Samsung AM017NN1PEH Series Technical Data Book page 20

5. Dimensional Drawing
Wind-Free 1Way Cassette
• AM056/071NN1DEH/∗∗
138
NO
Gas pipe
01
connection
Liquid pipe
02
connection
20
50
Name
5.2 kW Ø12.70 (1/2")
7.1 kW Ø15.88 (5/8")
5.2 kW Ø6.35 (1/4")
7.1 kW Ø9.52 (3/8")
Ceiling opening dimension
Space of suspension bolts
Description NO
Drain hose connection
03
Power supply/Communication wiring
04
conduit
Air outlet louver
05
06 Air inlet grille
1380
1260
1410
Name
(Unit: mm)
Ceiling
Description
V25 (OD32, ID25)
-
-
-
