Manual Programming Mode - Autoleads ControlPRO CP2-UNI User Manual

PC Application Mode
3. PLEASE NOTE: It may be necessary to update
your Microsoft .NET Framework. If you require this
update your PC will automatically notify you. If you
do not get a notification, then you do not require
the update.
4. Launch the application or software and follow the
on screen prompts

Manual Programming Mode

With this method the steering wheel button values
must be manually programmed into the CP2 by using
either the PC application or the programming button
located on the module. The vehicle dipswitches on
the side of the interface must all be set to the up
(off) position.
PLEASE NOTE: This mode is only compatible in
vehicles with both analog steering controls and a
12v Accessory wire. Vehicles with CAN-Bus buttons
cannot be manually programmed.
The radio dipswitches must be set to the correct
radio configuration.
www.autoleads.co.uk/XXXXXX
1. Visit
the Autoleads ControlPro PC application.
2. Launch the application and find the installation
instructions for your vehicle
3. Set the radio dipswitches according to the chart
on the next page
4. Connect the interface according to the installation
instructions.
5. You can now either connect the CP2 to your PC
and use the application to program the steering
control values or follow the programming
instructions on the next page
email - technical.eu@aampglobal.com
www.autoleads.co.uk
to download
