Rongpeng R805 Instruction Manual

Air-powered spray gun, touch up spray gun
Hide thumbs

Advertisement

Table of Contents

AIR-POWERED SPRAY GUN
IMPORTANT:
Residual Risks
Even when the tool is used as prescribed it is not possible to eliminate all residual risk factors.
The following hazards may arise in connection with the tool's construction and design:
TOUCH UP SPRAY GUN
MODEL
INSTRUCTION MANUAL
Read all safety rules and operating Instructions
carefully before starting the product.
Keep this Manual for future reference.
- 1 -
R805
Wear gloves and respirator.
2018

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the R805 and is the answer not in the manual?

Questions and answers

Related Manuals for Rongpeng R805

Summary of Contents for Rongpeng R805

  • Page 1 AIR-POWERED SPRAY GUN TOUCH UP SPRAY GUN MODEL R805 INSTRUCTION MANUAL IMPORTANT: Read all safety rules and operating Instructions carefully before starting the product. Keep this Manual for future reference. 2018 Residual Risks Even when the tool is used as prescribed it is not possible to eliminate all residual risk factors.
  • Page 2 TABLE OF CONTENTS:  DESCRIPTION  TECHNICAL DATA  IMPORTANT SAFETY INSTRUCTION  KEY PARTS DIAGRAM  INSTRUCTIONS FOR OPERATION  MAINTENANCE  TROUBLESHOOTING  EXPLODED VIEW  PARTS LIST  Description This VALU-AIR Air-powered Gravity-feed Spray Gun is a TOUCH UP sprayer. This tool applies paint with less force, reducing the bounce of the material from the surface to be painted.
  • Page 3  Instructions For Operation  Key parts Diagram Cap, nozzle and needle Fluid Control Pattern Control Trigger Air Flow Control 1. Fluid Control: Controls the volume ofmaterial that travels through the fluidtip. 2. Pattern Control: Adjusts the spray pattern from a round pattern to a wide fan. 3.

  • Page 4: Atomizing Cap And Fan Adjustments

    WARNING DO NOT EXCEED Maximum Pressure of Spray Gun or any other parts in the compressor system. 5. After Connect the gun to air supply, please make sure that the fluid cap, container and air hose have been connected tightly with spray gun. 6.
  • Page 5  Maintenance Incomplete cleaning could cause function failures and a degradation of the fan form. Proper cleaning is the best way to ensure trouble free performance from your spray gun. If your gun is not thoroughly cleaned, damage and poor spraying will result. Problems caused by improper cleaning will not be covered by the warranty.
  • Page 6  Remove and clean the inside and outside of the air cap with a brush soaked in cleaning solvent. Note: Wash the air cap(1) carefully without causing any damage to its air hole as this would affect the spraying pattern. Never use a steel wire or wire brush for cleaning.If the air hole is clogged, clean it using a wooden toothpick(2).

  • Page 7: Trouble Shooting

     Trouble shooting WARNING Potential hazard that could result in serious injury or loss of life. • If any of the following symptoms appear while the tool is in use, turn it off and disconnect it from the air supply immediately.
  • Page 8  Explode view & Parts List NO. Description Qty. NO. Description Qty. Description Qty. Air Adjustment Knob Nut Sleeve Cup cover Air Adjustment Seat O-ring 17*1.5 Hex nut O-ring 2.5x2.1 Nozzle Needle Gasket Nozzle Gasket Needle spring Air Inlet Spring Guide Bolt Air Valve Stem Needle Sealing Gasket...
