PCM / Crusader ECM-07 & ECM-08
Figure 9 PCM / Crusader GCP ECM
Pleasurecraft Engine Group, manufacturer of both PCM and Crusader brand
engines, introduced their ECM-07 engine control system on 2007 model year
engines. Engines produced prior to the 2007 model year used GM-Delphi MEFI
control modules which are described starting on page 12 of this manual.
ECM-07 equipped engines require use of the #94026 GCP scan tool adapter for
diagnostic communication (see photo below). Please note that 2007 year engines
are also equipped with a CAN connector which is compatible with the #94029
CAN adapter, however diagnostics are NOT supported via the CAN connector
on ECM-07 equipped engines. You must use the #94026 GCP adapter.
In 2008 Pleasurecraft Engine Group introduced the ECM-08 module which fully
supports CAN communication for engine diagnostics. ECM-08 based systems
require use of the #94029 scan tool CAN network adapter for all diagnosis and
troubleshooting functions. Be sure to correctly identify the model year of the
engine you are working on and select the correct adapter as shown in the photos
below.
PCM / Crusader GCP CAN Network Adapter
(ECM-07) Adapter Rinda Tech P/N 94029
Rinda Tech P/N 94026
Diagnostic functions for ECM-07 and ECM-08 modules are identical to those
described in the Volvo Penta EGC section of this manual. Refer to page 21 for
a comprehensive description of the available functions.
Page 28
