Technical Note
Introduction
This document describes how to connect a Honeywell HJK7000 UltraKey Plus keyboard
controller (HJK7000) to an Enterprise Alpha Viewer workstation (Viewer) to control PTZ
cameras. This provides an optional method of controlling PTZ cameras instead of using a
mouse on the Viewer GUI.
To connect an HJK7000, the Viewer workstation must be licensed with the SCP (Simple Control
Protocol) license in License Manager. The SCP Manager application is used to configure the
Enterprise Alpha NVR system for an external keyboard or other device using a similar protocol.
Terms, Acronyms and Abbreviations
Table 1
Term
DVR/ NVR
Device
License
iKey
RS232/ RS485
Alpha technology ®
GUI
O/S
PTZ
explains the terms, acronyms, and abbreviations used within this document.
Table 1
Terms, Acronyms, and Abbreviations
Definition
Digital Video Recorder- Digital recorder that stores video and
associated events from analog cameras.
Network Video Recorder- A device that primarily records video and
associated events from network devices.
Recorder, Streamer, Cameras, Peripheral units
A string of digits applied to the software to enable or disable
functions, features and numbers of devices supported in the
software
USB license key, also called a dongle, with encrypted license
information
Serial communication ports for transfer of Text/Data or PTZ data
A proprietary technology used by the Video server to compress
and encrypt the video and event data
Graphical User Interface, program(s) running on the Windows®
O/S
Microsoft Windows® platform- operating system
Pan, Tilt, Zoom operations
Document 800-18320 – Rev A – 04/2014
Advertisement
Table of Contents
Related Manuals for Honeywell HJK7000 UltraKey Plus
Summary of Contents for Honeywell HJK7000 UltraKey Plus
- Page 1 Technical Note Introduction This document describes how to connect a Honeywell HJK7000 UltraKey Plus keyboard controller (HJK7000) to an Enterprise Alpha Viewer workstation (Viewer) to control PTZ cameras. This provides an optional method of controlling PTZ cameras instead of using a mouse on the Viewer GUI.
-
Page 2: Connecting An Enterprise Workstation To An Hjk7000
2 | Configuring HJK7000 UltraKey Plus Joystick With Enterprise ALPHA Technical Note Table 1 Terms, Acronyms, and Abbreviations Term Definition UltraKey Plus / HJK7000 Honeywell programmable keyboard with color touch screen LCD Viewer Enterprise Alpha NVR viewing application Viewer Manager... -
Page 3: Configuring The Hjk7000 Port
Configuring the HJK7000 Port To configure the port on the HJK7000 after you have made the physical connection between the Enterprise Alpha workstation running Viewer: Power up the HJK7000. Press Alt + Clr + Home keys (simultaneously) on the HJK7000, When prompted, log on. -
Page 4: Configuring The Port Settings On The Workstation
4 | Configuring HJK7000 UltraKey Plus Joystick With Enterprise ALPHA Technical Note Configuring the Port Settings on the Workstation Note The following procedure may vary, depending on your version of Windows OS. Right-click My computer, then click Properties. Select Device Manager, then Ports. -
Page 5: Modifying The C: Dvmsscpman.ini File
Modifying the c: \DVMS\scpman.ini File The Simple Control Protocol (SCP) application is normally hidden; that is, running in the background. Once the SCP routine is running the user does not need to see the window associated with SCP control of the system. ... -
Page 6: Configuring Settings In Scp Manager
6 | Configuring HJK7000 UltraKey Plus Joystick With Enterprise ALPHA Technical Note Configuring Settings in SCP Manager Click SCP Manager twice. On the File drop-down menu, select Settings and then select the Keyboard. Set the Device, COM port, Baud rate, Data bit, Stop bit and Parity fields exactly the same as previously set for the HJK7000 and the Viewer workstation. - Page 7 Note The Site and Monitor must be configured in Device Manager and Viewer Manager to be usable. Once these settings are made, PTZ cameras can be controlled by the HJK7000 connected to the Viewer workstation. 800-18320 - A - 04/2014...
