A and B series = 8 seconds, C and D series = 4 seconds and S series = 6 seconds)
LED's On/Off: 8 LED's lit on right side = LED On state, 1 LED lit on right side = LED Off state
Swap LED's: 1 LED on right and left side = LED lights opposite side of key press, 8 LED's on right and left side = LED lights same side
as key press
