PCI-PDISO16 User's Guide
Pin Signal Name
50 NC
48 NC
46 NC
44 NC
42 NC
40 RELAY 6 (NC)
38 RELAY 7 (NC)
36 RELAY 0 (C)
34 RELAY 1 (NO)
32 RELAY 1 (NC)
30 RELAY 2 (C)
28 RELAY 3 (NO)
26 RELAY 3 (NC)
24 RELAY 4 (C)
22 RELAY 5 (NO)
20 RELAY 6 (NO)
18 RELAY 7 (NO)
16 INPUT 0
14 INPUT 1
12 INPUT 2
10 INPUT 3
8 INPUT 4
6 INPUT 5
4 INPUT 6
2 INPUT 7
Table 5-1. Port A (P2) connector pin out
5-3
Pin Signal Name
49 NC
47 NC
45 NC
43 NC
41 NC
39 RELAY 5 (NC)
37 RELAY 0 (NO)
35 RELAY 0 (NC)
33 RELAY 1 (C)
31 RELAY 2 (NO)
29 RELAY 2 (NC)
27 RELAY 3 (C)
25 RELAY 4 (NO)
23 RELAY 4 (NC)
21 RELAY 5 (C)
19 RELAY 6 (C)
17 RELAY 7 (C)
15 INPUT 0
13 INPUT 1
11 INPUT 2
9 INPUT 3
7 INPUT 4
5 INPUT 5
3 INPUT 6
1 INPUT 7
