E
P
LECTRONIC
ANEL
Mono-phase electronic exchange, for the automation of gates
with incorporated receiver.
- Mod. LG 2151:
- Mod. ( LRQ 2151 ) :
- Mod. ( LR 2151 ) :
- Mod. ( LR 2151/330 ) :
- Mod. ( LR 2151/418 ) :
- Mod. LRS 2151:
- Mod. LRS 2151 SET : Narrow band
( ) This product is destined only for countries in which this use
is allowed.
T
D
ECHNICAL
ATA
- Power supply:
- Flashing light output:
- Motor output:
- Aux. power output:
- Radio receiver:
- Op. transmitters:
- TX max. codes in memory
- Working temperature:
- Dimension of panel:
- Degree of panel protection:
T
B
C
ERMINAL
OARD
ONNECTION
1: 230VAC input.
2: 230VAC input.
3: 230VAC flash input.
4: 230VAC flash input.
5: Opening 1 motor output.
6: Common 1 motor output.
7: Closing 1 motor output.
8: Opening 2 motor output.
9: Common 2 motor output.
10: Closing 2 motor output.
T
B
C
ERMINAL
OARD
ONNECTION
1: 24VAC 5W service feed output.
2: 24VAC 5W service feed output.
3: Open-close push button input (NA).
4: Common GND input.
5: Safety device input (NC).
6: Aerial earth input.
7: Aerial hot pole.
O
C
PERATING
HARACTERISTICS
Selection of Automatic operation or Step by step
operation :
The centre in its default setting shows the automatic working
function set. To set the step by step function: press the MODE
button continuously for 5 seconds, when all the signalling
Leds are flashing, the programming is stored. If on the other
hand, the memorized function is to be removed, follow the
same
programming
procedure
procedure.
Automatic operation:
By using either the radio control (led CODE on) or the low
tension button panel (PUL) to operate the gates, commands
will have the following effect: the first command impulse
activates the opening mechanism
timing motor or until the gate is fully opened, the second
command impulse closes the gate, if a command impulse is
received before the activation of the limit switch, the direction
LRX 2151
Without radio Receiver
30,875MHz
306
330
418
433,92 MHz
433,92 MHz
230VAC 50-60Hz 8W Max
230VAC 500W Max
230VAC 500W Max
24VAC 5W Max
refer to type
12-18 Bit or Rolling Code
63 different codes
-20÷85°C
110x150x75mm
( ABS V-0 ) IP 55
CN1
CN2
or
follow
the
RESET
until time expiry of the
GB
of movement of the mechanism will be reversed whether
engaged in opening or closing operations.
Step by step operation:
MHz
By using either the radio control (led CODE on) or the low
MHz
tension button panel (PUL) to operate the gates, commands
MHz
will have the following effect: the first command impulse
activates the opening mechanism
timing motor or until the gate is fully opened, the second
command impulse closes the gate, if a command impulse is
received before the activation of the limit switch, the direction
of movement of the mechanism will be halted whether
engaged in opening or closing operations.
Automatic closing
The control board may be set up automatically to close the
gates.
The set-up procedure is described under the instruction for
setting the delay period.
Safety device
The control board allows for the connection and control of
Photocells, Tyre sensors (NC).
Command from these devices are ignored during opening
whilst the gate is closing they will reverse the direction of
movement.
If not used the terminals must be jumped.
Electronic clutch
The control is equipped with an adjustable electronic clutch,
using Trimmer VR1. To adjust, move Trimmer VR1 until the
device moves, but can still be blocked by an obstacle (for
example, the test can be carried out by blocking the device
with the hands).
Functioning of the Flasher
The panel board is powered by an output for the use of a
flasher 230VAC. Its function is conditioned by the movement of
the motor and the automatic closure that when inserted
enables the flash even during a pause.
P
ROGRAMMING
SEL button: selects the type of function to be memorised, the
selection is indicated by a flashing Led.
By repeatedly pressing the button it is possible to choose the
desired function. The selection will remain active for 10
seconds indicated by a flashing Led, if no other operations are
executed during this period, the control board will return to its
previous state.
SET button: programmes the information relative the type of
function previously selected with the SEL button.
Led Reference
1) CODE
2) T. MOT.
3) T. PAUSE
4) RIT. ANTE AP
5) RIT. ANTE CH No wing delay
1) CODE: (Radio control code)
The board allows the memorisation up to 63 radio commands
having different codes, which are either fixed or rolling code.
Programming:
the following manner: press the SEL button until the CODE led
3
until time expiry of the
Led off
Led on
No code
Code activated
Unlimited timing
Programmed delay
No automatic close With automatic close
No wing delay
Programmed delay
Programmed delay
The transmission code is programmed in
Rev. 1.3 11/03
