User's Manual
BGT-100P/102P
mPOS Thermal Printer
Rev. 1.00
http://www.bixolon.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BGT-102P and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for BIXOLON BGT-102P

Summary of Contents for BIXOLON BGT-102P

  • Page 1 User’s Manual BGT-100P/102P mPOS Thermal Printer Rev. 1.00 http://www.bixolon.com...

  • Page 2: Safety Precautions

    BGT-100P/102P ■ Safety Precautions In using the present appliance, please keep the following safety regulations in order to prevent any hazard or material damage. WARNING Violating following instructions can cause serious injury or death. Do not plug several products in one multi-outlet. You must use only the supplied adapter.
  • Page 3 BGT-100P/102P CAUTION Violating following instructions can cause slight wound or damage the appliance. Keep the desiccant out of children’s reach. If you observe a strange smoke, odor or noise from the printer, unplug it before taking following • If not, they may eat it. measures.
  • Page 4 BGT-100P/102P ■ Warning - U.S.A Class A Digital Device : Wired Device This equipment has been tested and found to comply with the limits for a Class A digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 5: Label Material

    BGT-100P/102P ■ Caution Some semiconductor devices are easily damaged by static electricity. You should turn the printer “OFF”, before you connect or remove the cables on the rear side, in order to guard the printer against the static electricity. If the printer is damaged by the static electricity, you should turn the printer “OFF”.
  • Page 6 - The following Bluetooth mark and QD ID B021701 is only applicable to models with the Bluetooth SIG qualification. We at Bixolon Co., Ltd. constantly strive to improve product functions and quality. To do this, the specifications of our product and the contents of the manual may change without prior notice.

  • Page 7: Table Of Contents

    BGT-100P/102P ■ Table of Contents 1. Installing Printer and Getting Started ................8 1-1 Unpacking ........................8 1-2 Interface ........................9 1-2-1 USB Interface(Host Function USB A type connector) ........9 1-2-2 USB Interface(Device Function USB B type connector) ......10 1-2-3 Ethernet Interface ..................

  • Page 8: Installing Printer And Getting Started

    BGT-100P/102P 1. Installing Printer and Getting Started 1-1 Unpacking Check the following contents list, and contact your dealer for assistance if any item is missing or incorrect. BGT-100P/102P Cable Cover Paper Installation Guide AC/DC Adapter Power Cord - 8 - Rev.

  • Page 9: Interface

    BGT-100P/102P 1-2 Interface Connect the printer to the host computer using the right interface cable that complies with the specifications of the interface. The drawer to be used with the printer should meet the specifications of the printer. ※ CAUTIONS Before connecting any cables, make sure that both the printer and the host are turned off.

  • Page 10: Usb Interface(Device Function Usb B Type Connector)

    WHITE BROWN Reserved BROWN Reserved * If you push the function key, IP and MAC information can be obtained. * Refer to the Network Manual that is available from the BIXOLON website for more detailed information. - 10 - Rev. 1.00...

  • Page 11: Bluetooth Interface

    BGT-100P/102P 1-2-4 Bluetooth Interface 1) Bluetooth Communication Specifications Item Specifications Frequency 2.402 ~ 2.480 GHz Version 2.1 + EDR Module Type Class 1 2) Bluetooth Connection Printer can be connected to terminal devices with Bluetooth communication capability (PDA, PC, smartphone, tablet PC, etc.) * Refer to the Bluetooth Connection Manual for more detailed instructions about how to establish the connection.

  • Page 12: Setting Dip Switches

    BGT-100P/102P 1-4 Setting Dip Switches Switch (SW1) Function Default None None Print Density Refer to the following table None None Emergency Download Deactivated Activated None *1) Print Density(DIP Switch) Print Density Default Level 1 (Low) Level 2 Level 1 Level 3 Level 4 (High) ※...

  • Page 13: Installing & Replacing Paper

    BGT-100P/102P 1-5 Installing & Replacing Paper ※ CAUTIONS Only use paper that meets the specifications otherwise the printer cannot recognize that paper is not loaded. 1-5-1 Make sure that the printer is not receiving data; otherwise, data may be lost. 1-5-2 Open the paper roll cover by pressing the Cover-Open button.
  • Page 14 BGT-100P/102P 1-5-5 Check the orientation of the roll paper when inserting it into the printer. 1-5-6 Pull out a small amount of paper as shown in the picture, and close the cover. ※ CAUTIONS When closing the cover, hold down the center of printer cover firmly so that paper roll is loaded correctly.

  • Page 15: Recommended Papers

    BGT-100P/102P 1-6 Recommended Papers - TF50KS-E (Paper Thickness: 65μm): Nippon Paper Industries Co., Ltd. - PD 160R (Paper Thickness: 75μm): New Oji Paper Mfg. Co., Ltd. - P350 (Paper Thickness: 62μm): Kansaki Specialty Paper, Inc. (USA) ※ CAUTIONS Use of papers other than those recommended above may damage TPH or degrade the printing quality and our company is not responsible for the damage caused by non- recommended papers.

  • Page 16: Removing Paper Jam

    BGT-100P/102P 1-8 Removing Paper Jam 1-8-1 When a paper jam occurs, turn the printer OFF and then back ON, open the cover, and remove the jammed paper. ※ In case of a minor jam, it may be possible that the operating blade returns to the original position and cover can be opened simply by turning the printer OFF and then back ON.

  • Page 17: Adjusting Paper Near-End Sensor Setting

    BGT-100P/102P 1-9 Adjusting Paper Near-end Sensor Setting BGT-100P/102P printer has built-in near-end sensors that provides an alarm signal when the paper has run almost to the end. BGT-100P/102P can be configured as wall mounted or desktop operation and the settings of the paper near-end sensor should be adjusted accordingly.

  • Page 18: Connecting A Computer

    BGT-100P/102P 1-11 Connecting a Computer Use the cable that comes with the printer to connect the printer to computers. 1-11-1 Plug the cable connector securely into the printer’s interface connector located in the back of the printer. 1-12 Connecting Power Supply ※...

  • Page 19: Self-Test

    BGT-100P/102P 2. Self-Test The self-test checks whether the printer has any problems. If the printer does not function properly, contact your dealer. The self-test procedure is as follows: 2-1 Make sure paper roll has been installed properly. 2-2 Turn on the power while holding down the FEED button and the self-test begins. 2-3 The self-test prints the current status of the printer including control ROM version and the DIP switch settings.
  • Page 20 BGT-100P/102P 2-5-2 Virtual Switch Setting Mode 2-5-2-1 When the printer goes into virtual switch-setting mode, the following lines will be printed: ** VMSM Selection ** 0: Exit and reboot printer 1: Print current settings 2: Set Print Density 3: Set Print Speed 4: Set Cutting mode 5: Set External Buzzer after cutting 6: Set Internal Buzzer after cutting...

  • Page 21: Hexadecimal Dumping

    BGT-100P/102P 3. Hexadecimal Dumping This function allows experienced users to see exactly what data is coming to the printer. This can be useful in finding software problems. When you turn on the hexadecimal dump function, the printer prints all commands and data in hexadecimal format along with a guide section to help you find specific commands.

  • Page 22: Specifications

    2 inches 57.5±0.5 mm BGT-100P: 42 (Font A), 56 (Font B), 56 (Font C) No. of Characters per Line BGT-102P: 48 (Font A), 64 (Font B), 64 (Font C) (Default Value) BGT-100P: Max. 300 mm/sec Printing Speed BGT-102P: Max. 270 mm/sec...

  • Page 23: Appendix

    BGT-100P/102P 5. Appendix 5-1 Cleaning Printer Paper dust inside the printer may lower the print quality. In this case clean the printer as follows: 5-1-1 Open the printer cover and remove any paper. 5-1-2 Clean the print head with a cotton swab moistened with alcohol solvent. 5-1-3 Clean the paper sensor and paper roller with a cotton swab and a dry cloth.
