Intelligent-Lab™ range of balances
We have a combined 60 years of experience in the
weighing and measurement industry, both in the USA and
worldwide. With contacts in over 50 countries, we provide
you with the weighing and measurement equipment you
need.
QUALITY • Products solidly built from the ground up with
superior engineering and components for exacting results.
VALUE • Equipment priced for real-world business
applications, with superior service and support.
EXPERIENCE • Expert advice to help you choose just the
right product for your application.
Quality + Value + Experience ...it adds up to the Intelligent
Investment.
Intelligentwt.com
Cl
Intelligent
Wei
ghing Technology, I
nc.
2016 All rights reserved
The Information contained
herein
Is the property of Intelligent Weighing
without liability for
errors
or omissions. No part may be reproduced or used except as authorized by contract
or
other
written
permission.
The copyright and the foregoing restriction on
media in which the information may be
embodied.
worldwide.
Technology, Inc.
and Is supplied
reproduction
and use extend to all
Intelligent-Lab Models
PBW
PMW
USER MANUAL
Ver sion: H 16 V 0 2
Advertisement
Table of Contents
Related Manuals for Intelligent Intelligent-Lab PBW
Summary of Contents for Intelligent Intelligent-Lab PBW
- Page 1 VALUE • Equipment priced for real-world business applications, with superior service and support. EXPERIENCE • Expert advice to help you choose just the right product for your application. Quality + Value + Experience ...it adds up to the Intelligent Investment. Intelligentwt.com Intelligent...
-
Page 2: Table Of Contents
CONTENTS I. Notes................1 II. General Information............1 i. Overview..............1 ii. Parameters..............2 iii. Display...............3 iv. Panel Functions............3 III. Instruction for Use............4 i. Precautions Before use..........4 ii. Storage and shipping conditions........ 4 iii. -
Page 3: Notes
I. Notes 1.) Please do not get the balance wet. If the balance gets wet, please wipe it with a dry cloth. If water damage occurs, this will void your warranty. 2.) Do not drop or shock the balance. Do not drop any item(s) onto the weighing tray. -
Page 4: Parameters
processes the weight very quickly and will provide you with a very speedy weighing experience. The glass windshield protects against wind (PMW only). The integrated RS232 enables you to auto send the weighing data to PC or other equipment if you have the required software. In order to provide a quick and easy weighing experience, the following functions are included. -
Page 5: Display
iii. Display Battery Indicator Animal Weighing Calibration Indicator Negative Weight Symbol Zero and Tare Overloading Indicator Sleeping mode Percent weighing Indicator High Limit Value OK Limit Value Low Limit Value iv. Panel Functions Name Function Switch on or off Calibration Print Function Units conversion &... -
Page 6: Instruction For Use
III. Instructions for Use i. Precautions Before use 1.) The balance must be used on a stable, flat, and vibration free surface in order to achieve accurate measurements. 2.) Please use an independent power outlet to avoid interference by other electronic appliances. 3.) In order to bring the balance into a horizontal position, the adjustable feet can be turned either clockwise or counter- clockwise until the air bubble is in the center of the marked circle. -
Page 7: Calibration
* Glass windshield (PMW only) * Weighing pan * AC adapter * Calibration weight 2) Installation instructions * Place the weighing pan on the balance. * Leveling the balance using the leveling feet so that the air bubble is centered within the circle of the level indicator. * Plug the cord on the AC adapter into the AC jack;... - Page 8 Place the required weight as indicated on the screen on the center 4.) Once the required weight is placed on the scale it will show lines across the screen -------, Then it will show the required weight once more. 5.) Then remove the weight and the screen will show ------ then set back to zero.
-
Page 9: Operations
Then set back to zero. Calibration is complete. V. Operations i. Turning the balance On/Off Press ON/OFF KEY to switch the balance On and Off. ii. Zero and Tare Function (Always press this before weighing for more accurate results. Press TARE will deduct the container weight or return the display to zero. -
Page 10: Check Weighing
vi Check Weighing 1. Preset high & low limit values operation... -
Page 11: Animal Weighing
2. Display high & low limit values operation Press MODE key for about 3s and the screen will show "COU", Press MODE key twice and the screen will show "PST". And press PRINT key and the screen will show "----Hi----", and than the screen display high limit values. -
Page 12: Rs232 Transmission
VI. RS232 Transmission 1. RS232 cable Format Data Baud rate: 1200, 2400, 4800 or 9600(defaut) Data bits: 8 BITS. Parity bit: None . Stop bits: 1 BIT. 1) SET-UP menu select CLA--0,data format as follow: SET-UP menu select CLA--1,data format as follow: VII.POWER LOW BATTERY LCD series has the function of detecting the battery all the... -
Page 13: Troubleshooting Guide
Charging tips In LCD series when Battery status indication is " " and hold on. It means the battery will be full after recharging 1~2 more hours (Usually, it takes about 8~10 hours to charge fully.). VIII. Troubleszzhooting Guide Problems Reasons Ways to solve When the screen... -
Page 14: Advanced Function Setting
IX. Advanced Function Setting PressTARE until the screen shows sensor code, then press MODE will enter the advanced function setting (Press CAL to select, press MODE to confirm, press ON/OFF to exit.). 1) C Function (Zero Tracking Selection) C---1: No zero tracking C---2: Zero tracking +/-1d (default) C---3: Zero tracking +/-2d Note: The value is larger, the system is more stable;... - Page 15 b---3: 4800 bps b---4: 9600 bps (default) 6) BL Function (Power-saving mode Selection) BL---1: power saving turns off, backlight turns on. BL---2: Power-saving mode turns on. Power-saving mode will auto turn on within 60 seconds no using of the balance.(default) BL---3: Power-saving mode turns off, backlight turns off.
-
Page 16: Unit Conversion Table
X. Unit conversion table Mark Unit Conversion Factor gram carat ounce 0.03527396200 troy ounce 0.03215074700 Pennyweight 0.64301493100 Grain 15.43235835000 pounds 0.00220462260 kilogram 0.00100000000 Taiwanese tael 0.02666666000 Hong Kong tael 0.0271700000 grams for square meter Tola/anna/ratti 0.01.2.2 Tola/masha/ratti 0.01.0.2 XI. Warranty The balance is warranted for one year from the date of purchase against defects in materials and/or workmanship.
