Fitting the All Weather In Ceiling Series Loudspeakers
1
Draw around template and mark centre lines if necessary.
Template
3 Connect speaker cables by pushing down on the
terminals and clamping the bare wire in the through
hole. Once connected close the protective cover.
5
Tighten the 3 Tri-Grip screws and replace the protective
screw covers.
See over tightening warning.
2
211mm (8 ")
1/4
AWC265 & AWC265-T2
All Weather In Ceiling Series
2
Cut around marked line.
4
Guide speaker into cut out.
6
Fit grilles. They are held in place magnetically and
should 'snap' into place.
