S+S Regeltechnik Thermasreg RTR-S Series Operating Instructions, Mounting & Installation

Room temperature controllers, continuous, on-wall
Hide thumbs Also See for Thermasreg RTR-S Series:

Advertisement

D G F r
6002-3000-2011-000 23000-2017 V101 12 ⁄ 2016
RTR - S
THERMASREG
® 
D
Bedienungs- und Montageanleitung
Raumtemperaturregler, stetig,
Aufputz
G
Operating Instructions, Mounting & Installation
Room temperature controllers, continuous,
on-wall
F
Notice d'instruction
Thermostat d'ambiance analogique,
en saillie
r
Руководство по монтажу и обслуживанию
Терморегулятор для внутренних помещений,
с аналоговым выходом, для открытой установки
S+S REGELTECHNIK GMBH
PIRNAER STRASSE 20
90411 NÜRNBERG ⁄ GERMANY
FON +49 (0) 911 ⁄ 5 19 47- 0
FAX +49 (0) 911 ⁄ 5 19 47- 70
mail@SplusS.de
www.SplusS.de
Herzlichen Glückwunsch!
Sie haben ein deutsches Qualitätsprodukt erworben.
Congratulations!
You have bought a German quality product.
Félicitations !
Vous avez fait l'acquisition d'un produit allemand de qualité.
Примите наши поздравления !
Вы приобрели качественный продукт, изготовленный в Германии.
RTR - S 010
RTR - S 015
