Installation

2 - Dynamic IP Address Assignment

Insert SNMPWEBCARD in Accessory Slot: Use a screwdriver to remove
2-1
the accessory slot cover from the UPS. While the UPS is turned on, align
the SNMPWEBCARD with the guides in the accessory slot and push the
card into the slot until the ports are nearly even with the rear surface of the
UPS.
Connect SNMPWEBCARD to Network: Connect a standard Ethernet
2-2
patch cable to the RJ-45 Ethernet port on the card. Note: This port does not
support PoE (Power over Ethernet) applications. The card will attempt to
obtain an IP address via DHCP. This may take as long as several minutes,
depending on your network environment.
Discover IP Address: Contact your network administrator to determine
2-3
which IP address has been assigned to the card by the DHCP server. The
card can be identified on the DHCP server by referring to its MAC address
(see Step
address, depending on your application. After you have discovered the IP
address, proceed to 4 -Test and Configure. Note: The DHCP addresss is
also displayed during boot-up when connected to a computer through the
configuration cable and a terminal emulation program.
3 - Static IP Address Assignment/Terminal Menu

Configuration Settings

Determine IP Information: Before assigning a static IP address, you'll
3-1
need to know the IP address, gateway address and subnet mask. If you do
not have this information, contact your network administrator for assistance.
200907010 93-2916.indb 3
). You may wish to request a long-term lease period for the IP
1-3
