RindaTechnologies TechMate Pro User Manual page 18

GM Marine EFI
MEFI-1 EFI Output Tests (MerCruiser only)
MEFI-1 EFI Output Tests (Volvo & Other Makes)
MEFI-2 EFI Output Tests (MerCruiser only)
* Physically connected to J2-11, may electronically respond as J2-12 due to ECM's calibration.
MEFI-2 EFI Output Tests (Volvo and Other Makes)
MEFI 1 & 2 Output Tests
Buzzer Circuit Output 1
Buzzer Circuit Output 2
Fuel Pump Output
IAC Motor Reset
Over Temp Lamp
Buzzer Output
I/O Fluid Level Lamp
Oil Pressure Lamp
Oil Level Lamp
Check Engine Lamp
Fuel Pump Output
IAC Motor Reset
(MerCruiser models using 1996 GM MEFI II ECM only)
Buzzer Circuit Output 1
Buzzer Circuit Output 2
Fuel Pump Output
IAC Motor Reset
Check Gauges Lamp
Buzzer Output
General Warning #1 Output
RPM Controlled Output
Oil Level Lamp
Check Engine Lamp
Fuel Pump Output
IAC Motor Reset
ECM Pin #
J2-11
J2-27
J2-9
J2-11
J2-12
J2-26
J2-27
J2-30
J2-31
J2-9
J2-11 *
J2-26
J2-9
J2-11
J2-12
J2-26
J2-27
J2-30
J2-31
J2-9
