Seav LRX 2145 Quick Start Manual

ELECTRONIC PANEL LRX 2145
Mono-phase electronic exchange, for the automation of swing-
doors with incorporated receiver.
- Mod. LG 2145
- Mod. ( LRQ 2145 )
- Mod. ( LR 2145 )
- Mod. ( LRS 2145 / 330 )
- Mod. ( LRS 2145 / 418 )
- Mod. LRS 2145
( ) This product is designed only for countries in which this
use is allowed

TECHNICAL DATA:

- Power supply :
- Flashing light output:
- Motor output:
- Electric lock output:
- Aux. power output:
- Warning light output:
- Limit switch and BT controls:
- Working temperature:
- Radio receiver:
- Op. transmitters:
- TX max. codes in memory:
- Container dimensiond:
- Protection capability:

TERMINAL BOARD CONNECTION:

CN1 : Terminal board
1 : Earth.
2 : Earth.
3 : Earth.
CN2 : Terminal board
1 : 230 Vac input.
2 : 230 Vac input.
3 : 230 Vac flash input.
4 : 230 Vac flash input.
5 : Opening 1 motor output.
6 : Common 1 motor output.
7 : Closing 1 motor output.
8 : Opening 2 motor output.
9 : Common 2 motor output.
10 : Closing 2 motor output.
CN3 : Terminal board
1 : Electric lock feed output 12 Vac 12 W.
2 : Electric lock feed output 12 Vac 12 W.
3 : 24 Vac 5 W service feed output.
4 : 24 Vac 5 W service feed output.
5 : Warning light output 24 Vac 4 W.
6 : Warning light output 24 Vac 4 W.
7 : Open-close push button input (NA).
8 : Single pedestrian push button input (NA).
9 : Common GND input.
10 : Input lockout (NC).
11 : Safety device input 1 (NC).
12 : Common GND input.
13 : Safety device input 2 (NC).
14 : Opening limit switch input (NC).
: Without radio Receiver
: 30,875 Mhz
: 306 Mhz
: 330 Mhz
: 418 Mhz
: 433,92 Mhz "narrow band"
230 Vac 50-60Hz 20W max.
230 Vac 500 W max.
230 Vac 500 W max.
12 Vac 12 W max.
24 Vac 5 W max.
24 Vac 4 W max.
24 Vcc
-20 ÷ 85 °C
refer to type
12-18 Bit or Rolling Code
120 (CODE or CODE PED)
240x185x110 mm.
GB
15 : Common GND input.
16 : Closing limit switch input (NC).
17 : Aerial earth input .
18 : Aerial hot pole input.
I
MPORTANT NOTICE FOR THE INSTALLER
− In order to have proper functioning of the radio receiver,
in cases where two or more supply-stations are used, it
is advised to install them at a distance of at least 3
metres from each other.
− The supply-station
sectioning mechanism from the electrical line 230 Vac;
it is therefore the responsibility of the installer to see the
installation of a sectioning device within the plant.
− The fixing of the electricity supply cables and their
connection, must be guaranteed by means of the
assembly of the cable presses which are provided as
"optional".
− The input, which is labelled as normally closed (NC),
must be b ondedif not used!!

OPERATING CHARACTERISTICS:

Automatic operation:

By using either the radio control (led CODE on) or the low
tension button panel (PUL) to operate the gates, commands
will have the following effect:
IP 65
The first command impulse activates the opening mechanism
until time expiry of the timing motor or until the gate is fully
opened, the second command impulse closes the gate, if a
command impulse is received before the activation of the limit
switch, the direction of movement of the mechanism will be
reversed whether engaged in opening or closing operations.

Step by step operation:

By using either the radio control (led CODE on) or the low
tension button panel (PUL) to operate the gates, commands
will have the following effect:
The first command impulse activates the opening mechanism
until time expiry of the timing motor or until the gate is fully
opened, the second command impulse closes the gate, if a
command impulse is received before the activation of the limit
switch, the direction of movement of the mechanism will be
halted whether engaged in opening or closing operations.

Automatic closing:

The control board may be set up automatically to close the
gates.
The set-up procedure is described under the instruction for
setting the delay period.

Pedestrian access:

If selected (led PED\ANTA S is off), using the radio command
(led CODE PED is on) or the low tension button panel (PED)
to activate the lock will mean that the first command opens the
lock for 10 seconds and the centre waits for 10 seconds
before closing the lock.
Single wing :
If selected (led PED\ANTA S is on), using the radio command
(led CODE PED is on) and the low tension button panel (PED)
to activate the lock will mean that only motor 1 used with
regard to normal functioning.

Access block:

must not have any type of
