Required Tools
You will need these tools to install the 10-Gigabit Ethernet X2 transceiver modules:
•
•
•
•
Installing the 10-Gigabit Ethernet X2 Transceiver Module
Note
This installation procedure applies to both the spring-loaded and non-spring-loaded X2 transceiver
modules.
The X2 transceiver is a static-sensitive device. Always use an ESD wrist strap or similar individual
Caution
grounding device when handling X2 transceivers or coming into contact with system modules.
To install an X2 transceiver module, follow these steps:
Step 1
Using a small flat-blade screwdriver, carefully pry the X2 transceiver port cover off of the system module
faceplate. Use the two arrows on the port cover as guides for inserting the screwdriver blade. Save the
port cover for future use.
Remove the new X2 transceiver module from its protective packaging.
Step 2
Check the label on the X2 transceiver module body to verify that you have the correct model for your
Step 3
network.
Remove the dust plug from X2 transceiver module optical port and set it aside.
Step 4
Slide the X2 transceiver into the transceiver socket on the system module front panel until the X2
Step 5
transceiver EMI gasket flange makes contact with the system module faceplate. (See
Note
OL-23589-01
Small flat-blade screwdriver for removing the X2 transceiver socket covers.
Wrist strap or other personal grounding device to prevent ESD occurrences.
Antistatic mat or antistatic foam to set the transceiver on.
Fiber-optic end-face cleaning tools and inspection equipment. For complete information on
inspecting and cleaning fiber-optic connections, refer to the Inspection and Cleaning Procedures for
Fiber-Optic Connections document at this URL:
http://www.cisco.com/en/US/tech/tk482/tk876/technologies_white_paper09186a0080254eba.shtml
10-Gigabit Ethernet X2 transceiver modules are keyed to prevent incorrect insertion.
Cisco 10-Gigabit Ethernet X2 Transceiver Modules Installation Note
Required Tools
Figure
2.)
13
