PCI-PDISO16 User's Guide
Table 2-3.
Port B connector
pinout
Caution!
High voltages are present on the PCI-PDISO16 board when you connect high
voltage inputs or outputs to the board's connector. Use extreme caution! Never handle the
PCI-PDISO16 board when signals are connected to the board through the connector. Do not
remove the protective plates on the PCI-PDISO16 board.
2
50
50-pin Female
IDC Connector
Details on this cable are available on our web site at
www.mccdaq.com/cbicatalog/cbiproduct.asp?dept_id=104&pf_id=136.
Signal Name
NC
NC
NC
NC
NC
RELAY 6 (NC)
RELAY 7 (NC)
RELAY 0 (C)
RELAY 1 (NO)
RELAY 1 (NC)
RELAY 2 (C)
RELAY 3 (NO)
RELAY 3 (NC)
RELAY 4 (C)
RELAY 5 (NO)
RELAY 6 (NO)
RELAY 7 (NO)
INPUT 0
INPUT 1
INPUT 2
INPUT 3
INPUT 4
INPUT 5
INPUT 6
INPUT 7
↓
PCI slot
1
49
Figure 2-2. C50FF-x cable
Pin Pin
• •
50 49
48 • • 47
46 • • 45
44 • • 43
• •
42 41
40 • • 39
38 • • 37
36 • • 35
• •
34 33
32 • • 31
30 • • 29
28 • • 27
• •
26 25
• •
24 23
22 • • 21
20 • • 19
• •
18 17
• •
16 15
14 • • 13
12 • • 11
• •
10 9
8 • • 7
6 • • 5
4 • • 3
2 • • 1
The red stripe
identifies pin # 1
2-8
Installing the Board
Signal Name
NC
NC
NC
NC
NC
RELAY 5 (NC)
RELAY 0 (NO)
RELAY 0 (NC)
RELAY 1 (C)
RELAY 2 (NO)
RELAY 2 (NC)
RELAY 3 (C)
RELAY 4 (NO)
RELAY 4 (NC)
RELAY 5 (C)
RELAY 6 (C)
RELAY 7 (C)
INPUT 0
INPUT 1
INPUT 2
INPUT 3
INPUT 4
INPUT 5
INPUT 6
INPUT 7
2 1
50 49
50-pin Female
IDC connector
