GM Marine EFI
MEFI 5 & 6 Output Tests
MEFI-5 Output Tests
MIL Lamp
Fuel Pump Output
Check Gauges Lamp
General Warning #1 Output
General Warning #2 Output
RPM Controlled Output
Warning Horn Output
Governor Status Lamp
Oil Level Lamp
Trans Shift Output
Troll Lamp
MEFI-6 Output Tests
DTC Lamp 1
MIL Lamp
RPM Controlled Output
Warning Horn Output
Governor Status Lamp
Fuel Select 1
Fuel Select 2
Intercooler Relay Output
SVS Lamp
DTC Lamp 2
Trans Shift Output
Slow Mode Lamp
DTC Lamp 3
ECM Pin #
J1-12
J1-13
J1-41
J1-51
J1-52
J1-53
J1-54
J1-55
J3-8
J3-13
J3-16
ECM Pin #
J1-51
J1-52
J1-53
J1-54
J1-56
J3-4
J3-6
J3-7
J3-8
J3-9
J3-11
J3-12
J3-14
